1 - MOTOR HOUSING
BSD-3605108088.A15
3605108088
|
-
|
|
|
|
2 - FIELD 220-230V
BSD-1604220122.A17
1604220122
|
-
|
|
|
|
3 - ARMATURE 220-230V
BSD-1604011236.A8
1604011236
|
-
|
|
|
|
4/00/04 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A514
2910091118
|
£1.84
|
£2.21
|
|
|
5 - POWER SUPPLY CORD
BSD-1604460080.A1
1604460080
|
-
|
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A1112
3600703011
|
£2.94
|
£3.53
|
|
|
6 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A464
1600703009
|
£5.87
|
£7.04
|
|
|
7 - FASTENING CLAMP
BSD-1601302013.A92
1601302013
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601110005.A20
1601110005
|
-
|
|
|
|
9 - POWER SUPPLY CORD EU 4.15m 2 x 1.5mm H07 RN-F
BSD-1607000228.A618
1607000228
|
£23.86
|
£28.63
|
|
|
11 - SUPPRESSION FILTER
BSD-1607328034.A463
1607328034
|
£4.48
|
£5.37
|
|
|
16 - BRUSH HOLDER
BSD-3604336012.A68
3604336012
|
£5.58
|
£6.70
|
|
|
18 - PROFILE STRIP 3.4x7x240 MM
BSD-1601014005.A212
1601014005
|
-
|
|
|
|
19 - CONTROL LEVER
BSD-1602026041.A124
1602026041
|
-
|
|
|
|
19/01 - FELT WASHER
BSD-1600205019.A178
1600205019
|
£1.75
|
£2.10
|
|
|
20 - BEARING COVER
BSD-1605808054.A68
1605808054
|
-
|
|
|
|
21 - COVER DISC
BSD-1600102012.A21
1600102012
|
-
|
|
|
|
23 - SEALING DISK
BSD-1600108055.A237
1600108055
|
£1.75
|
£2.10
|
|
|
27 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A741
2600910001
|
£4.48
|
£5.37
|
|
|
28 - RUBBER RING 7 MM
BSD-1600206020.A55
1600206020
|
£1.84
|
£2.21
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600502009.A42
1600502009
|
-
|
|
|
|
30 - SPRING RETAINING RING DIN 472 38X1.5MM
BSD-2916660017.A107
2916660017
|
£4.26
|
£5.11
|
|
|
31 - SPIRAL SPRING
BSD-1604652006.A195
1604652006
|
£1.84
|
£2.21
|
|
|
32 - ROTARY SHAFT LIP SEAL
BSD-1600290008.A223
1600290008
|
£2.61
|
£3.13
|
|
|
34 - SHIM 0.2 MM
BSD-1600190005.A129
1600190005
|
£1.38
|
£1.66
|
|
|
34 - SHIM 0.1 MM
BSD-1600190004.A154
1600190004
|
-
|
|
|
|
35 - TAB WASHER
BSD-1601030022.A297
1601030022
|
£1.84
|
£2.21
|
|
|
36 - RUBBER BUSHING
BSD-1600502006.A48
1600502006
|
£1.75
|
£2.10
|
|
|
40 - SPRING WASHER dia27.5x38.4 MM
BSD-1600150007.A115
1600150007
|
£1.84
|
£2.21
|
|
|
41 - SEALING CAP
BSD-1605500089.A190
1605500089
|
-
|
|
|
|
50 - GROOVE BALL BEARING 17x40x12
BSD-1900905281.A29
1900905281
|
£33.22
|
£39.87
|
|
|
51 - RETAINING RING dia22 MM
BSD-2916620011.A406
2916620011
|
£1.84
|
£2.21
|
|
|
52 - GROOVE BALL BEARING 15x35x11
BSD-1900905234.A44
1900905234
|
£33.22
|
£39.87
|
|
|
53 - GROOVE BALL BEARING 10x26x8
BSD-1900900407.A45
1900900407
|
-
|
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1218
2910021118
|
£1.84
|
£2.21
|
|
|
56 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A590
2916011005
|
£1.84
|
£2.21
|
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-5.8
BSD-2910011157.A107
2910011157
|
-
|
|
|
|
58 - HEX NUT DIN 934 -M4-m-8
BSD-2915011005.A647
2915011005
|
£1.84
|
£2.21
|
|
|
59 - SCREW B 4.8x45 MM
BSD-3603415560.A142
3603415560
|
£1.84
|
£2.21
|
|
|
60 - TAPPING SCREW DIN 7971-ST4.8x25-F
BSD-2910211036.A239
2910211036
|
£1.84
|
£2.21
|
|
|
61 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-5.8
BSD-2910011162.A146
2910011162
|
£1.84
|
£2.21
|
|
|
63 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A288
1613435009
|
£1.75
|
£2.10
|
|
|
66 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A536
2910021122
|
£2.27
|
£2.72
|
|
|
69 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A300
2910211011
|
£1.84
|
£2.21
|
|
|
76 - REFERENCE PLATE
BSD-3601119236.A975
3601119236
|
£3.91
|
£4.69
|
|
|
78 - END SPLICE
BSD-3604477009.A357
3604477009
|
£2.61
|
£3.13
|
|
|
650 - AUXILIARY HANDLE M14
BSD-1602025022.A274
1602025022
|
£13.41
|
£16.09
|
|
|
650 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A354
1602025030
|
£19.91
|
£23.89
|
|
|
651 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A864
2607950511
|
£4.48
|
£5.37
|
|
|
651 - SINGLE-HEAD ENG. WRENCH SW19
BSD-1907950511.A29
1907950511
|
£11.78
|
£14.13
|
|
|
652/00/02 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x20-8.8
BSD-2910141242.A69
2910141242
|
£1.84
|
£2.21
|
|
|
656 - PIN-TYPE FACE-WRENCH SW6-HL8-N6
BSD-1607950007.A43
1607950007
|
-
|
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014106.A17
1607014106
|
£19.91
|
£23.89
|
|
|
801 - CONNECTING CABLE
BSD-1604440004.A125
1604440004
|
-
|
|
|
|
803 - BEVEL GEAR Z=59
BSD-1606333160.A7
1606333160
|
-
|
|
|
|
804 - BEVEL GEAR Z=6
BSD-1606333161.A2
1606333161
|
-
|
|
|
|
810 - SEAL KIT
BSD-1607000111.A22
1607000111
|
-
|
|
|
