Bosch GSB 14.4 VE-2 / 0601952403 / EU 14.4 Volt Spare Parts

An exploded drawing and listing for the Bosch GSB 14.4 VE-2 / 0601952403 / EU 14.4 Volt

	Ex VAT	Inc VAT
1 - HOUSING SECTION BSD-2605105028.A2 2605105028	-
2/1 - PINION Z=19 BSD-2606316180.A2 2606316180	£2.61	£3.13
5 - ADJUSTING SLIDE BSD-2601099085.A71 2601099085	-
25 - KEYLESS CHUCK dia 2-13 MM.1/2 BSD-2608572088.A29 2608572088	£41.62	£49.95
32 - ADJUSTING SLIDE BSD-2601099086.A1 2601099086	£2.16	£2.59
50 - INTERMEDIATE FLANGE BSD-2605719901.A35 2605719901	-
91 - SLIDE-IN ACCU PACKAGE 14.4V. 2.6Ah. NiMH BSD-2607335685.A1 2607335685	£120.11	£144.13
93 - SCREWDRIVER BLADE BSD-2608521018.A30 2608521018	£5.01	£6.01
96 - SUPPORT BSD-2608040131.A77 2608040131	£1.95	£2.34
101 - TORX OVAL-HEAD SCREW 3x18 BSD-2603490018.A559 2603490018	£1.75	£2.10
107 - COUNTERSUNK-HEAD SCREW M6x23 BSD-2603421229.A339 2603421229	£1.75	£2.10
653 - FAST CHARGER EU 230/7.2-24V. 1h BSD-2607224425.A224 2607224425	£88.07	£105.68
653 - FAST CHARGER EU 230/7.2-14.4V. 30 MIN. BSD-2607224701.A326 2607224701	£88.07	£105.68
802 - DC MOTOR 14.4V BSD-2607022874.A0 2607022874	£80.61	£96.73
804 - ON-OFF SWITCH BSD-2607200421.A12 2607200421	£48.38	£58.06
809 - MANUFACTURER'S NAMEPLATE BSD-2601116142.A6 2601116142	£2.16	£2.59
820 - REFERENCE PLATE BSD-2601116143.A0 2601116143	£2.16	£2.59
845 - PLANETARY GEAR TRAIN BSD-2606200926.A13 2606200926	£80.61	£96.73
899 - CORDLESS IMPACT DRILL BSD-0601952420.A0 0601952420	-
