2 - BRUSH HOLDER
BSD-1604336008.A238
1604336008
|
£21.52
|
£25.83
|
|
|
3 - FIELD 220V
BSD-1604220109.A7
1604220109
|
-
|
|
|
|
4 - ARMATURE 220V
BSD-1604011223.A9
1604011223
|
-
|
|
|
|
6 - SPIRAL SPRING
BSD-1604652015.A444
1604652015
|
£2.80
|
£3.36
|
|
|
9 - HANDLE
BSD-1605132083.A11
1605132083
|
-
|
|
|
|
10 - SWITCH
BSD-1607200064.A4
1607200064
|
£40.80
|
£48.96
|
|
|
12 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A449
3600703011
|
£2.80
|
£3.36
|
|
|
13 - POWER SUPPLY CORD GB 110V 4.15m 2 x 1.5mm H07RN-F
BSD-1604460203.A65
1604460203
|
£33.74
|
£40.49
|
|
|
14 - SUPPRESSION FILTER
BSD-1607328034.A159
1607328034
|
£4.26
|
£5.11
|
|
|
17 - COVER PLATE
BSD-1601037006.A116
1601037006
|
-
|
|
|
|
19/00/08 - FELT WASHER
BSD-1600205019.A61
1600205019
|
£1.75
|
£2.10
|
|
|
20 - BEARING COVER
BSD-1605808054.A290
1605808054
|
-
|
|
|
|
21 - COVER DISC
BSD-1600102012.A289
1600102012
|
-
|
|
|
|
23 - SEALING DISK
BSD-1600108055.A74
1600108055
|
£1.75
|
£2.10
|
|
|
27 - NEEDLE BEARING dia22x11.3 MM
BSD-1600910010.A292
1600910010
|
£45.67
|
£54.80
|
|
|
28 - RUBBER RING 10 MM
BSD-1600206014.A47
1600206014
|
£1.75
|
£2.10
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600502007.A42
1600502007
|
-
|
|
|
|
30 - SPRING RETAINING RING DIN 472 38X1.5MM
BSD-2916660017.A34
2916660017
|
£4.26
|
£5.11
|
|
|
32 - ROTARY SHAFT LIP SEAL
BSD-1600290008.A81
1600290008
|
£2.61
|
£3.13
|
|
|
34 - SHIM 0.1 MM
BSD-1600190004.A119
1600190004
|
-
|
|
|
|
34 - SHIM 0.2 MM
BSD-1600190005.A164
1600190005
|
£1.32
|
£1.58
|
|
|
35 - TAB WASHER
BSD-1601030022.A420
1601030022
|
£1.75
|
£2.10
|
|
|
36 - RUBBER BUSHING
BSD-1600502006.A109
1600502006
|
£1.75
|
£2.10
|
|
|
38 - MANUFACTURER'S NAMEPLATE
BSD-1601110003.A233
1601110003
|
-
|
|
|
|
40 - SPRING WASHER dia27.5x38.4 MM
BSD-1600150007.A34
1600150007
|
£1.75
|
£2.10
|
|
|
49 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A57
2910211021
|
£1.75
|
£2.10
|
|
|
50 - GROOVE BALL BEARING 6203-2 Z DIN 625
BSD-1900905227.A41
1900905227
|
£14.72
|
£17.67
|
|
|
51 - RETAINING RING dia22 MM
BSD-2916620011.A154
2916620011
|
£1.75
|
£2.10
|
|
|
52 - GROOVE BALL BEARING 15x35x11
BSD-1900905234.A169
1900905234
|
£31.64
|
£37.97
|
|
|
53 - GROOVE BALL BEARING
BSD-1600900029.A49
1600900029
|
-
|
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A269
2910021118
|
£1.75
|
£2.10
|
|
|
55 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A74
2910211006
|
£1.75
|
£2.10
|
|
|
55 - SOCKET HEAD CAP SCREW DIN 84-AM3x8-8.8
BSD-2910021050.A172
2910021050
|
£1.75
|
£2.10
|
|
|
56 - SPRING WASHER A 3 DIN 137-ST
BSD-2916060003.A16
2916060003
|
£1.32
|
£1.58
|
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-8.8
BSD-2910021157.A13
2910021157
|
£1.32
|
£1.58
|
|
|
58 - HEX NUT DIN 934 -M4-m-8
BSD-2915011005.A111
2915011005
|
£1.75
|
£2.10
|
|
|
59 - TAPPING SCREW B4.8x57.5 MM
BSD-1603429000.A41
1603429000
|
£1.75
|
£2.10
|
|
|
60 - SOCKET HEAD CAP SCREW DIN 84-AM5x16-8.8
BSD-2910021158.A76
2910021158
|
£1.32
|
£1.58
|
|
|
60/1 - TAPPING SCREW DIN 7971-ST4.8x25-F
BSD-2910211036.A20
2910211036
|
£1.75
|
£2.10
|
|
|
61 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-8.8
BSD-2910021162.A13
2910021162
|
-
|
|
|
|
62 - HEX NUT M12x1.5 MM
BSD-1603300009.A16
1603300009
|
£1.75
|
£2.10
|
|
|
63 - TAPPING SCREW B4.8x90 MM
BSD-1603435006.A164
1603435006
|
-
|
|
|
|
63/01 - SOCKET HEAD CAP SCREW DIN 84-BM5x82
BSD-1603410001.A151
1603410001
|
-
|
|
|
|
64 - SPRING LOCK WASHER DIN 127-B 5
BSD-2916680006.A97
2916680006
|
-
|
|
|
|
66 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A268
2910021118
|
£1.75
|
£2.10
|
|
|
78 - END SPLICE
BSD-3604477009.A52
3604477009
|
£2.61
|
£3.13
|
|
|
78 - END SPLICE A 4-9 DIN 46 228
BSD-1900452004.A13
1900452004
|
-
|
|
|
|
79 - SOCKET-TERMINAL STRIP 1x1.5 MM/2
BSD-1901091012.A2
1901091012
|
£5.30
|
£6.36
|
|
|
650 - AUXILIARY HANDLE M14
BSD-1602025022.A1465
1602025022
|
£13.41
|
£16.09
|
|
|
650 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A1316
1602025030
|
£18.96
|
£22.75
|
|
|
652/2 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x20-8.8
BSD-2910141242.A141
2910141242
|
£1.75
|
£2.10
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014103.A66
1607014103
|
£14.91
|
£17.89
|
|
|
801 - ASSEMBLY OF SERVICE PARTS
BSD-1605108902.A38
1605108902
|
-
|
|
|
|
803 - CONNECTING CABLE
BSD-1604440004.A75
1604440004
|
-
|
|
|
|
803/00/01 - TERMINAL LUG
BSD-1601353003.A22
1601353003
|
-
|
|
|
|
804 - CROWN GEAR Z=59
BSD-1606333144.A1
1606333144
|
-
|
|
|
|
805 - BEVEL GEAR Z=15
BSD-1606333145.A17
1606333145
|
-
|
|
|
|
809/00/04 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A143
2910091118
|
£1.75
|
£2.10
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3840
160111A3H3
|
£2.61
|
£3.13
|
|
