1 - POLE HOUSING
BSD-1605108049.A17
1605108049
|
-
|
|
|
|
2 - POLE SHOE 240V
BSD-1604220133.A0
1604220133
|
-
|
|
|
|
3 - SOCKET HEAD CAP SCREW
BSD-1603410008.A22
1603410008
|
-
|
|
|
|
6 - ARMATURE 240V
BSD-1604011074.A1
1604011074
|
-
|
|
|
|
11 - BEARING FLANGE
BSD-1605820174.A40
1605820174
|
-
|
|
|
|
12 - GROOVE BALL BEARING 6203-TH/C3 DIN 625
BSD-1900900413.A11
1900900413
|
-
|
|
|
|
14 - GROOVE BALL BEARING 12x28x8
BSD-1900905121.A126
1900905121
|
£18.96
|
£22.75
|
|
|
16 - GRINDING SPINDLE M14x1.5 MM
BSD-1603523032.A20
1603523032
|
£37.27
|
£44.72
|
|
|
16 - GRINDING SPINDLE 5/8-UNC-2A
BSD-1603523091.A53
1603523091
|
-
|
|
|
|
17 - BEARING FLANGE dia 14.8 MM
BSD-1605805044.A38
1605805044
|
-
|
|
|
|
18 - PLAIN WASHER
BSD-2100551000.A148
2100551000
|
-
|
|
|
|
19 - SHIM 0.10 MM
BSD-1601038020.A34
1601038020
|
-
|
|
|
|
19 - SHIM 0.20 MM
BSD-1601038021.A35
1601038021
|
-
|
|
|
|
20 - CONICAL SPRING WASHER
BSD-1600521013.A259
1600521013
|
-
|
|
|
|
21 - AIR-DEFLECTOR RING
BSD-1600502001.A63
1600502001
|
-
|
|
|
|
23 - SCREW PLUG
BSD-1603465003.A34
1603465003
|
-
|
|
|
|
26 - POWER SUPPLY CORD GB 110V 4.15m 2 x 1.5mm H07RN-F
BSD-1604460203.A82
1604460203
|
£33.74
|
£40.49
|
|
|
28 - FASTENING CLAMP
BSD-1601302013.A531
1601302013
|
£1.75
|
£2.10
|
|
|
29 - SEALING PLATE
BSD-1600113003.A362
1600113003
|
£2.80
|
£3.36
|
|
|
31 - GROMMET
BSD-1600306002.A38
1600306002
|
-
|
|
|
|
32 - SUPPRESSION CAPACITOR
BSD-1607329019.A40
1607329019
|
-
|
|
|
|
33 - FASTENING CLAMP
BSD-1601302003.A19
1601302003
|
-
|
|
|
|
34 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A91
2916011005
|
£1.75
|
£2.10
|
|
|
37 - SLEEVE TERMINAL
BSD-1600390006.A44
1600390006
|
-
|
|
|
|
43 - REFERENCE PLATE
BSD-1601110058.A150
1601110058
|
£1.75
|
£2.10
|
|
|
44 - SHIM
BSD-1600102674.A39
1600102674
|
-
|
|
|
|
45 - HOLDING BRACKET
BSD-1601331032.A136
1601331032
|
-
|
|
|
|
50 - GROOVE BALL BEARING 17x47x14
BSD-1900900352.A39
1900900352
|
£27.23
|
£32.68
|
|
|
51 - NEEDLE BEARING dia22x11.3 MM
BSD-1600910010.A267
1600910010
|
£45.67
|
£54.80
|
|
|
53 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A132
2910021122
|
£2.16
|
£2.59
|
|
|
55 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-5.8
BSD-2910011157.A372
2910011157
|
-
|
|
|
|
56 - SOCKET HEAD CAP SCREW DIN 84-AM5x25-5.8
BSD-2910011164.A26
2910011164
|
-
|
|
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM3x8-8.8
BSD-2910021050.A150
2910021050
|
£1.75
|
£2.10
|
|
|
57 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A111
2910211006
|
£1.75
|
£2.10
|
|
|
58 - SOCKET HEAD CAP SCREW DIN 84-AM4x20-8.8
BSD-2910021130.A41
2910021130
|
£1.75
|
£2.10
|
|
|
59 - PAN HEAD SCREW DIN 85-AM4x10-MS
BSD-2910110120.A397
2910110120
|
£1.75
|
£2.10
|
|
|
60 - SELF-CUTTING SCREW dia 3.9x13 MM
BSD-1603435000.A63
1603435000
|
-
|
|
|
|
62 - SPRING WASHER DIN 137-A4
BSD-1600150006.A723
1600150006
|
-
|
|
|
|
67 - PLAIN WASHER DIN 46 255-DPG 9
BSD-2916010409.A84
2916010409
|
-
|
|
|
|
70 - ROUND-HEAD GROOVED PIN DIN 1476-2x3-St
BSD-2917721031.A56
2917721031
|
£1.75
|
£2.10
|
|
|
74 - MANUFACTURER'S NAMEPLATE
BSD-1601110011.A34
1601110011
|
-
|
|
|
|
76 - FELT WASHER
BSD-1600205008.A291
1600205008
|
£1.75
|
£2.10
|
|
|
81 - SHIM 0.05 MM
BSD-1600101612.A13
1600101612
|
-
|
|
|
|
82 - SHIM 1.0 MM
BSD-1600101606.A17
1600101606
|
-
|
|
|
|
83 - SHIM
BSD-1600101608.A61
1600101608
|
-
|
|
|
|
95 - REFERENCE PLATE
BSD-1601110052.A14
1601110052
|
-
|
|
|
|
651 - OFFSET SCREWDRIVER DIN 911;SW6
BSD-1907950007.A331
1907950007
|
£5.30
|
£6.36
|
|
|
651 - SINGLE-HEAD ENG. WRENCH SW19
BSD-1907950511.A80
1907950511
|
£11.78
|
£14.13
|
|
|
652 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A295
2607950511
|
£4.26
|
£5.11
|
|
|
653 - AUXILIARY HANDLE M14
BSD-1602025022.A1503
1602025022
|
£13.41
|
£16.09
|
|
|
653 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A1278
1602025030
|
£18.96
|
£22.75
|
|
|
654 - OFFSET SCREWDRIVER DIN 911-4
BSD-2607950004.A501
2607950004
|
£1.75
|
£2.10
|
|
|
656 - CLAMPING-FLANGE dia45 MM
BSD-2600501006.A141
2600501006
|
£16.43
|
£19.72
|
|
|
657 - ROUND NUT M14
BSD-2603345004.A184
2603345004
|
£6.52
|
£7.83
|
|
|
800 - HANDLE
BSD-1605132060.A67
1605132060
|
-
|
|
|
|
802 - CONTROL LEVER
BSD-1602026030.A349
1602026030
|
£10.10
|
£12.12
|
|
|
803 - CARBON-BRUSH SET
BSD-1607014100.A43
1607014100
|
-
|
|
|
|
808 - MOTOR HOUSING
BSD-1605102041.A46
1605102041
|
-
|
|
|
|
811 - SEAL KIT
BSD-1607000040.A30
1607000040
|
-
|
|
|
|
815 - BEVEL GEAR Z=15
BSD-1606333093.A15
1606333093
|
-
|
|
|
|
816 - BEVEL GEAR Z=59
BSD-1606333066.A12
1606333066
|
-
|
|
|
|
835/020 - END SPLICE
BSD-3604477009.A60
3604477009
|
£2.61
|
£3.13
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3870
160111A3H3
|
£2.61
|
£3.13
|
|
