2 - FIELD 220-230V
BSD-1604220284.A108
1604220284
|
£30.28
|
£36.33
|
|
|
4 - SWITCH
BSD-1607200150.A6
1607200150
|
£21.52
|
£25.83
|
|
|
5 - POWER SUPPLY CORD EU 4.15m 2x1.0mm H07RN-F
BSD-3604460185.A9
3604460185
|
£21.42
|
£25.71
|
|
|
6 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A174
2600703011
|
£2.80
|
£3.36
|
|
|
7 - FASTENING CLAMP
BSD-1601302017.A1059
1601302017
|
£1.66
|
£1.99
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601118891.A13
1601118891
|
£4.26
|
£5.11
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328042.A133
1607328042
|
£6.52
|
£7.83
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A399
1610905025
|
£6.52
|
£7.83
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-1600905032.A512
1600905032
|
£5.58
|
£6.70
|
|
|
25 - HOUSING COVER
BSD-1600508016.A15
1600508016
|
£6.52
|
£7.83
|
|
|
26 - RUBBER RING
BSD-1600206036.A115
1600206036
|
£1.66
|
£1.99
|
|
|
27 - RUBBER RING
BSD-1600206025.A846
1600206025
|
£1.95
|
£2.34
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600591025.A24
1600591025
|
£2.33
|
£2.80
|
|
|
30 - AIR-DEFLECTOR RING
BSD-1600591014.A282
1600591014
|
£2.33
|
£2.80
|
|
|
32 - GRINDING SPINDLE M14
BSD-3603523041.A10
3603523041
|
£40.80
|
£48.96
|
|
|
33 - O-RING 46.0x1.1 MM
BSD-3600210124.A337
3600210124
|
£2.80
|
£3.36
|
|
|
35 - SHIM 0.1 MM
BSD-1600136013.A209
1600136013
|
£2.33
|
£2.80
|
|
|
35 - SHIM 0.15 MM
BSD-1600136020.A298
1600136020
|
£3.72
|
£4.47
|
|
|
35 - SHIM 0.2 MM
BSD-1600136014.A311
1600136014
|
£2.33
|
£2.80
|
|
|
35 - SHIM 0.3 MM
BSD-1600136015.A209
1600136015
|
£2.33
|
£2.80
|
|
|
37 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A1
1600290016
|
£1.95
|
£2.34
|
|
|
40 - RETAINING CLIP
BSD-1600119011.A550
1600119011
|
£1.95
|
£2.34
|
|
|
41 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A511
1600910018
|
£5.30
|
£6.36
|
|
|
45 - HEX NUT M7. SW10
BSD-1603300016.A437
1603300016
|
£1.66
|
£1.99
|
|
|
47 - PLASTIC-CUTTING SCREW St3.9x12
BSD-1603435042.A434
1603435042
|
£1.66
|
£1.99
|
|
|
49 - TORX OVAL-HEAD SCREW
BSD-3603435047.A9
3603435047
|
£1.66
|
£1.99
|
|
|
50 - TAPPING SCREW DIN7981-ST3.9x19-F-Z
BSD-2912401420.A124
2912401420
|
£1.66
|
£1.99
|
|
|
51 - SPEED GOVERNOR 220-240V
BSD-1607233148.A12
1607233148
|
£52.15
|
£62.58
|
|
|
52 - LIGHT CONDUCTOR
BSD-3604460117.A5
3604460117
|
£2.80
|
£3.36
|
|
|
53 - CONNECTING CABLE L=50 MM
BSD-3604438020.A6
3604438020
|
£3.72
|
£4.47
|
|
|
55 - TORX OVAL-HEAD SCREW
BSD-1603435078.A259
1603435078
|
£1.66
|
£1.99
|
|
|
70 - COVER DISC
BSD-3600150023.A10
3600150023
|
£2.80
|
£3.36
|
|
|
81 - SHIM 0.2 MM
BSD-2600101022.A396
2600101022
|
£1.66
|
£1.99
|
|
|
104 - O-RING 4.0x1.0 MM
BSD-1600210034.A167
1600210034
|
£1.66
|
£1.99
|
|
|
105 - INSULATING PLATE
BSD-1601008005.A14
1601008005
|
£2.80
|
£3.36
|
|
|
154 - DISTANCE PIPE
BSD-3600913010.A10
3600913010
|
£5.58
|
£6.70
|
|
|
155 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A81
2916660013
|
£1.95
|
£2.34
|
|
|
156 - GROOVE BALL BEARING 12x32x10
BSD-3600905130.A10
3600905130
|
£12.04
|
£14.45
|
|
|
157 - SEAL RING
BSD-3600105009.A14
3600105009
|
£6.52
|
£7.83
|
|
|
202 - CLAMPING FLANGE dia22.3xdia42 MM
BSD-2605703014.A461
2605703014
|
£7.36
|
£8.83
|
|
|
203 - ROUND NUT M14
BSD-1603345043.A1259
1603345043
|
£8.67
|
£10.41
|
|
|
205 - REFERENCE PLATE
BSD-3601119236.A1499
3601119236
|
£3.72
|
£4.47
|
|
|
206 - STRAP-SHAPED HANDLE
BSD-3601303016.A9
3601303016
|
£63.50
|
£76.20
|
|
|
207 - HEX SCREW DIN 933 M10x16-8.8
BSD-2911061285.A6
2911061285
|
£1.95
|
£2.34
|
|
|
208 - PLAIN WASHER DIN 125-A10.5-ST
BSD-2916011017.A34
2916011017
|
£1.66
|
£1.99
|
|
|
301/1 - MOTOR HOUSING
BSD-1605108208.A10
1605108208
|
£11.30
|
£13.56
|
|
|
301/16 - BRUSH HOLDER
BSD-1601323025.A243
1601323025
|
£3.72
|
£4.47
|
|
|
301/17 - SPIRAL SPRING
BSD-1604652013.A957
1604652013
|
£1.66
|
£1.99
|
|
|
301/18 - SWITCH HANDLE
BSD-1602026057.A338
1602026057
|
£1.97
|
£2.36
|
|
|
301/19 - COMPRESSION SPRING
BSD-1604611026.A618
1604611026
|
£1.66
|
£1.99
|
|
|
301/20 - ADJUSTING SLIDE
BSD-1602319011.A12
1602319011
|
£1.66
|
£1.99
|
|
|
301/48 - TAPPING SCREW DIN7981-ST2.9x9.5C-Z
BSD-2912401005.A34
2912401005
|
£1.66
|
£1.99
|
|
|
650 - PIN-TYPE FACE-WRENCH
BSD-3607950017.A2
3607950017
|
-
|
|
|
|
803 - ARMATURE WITH FAN 220-240V
BSD-1604010650.A13
1604010650
|
£81.81
|
£98.17
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A2783
160111A3H3
|
£2.33
|
£2.80
|
|
|
810 - CARBON-BRUSH SET
BSD-3607014010.A9
3607014010
|
£21.52
|
£25.83
|
|
|
810 - CARBON-BRUSH SET 10 x 3 607 014 010
BSD-1607000500.A8
1607000500
|
£114.88
|
£137.86
|
|
|
821 - GEAR HOUSING
BSD-16058065B1.A5
16058065B1
|
£37.27
|
£44.72
|
|
|
824 - SUCTION HOOD
BSD-3605510040.A11
3605510040
|
£27.23
|
£32.68
|
|
|
828 - BEARING FLANGE
BSD-3605700158.A8
3605700158
|
£52.15
|
£62.58
|
|
|
829 - STRIP BRUSH
BSD-3600290054.A5
3600290054
|
£12.04
|
£14.45
|
|
|
835 - FAN
BSD-1606610132.A12
1606610132
|
£1.95
|
£2.34
|
|
|
838 - GEAR UNIT
BSD-1607000D4Y.A82
1607000D4Y
|
£21.42
|
£25.71
|
|
|
840 - PUSH-BUTTON
BSD-1607000253.A210
1607000253
|
£2.49
|
£2.99
|
|
|
851 - CUP WHEEL dia 125 MM
BSD-3608600008.A12
3608600008
|
£306.81
|
£368.17
|
|
|
866 - STRAP-SHAPED HANDLE
BSD-3607031584.A12
3607031584
|
£57.05
|
£68.46
|
|
|
890 - O-RING 20.35x1.78 MM
BSD-1600210039.A934
1600210039
|
£1.66
|
£1.99
|
|
