1 - MOTOR HOUSING
BSD-1605108283.A11
1605108283
|
£16.41
|
£19.69
|
|
|
2 - FIELD 230V
BSD-1604220478.A4
1604220478
|
£30.28
|
£36.33
|
|
|
4 - SWITCH
BSD-1607200256.A26
1607200256
|
£12.04
|
£14.45
|
|
|
5 - POWER SUPPLY CORD EU 4.15m 2x1.0mm H07RN-F
BSD-3604460185.A4
3604460185
|
£21.42
|
£25.71
|
|
|
6 - GROMMET
BSD-1600703044.A4
1600703044
|
£1.95
|
£2.34
|
|
|
7 - FASTENING CLAMP
BSD-1601302017.A721
1601302017
|
£1.66
|
£1.99
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-3601110606.A0
3601110606
|
£2.33
|
£2.80
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A353
1610905025
|
£6.52
|
£7.83
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-1600905032.A213
1600905032
|
£5.58
|
£6.70
|
|
|
17 - SPIRAL SPRING
BSD-1604652021.A76
1604652021
|
£1.66
|
£1.99
|
|
|
18 - SWITCH HANDLE
BSD-1602026091.A59
1602026091
|
£1.66
|
£1.99
|
|
|
19 - COMPRESSION SPRING
BSD-1604611031.A137
1604611031
|
£2.80
|
£3.36
|
|
|
20 - ADJUSTING SLIDE
BSD-1602319026.A6
1602319026
|
£1.66
|
£1.99
|
|
|
24 - COVER
BSD-1605500274.A25
1605500274
|
£2.80
|
£3.36
|
|
|
25 - HOUSING COVER
BSD-1605500276.A59
1605500276
|
£8.67
|
£10.41
|
|
|
27 - RUBBER RING
BSD-1600206025.A711
1600206025
|
£1.95
|
£2.34
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600591047.A30
1600591047
|
£1.95
|
£2.34
|
|
|
30 - AIR DISTRIBUTOR
BSD-1600591048.A54
1600591048
|
£2.33
|
£2.80
|
|
|
31 - BRUSH-COVER
BSD-1605500277.A2
1605500277
|
£1.95
|
£2.34
|
|
|
33 - O-RING 46.0x1.1 MM
BSD-3600210124.A212
3600210124
|
£2.80
|
£3.36
|
|
|
35 - SHIM 0.1 MM
BSD-1600136013.A484
1600136013
|
£2.33
|
£2.80
|
|
|
35 - SHIM 0.2 MM
BSD-1600136014.A36
1600136014
|
£2.33
|
£2.80
|
|
|
35 - SHIM 0.3 MM
BSD-1600136015.A484
1600136015
|
£2.33
|
£2.80
|
|
|
35 - SHIM 0.15 MM
BSD-1600136020.A34
1600136020
|
£3.72
|
£4.47
|
|
|
37 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A389
1600290016
|
£1.95
|
£2.34
|
|
|
40 - RETAINING CLIP
BSD-1600119011.A231
1600119011
|
£1.95
|
£2.34
|
|
|
41 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A805
1600910018
|
£5.30
|
£6.36
|
|
|
45 - HEX NUT M7. SW10
BSD-1603300016.A225
1603300016
|
£1.66
|
£1.99
|
|
|
48 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A16
1613435034
|
£1.66
|
£1.99
|
|
|
49 - TORX OVAL-HEAD SCREW
BSD-3603435055.A1
3603435055
|
£3.72
|
£4.47
|
|
|
50 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1206
2603490023
|
£1.66
|
£1.99
|
|
|
53 - TORX OVAL-HEAD SCREW
BSD-1603435078.A190
1603435078
|
£1.66
|
£1.99
|
|
|
55 - TORX OVAL-HEAD SCREW 4x12
BSD-2603490021.A478
2603490021
|
£1.66
|
£1.99
|
|
|
80 - SEALING DISK
BSD-3600150021.A118
3600150021
|
£3.80
|
£4.56
|
|
|
104 - O-RING 4.5x1.0 MM
BSD-1600210044.A227
1600210044
|
£1.66
|
£1.99
|
|
|
202 - CLAMPING FLANGE dia22.3xdia42 MM
BSD-2605703014.A818
2605703014
|
£7.36
|
£8.83
|
|
|
202/2 - O-RING 20.35x1.78 MM
BSD-1600210055.A18
1600210055
|
-
|
|
|
|
203 - ROUND NUT M14
BSD-1603345043.A847
1603345043
|
£8.67
|
£10.41
|
|
|
205 - REFERENCE PLATE
BSD-3601119236.A1490
3601119236
|
£3.72
|
£4.47
|
|
|
206 - HANDLE
BSD-3602025029.A1
3602025029
|
£40.80
|
£48.96
|
|
|
207 - HEX SCREW
BSD-1619P07611.A4
1619P07611
|
£3.72
|
£4.47
|
|
|
208 - PLAIN WASHER DIN 125-A10.5-ST
BSD-2916011017.A18
2916011017
|
£1.66
|
£1.99
|
|
|
210 - SUCTION HOOD
BSD-3605510063.A1
3605510063
|
£57.02
|
£68.42
|
|
|
211 - SWIVEL ELEMENT
BSD-3605500219.A2
3605500219
|
£18.96
|
£22.75
|
|
|
212 - KNOB
BSD-3602305019.A1
3602305019
|
£4.26
|
£5.11
|
|
|
213 - COMPRESSION SPRING
BSD-3604611042.A0
3604611042
|
£1.66
|
£1.99
|
|
|
214 - METAL RING
BSD-3600190040.A1
3600190040
|
£14.91
|
£17.89
|
|
|
650 - PIN-TYPE FACE-WRENCH
BSD-1607950061.A411
1607950061
|
£5.42
|
£6.50
|
|
|
651 - DIAMOND CUP WHEEL
BSD-3608600013.A1
3608600013
|
£116.15
|
£139.38
|
|
|
803 - ARMATURE WITH FAN 230V
BSD-3607031750.A0
3607031750
|
£116.15
|
£139.38
|
|
|
808 - NAMEPLATE
BSD-160111A3HH.A2
160111A3HH
|
£2.33
|
£2.80
|
|
|
810 - CARBON-BRUSH SET
BSD-1607000V37.A84
1607000V37
|
£14.91
|
£17.89
|
|
|
813 - GROOVE BALL BEARING
BSD-3607031751.A5
3607031751
|
£21.68
|
£26.01
|
|
|
816 - BRUSH HOLDER
BSD-1607000V43.A87
1607000V43
|
£3.72
|
£4.47
|
|
|
818 - PAN HEAD SCREW
BSD-1607000V42.A0
1607000V42
|
£1.66
|
£1.99
|
|
|
821 - GEAR HOUSING
BSD-3607031752.A0
3607031752
|
£81.81
|
£98.17
|
|
|
828 - BEARING FLANGE
BSD-3607031753.A4
3607031753
|
£37.72
|
£45.27
|
|
|
829 - STRIP BRUSH
BSD-3607031875.A0
3607031875
|
£46.37
|
£55.64
|
|
|
832 - GRINDING SPINDLE
BSD-160312307B.A1
160312307B
|
£57.05
|
£68.46
|
|
|
835 - FAN
BSD-1606610132.A144
1606610132
|
£1.95
|
£2.34
|
|
|
838 - GEAR UNIT
BSD-1607000D4Z.A54
1607000D4Z
|
£21.52
|
£25.83
|
|
|
840 - PUSH-BUTTON
BSD-1607000V41.A92
1607000V41
|
£4.26
|
£5.11
|
|
|
851 - SPEED GOVERNOR
BSD-16072335JJ.A4
16072335JJ
|
-
|
|
|
|
866 - STRAP-SHAPED HANDLE
BSD-3607031755.A1
3607031755
|
£68.42
|
£82.10
|
|
|
896 - FAST LOCKING FLANGE M14. SDS-CLIC
BSD-1603340027.A670
1603340027
|
£46.82
|
£56.18
|
|
