Bosch 400-WATT-SERIE / 0607988004 / --- Spare Parts

An exploded drawing and listing for the Bosch 400-WATT-SERIE / 0607988004 / ---

	Ex VAT	Inc VAT
1 - MOTOR HOUSING BSD-3605108059.A0 3605108059	£27.23	£32.68
2 - STATOR 400W BSD-3604090046.A29 3604090046	£98.11	£117.73
3 - ROTOR BSD-3604220047.A16 3604220047	£89.79	£107.75
5 - BEARING FLANGE BSD-3605700076.A41 3605700076	£46.37	£55.64
7 - GROOVE BALL BEARING 9x24x7 MM BSD-3600905039.A62 3600905039	£12.04	£14.45
8 - GROOVE BALL BEARING 7x17x5 BSD-1900905028.A208 1900905028	£33.74	£40.49
10 - O-RING 25x2 MM BSD-1900210124.A13 1900210124	£2.80	£3.36
11 - O-RING 20x2 MM BSD-1900210118.A21 1900210118	£2.80	£3.36
12 - REDUCTION SLEEVE BSD-3600421001.A1 3600421001	£8.67	£10.41
21 - O-RING 39.0x2.0 MM BSD-3600210022.A0 3600210022	£3.72	£4.47
22 - STOP DISC BSD-3600100022.A34 3600100022	£1.95	£2.34
23 - O-RING 33.0x2.0 MM BSD-2600210019.A1 2600210019	£1.66	£1.99
24 - GUIDE SLEEVE BSD-3600327001.A0 3600327001	£13.12	£15.75
31 - INTERMEDIATE RING BSD-3600200058.A15 3600200058	£21.52	£25.83
55 - TAPPING SCREW DIN 7971-ST3.9x22-F BSD-2910211021.A333 2910211021	£1.66	£1.99
58 - CONNECTION COVER BSD-3605500032.A35 3605500032	£8.67	£10.41
59 - FITTING BSD-3603462011.A19 3603462011	£14.91	£17.89
60 - FILTER SCREEN BSD-3600002004.A77 3600002004	£2.80	£3.36
61 - O-RING 6.0x2.0 MM BSD-3600210023.A43 3600210023	£3.72	£4.47
62 - COMPRESSION SPRING BSD-2604611025.A54 2604611025	£2.80	£3.36
63 - STRAIGHT PIN BSD-3604710054.A42 3604710054	£3.72	£4.47
64 - O-RING 5.94x3.53 MM BSD-3600210024.A0 3600210024	£1.95	£2.34
65 - O-RING 2.7x1.5 MM BSD-3600210025.A43 3600210025	£1.95	£2.34
66 - BALL DIN 5401-3 MM-III-ST BSD-1903230004.A312 1903230004	£1.66	£1.99
69 - COMPRESSION SPRING BSD-3604610024.A0 3604610024	£1.66	£1.99
70 - HEX SCREW BSD-3603450006.A1 3603450006	£5.30	£6.36
71 - O-RING 15x2 MM BSD-1900210112.A139 1900210112	£2.33	£2.80
76 - LEAF SPRING BSD-3604682002.A16 3604682002	£10.10	£12.12
77 - TOGGLE SWITCH BSD-3602033001.A42 3602033001	£3.72	£4.47
95 - NAMEPLATE BSD-160111A3HF.A444 160111A3HF	£3.72	£4.47
96 - MANUFACTURER'S NAMEPLATE BSD-1601110481.A529 1601110481	£1.95	£2.34
97 - STICKER BSD-2601110055.A19 2601110055	£4.26	£5.11
99 - REFERENCE PLATE BSD-3601119236.A888 3601119236	£3.72	£4.47
101 - GEAR HOUSING BSD-3605808008.A8 3605808008	£81.81	£98.17
112 - SHIM 0.5 MM BSD-2600101616.A90 2600101616	-
113 - NEEDLE-ROLLER CAGE BSD-2600913036.A35 2600913036	£1.66	£1.99
114 - NEEDLE ROLLER 1.5x5.8 MM BSD-2603201037.A0 2603201037	£1.66	£1.99
115 - ECCENTRIC COG WHEEL BSD-1619P02581.A200 1619P02581	£21.68	£26.01
116 - SHIM 1.0 MM BSD-2600102653.A56 2600102653	£1.66	£1.99
117 - SHIM 0.3 MM BSD-2600100515.A99 2600100515	£1.66	£1.99
117 - SHIM 0.5 MM BSD-2600100516.A126 2600100516	£1.95	£2.34
118 - FORK LEVER BSD-2601923004.A153 2601923004	£2.80	£3.36
119 - LOCKING WASHER DIN 6799-4-FSt BSD-2916080007.A650 2916080007	£1.95	£2.34
120 - SHIM 0.5 MM BSD-2600102652.A172 2600102652	£1.66	£1.99
121 - SHIM 0.1 MM BSD-2600100625.A45 2600100625	-
121 - SHIM 0.2 MM BSD-2600100626.A193 2600100626	-
121 - SHIM 0.3 MM BSD-2600100627.A50 2600100627	-
121 - SHIM 0.5 MM BSD-2600100628.A253 2600100628	£1.66	£1.99
122 - COUNTERWEIGHT BSD-2601098003.A198 2601098003	£8.67	£10.41
123 - SPACER SLEEVE BSD-2600309009.A157 2600309009	£1.66	£1.99
124 - ECCENTRIC DISC BSD-2601072901.A158 2601072901	£7.36	£8.83
125 - SHIM 0.2 MM BSD-2600100575.A68 2600100575	£1.95	£2.34
125 - SHIM 0.3 MM BSD-2600100576.A249 2600100576	-
125 - SHIM 0.5 MM BSD-2600100577.A68 2600100577	£1.66	£1.99
126 - LOCKING WASHER DIN 6799-7-FSt BSD-2916080910.A122 2916080910	£1.66	£1.99
127 - MICROENCAPSULATED SCREW DIN 7985-M4x12MM BSD-2914551176.A2 2914551176	£1.66	£1.99
127 - MICROENCAPSULATED SCREW DIN 7985-M4x12MM BSD-2914551176.A3 2914551176	£1.66	£1.99
129 - SHIM 0.5 MM BSD-2600100568.A129 2600100568	£1.66	£1.99
129 - SHIM 1.0 MM BSD-2600100569.A145 2600100569	£1.66	£1.99
129 - SHIM 0.3 MM BSD-2600100607.A518 2600100607	£1.66	£1.99
130 - NEEDLE-ROLLER BEARING dia6 MM BSD-2600914010.A155 2600914010	£2.80	£3.36
131 - BEARING SLEEVE BSD-2600400012.A54 2600400012	£4.26	£5.11
134 - RATCHET CAP BSD-2600590006.A579 2600590006	£1.66	£1.99
135 - ROTARY KNOB BSD-2602026036.A31 2602026036	-
136 - LOCKING WASHER 5 DIN 6799 BSD-2916080908.A1 2916080908	£1.66	£1.99
139 - SEAL BSD-2601015050.A125 2601015050	£1.95	£2.34
160 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST BSD-2912401020.A9 2912401020	£1.66	£1.99
161 - SEALING CAP BSD-3605500035.A16 3605500035	£5.30	£6.36
162 - HEX NUT DIN 934-M6-8-A BSD-2915011007.A365 2915011007	-
163 - BASE PLATE BSD-2601016903.A26 2601016903	£16.41	£19.69
164 - PROFILE BEADING BSD-2601030019.A66 2601030019	£2.33	£2.80
165 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x16-8.8 BSD-2910141197.A421 2910141197	£1.66	£1.99
166 - OFFSET SCREWDRIVER DIN 911-SW5 BSD-1907950006.A862 1907950006	£4.26	£5.11
168 - FLANGED ELBOW FITTING BSD-3605703057.A7 3605703057	£12.04	£14.45
171 - COMPRESSION SPRING BSD-2604617003.A1 2604617003	-
172 - THREAD-FORMING TAP. SCREW M 5x16 BSD-2603410054.A114 2603410054	£2.33	£2.80
174 - THREAD-FORMING TAP. SCREW M4x12 MM BSD-2603410049.A324 2603410049	£1.66	£1.99
175 - MODIFICATION SET 100-240V BSD-2606491917.A23 2606491917	£21.52	£25.83
176 - SCALE PLATE BSD-2601328044.A33 2601328044	£2.33	£2.80
178 - STICKER BSD-2601110930.A34 2601110930	£1.32	£1.58
182 - STICKER BSD-2601110764.A44 2601110764	-
201 - SAFETY DEVICE BSD-2601322021.A115 2601322021	£4.26	£5.11
203 - THREAD-FORMING TAP. SCREW M4x12 MM BSD-2603410049.A323 2603410049	£1.66	£1.99
341 - THREAD-FORMING TAP. SCREW M4x8 BSD-2603410048.A121 2603410048	£1.66	£1.99
342 - COMPRESSION SPRING BSD-2604613000.A54 2604613000	£1.66	£1.99
343 - GUIDE BRACKET BSD-2601322010.A75 2601322010	£3.80	£4.56
344 - LIFTING ROD BSD-1619P12765.A101 1619P12765	£16.41	£19.69
345 - CLAMPING SADDLE BSD-2602329011.A1 2602329011	£4.75	£5.70
346 - SLIDING PIECE BSD-1619P12767.A142 1619P12767	£5.88	£7.05
347 - COUNTERSUNK-HEAD SCREW DIN 7962-M3.5x8-10.9 BSD-2603421040.A272 2603421040	£1.66	£1.99
348 - SUPPORTING DISC 0.5 MM BSD-2600112031.A231 2600112031	£1.66	£1.99
349 - SEAL RING 0.5 MM BSD-2600290017.A175 2600290017	£1.66	£1.99
350 - SHIM 0.5 MM BSD-2600101612.A250 2600101612	£1.66	£1.99
353 - MODIFICATION SET 100-240V BSD-2606491917.A24 2606491917	£21.52	£25.83
354 - ROLLER LEVER BSD-2601321046.A7 2601321046	£7.78	£9.33
355 - GUIDE ROLLER BSD-2600326019.A0 2600326019	£5.58	£6.70
356 - BEARING BOLT BSD-2603105089.A20 2603105089	£1.66	£1.99
357 - LOCKING WASHER BSD-2600116011.A42 2600116011	£1.95	£2.34
358 - STRAIGHT PIN DIN 6325-4M6x24 BSD-2917530101.A64 2917530101	£2.80	£3.36
359 - LOCKING WASHER DIN 6799-3.2 BSD-2916080906.A14 2916080906	£1.66	£1.99
364 - NEEDLE ROLLER DIN 5402-A3x11.8-G2 BSD-1903201042.A276 1903201042	£1.95	£2.34
371 - SINTERED-METAL BUSHING BSD-2600301046.A184 2600301046	£3.72	£4.47
372 - BUSHING BSD-2600301045.A43 2600301045	£2.80	£3.36
377 - SHIM 0.2 MM BSD-2600100032.A11 2600100032	£1.66	£1.99
650 - SAW BLADE SET BSD-2607010403.A7 2607010403	£7.78	£9.33
651 - OFFSET SCREWDRIVER DIN 911-SW5 BSD-1907950006.A863 1907950006	£4.26	£5.11
752 - HOSE FITTING BSD-3603386068.A17 3603386068	£21.52	£25.83
753 - SILENCER BSD-3607000073.A16 3607000073	£18.96	£22.75
802 - ROTOR BSD-3607030124.A8 3607030124	£293.32	£351.98
804 - ROTOR LAMELLA BSD-3607030030.A54 3607030030	£31.64	£37.97
810 - PISTON ASSEMBLY GROUP BSD-3607030494.A41 3607030494	£18.96	£22.75
840 - GEAR COVER BSD-2605808920.A43 2605808920	£70.24	£84.29
854 - ROLLER LEVER BSD-2601321902.A134 2601321902	-
855 - ROLLER SET BSD-1619P01375.A61 1619P01375	£11.30	£13.56
863 - BASE PLATE BSD-3607030131.A17 3607030131	£23.86	£28.63
869 - HANDLE BSD-2602026900.A0 2602026900	-
