1 - MOTOR HOUSING
BSD-3609201096.A0
3609201096
|
£72.18
|
£86.62
|
|
|
2 - VALVE BUSHING
BSD-3609201097.A1
3609201097
|
£18.96
|
£22.75
|
|
|
4 - CONTROL LEVER
BSD-3609201099.A0
3609201099
|
£6.52
|
£7.83
|
|
|
5 - SLOTTED SPRING PIN
BSD-3609201100.A1
3609201100
|
£4.26
|
£5.11
|
|
|
6 - O-RING
BSD-3609201101.A0
3609201101
|
£4.26
|
£5.11
|
|
|
7 - PRESSURE PIN
BSD-3609201102.A1
3609201102
|
£3.72
|
£4.47
|
|
|
9 - COMPRESSION SPRING
BSD-3609201103.A0
3609201103
|
£4.26
|
£5.11
|
|
|
10 - FITTING
BSD-3609201104.A1
3609201104
|
£11.30
|
£13.56
|
|
|
11 - CONTROL PISTON
BSD-3609201105.A0
3609201105
|
£21.52
|
£25.83
|
|
|
12 - O-RING
BSD-3609201106.A1
3609201106
|
£4.26
|
£5.11
|
|
|
13 - SCREW PLUG
BSD-3609201107.A0
3609201107
|
£2.80
|
£3.36
|
|
|
14 - RETAINING SNAP RING
BSD-3609201108.A1
3609201108
|
£4.26
|
£5.11
|
|
|
16 - PRESSURE DISK
BSD-3609201110.A0
3609201110
|
£7.36
|
£8.83
|
|
|
17 - BUSHING
BSD-3609201111.A1
3609201111
|
£10.10
|
£12.12
|
|
|
18 - STRIKER SPINDLE
BSD-3609201112.A0
3609201112
|
-
|
|
|
|
19 - STRIKER HOLDER
BSD-3609201113.A1
3609201113
|
£70.24
|
£84.29
|
|
|
20 - STRIKER PIN
BSD-3609201114.A0
3609201114
|
£23.86
|
£28.63
|
|
|
21 - GUIDE SLEEVE
BSD-3609201115.A1
3609201115
|
£12.04
|
£14.45
|
|
|
22 - CARRIER
BSD-3609201116.A0
3609201116
|
£45.67
|
£54.80
|
|
|
23 - O-RING
BSD-3609201117.A1
3609201117
|
£4.26
|
£5.11
|
|
|
24 - STATOR
BSD-3609201118.A0
3609201118
|
£46.37
|
£55.64
|
|
|
25 - ROTOR
BSD-3609201119.A1
3609201119
|
£63.50
|
£76.20
|
|
|
27 - BEARING FLANGE
BSD-3609201121.A0
3609201121
|
£18.96
|
£22.75
|
|
|
28 - GROOVE BALL BEARING 12x28x8
BSD-3609201122.A1
3609201122
|
£37.27
|
£44.72
|
|
|
29 - BEARING FLANGE
BSD-3609201123.A0
3609201123
|
£12.04
|
£14.45
|
|
|
30 - RADIAL SEAL
BSD-3609201124.A1
3609201124
|
£3.72
|
£4.47
|
|
|
31 - COMPRESSION SPRING
BSD-3609201125.A0
3609201125
|
£4.26
|
£5.11
|
|
|
32 - DETENT PIN
BSD-3609201126.A1
3609201126
|
£4.26
|
£5.11
|
|
|
33 - SEALING PLATE
BSD-3609201127.A0
3609201127
|
£11.30
|
£13.56
|
|
|
34 - HOUSING COVER
BSD-3609201128.A1
3609201128
|
£14.91
|
£17.89
|
|
|
37 - SPRING LOCK WASHER
BSD-3609201131.A0
3609201131
|
-
|
|
|
|
38 - HEX SOCKET HEAD CAP SCREW
BSD-3609201132.A1
3609201132
|
£10.10
|
£12.12
|
|
|
39 - AIR ELIMINATOR
BSD-3609201133.A0
3609201133
|
£2.80
|
£3.36
|
|
|
40 - GROOVE BALL BEARING
BSD-3609201134.A1
3609201134
|
£27.23
|
£32.68
|
|
|
41 - RADIAL SEAL
BSD-3609201135.A0
3609201135
|
£8.67
|
£10.41
|
|
|
42 - RAISED CTSK TAPPING SCREW
BSD-3609201136.A1
3609201136
|
£2.80
|
£3.36
|
|
|
43 - SCREW PLUG
BSD-3609201137.A0
3609201137
|
£2.80
|
£3.36
|
|
|
44 - PROTECTIVE RING
BSD-3609201138.A1
3609201138
|
£5.30
|
£6.36
|
|
|
45 - PROTECTIVE CAP
BSD-3609201139.A0
3609201139
|
£5.30
|
£6.36
|
|
|
46 - COMPRESSION SPRING
BSD-3609201140.A1
3609201140
|
£4.26
|
£5.11
|
|
|
47 - BALL
BSD-3609201423.A1
3609201423
|
£5.30
|
£6.36
|
|
|
48 - SEAL
BSD-3609201142.A0
3609201142
|
£4.26
|
£5.11
|
|
|
49 - VALVE BODY
BSD-3609201143.A1
3609201143
|
£13.12
|
£15.75
|
|
|
50 - VALVE PISTON
BSD-3609201144.A0
3609201144
|
£4.26
|
£5.11
|
|
|
51 - PIN
BSD-3609201145.A1
3609201145
|
£4.26
|
£5.11
|
|
|
52 - SET SCREW
BSD-3609201146.A0
3609201146
|
£2.80
|
£3.36
|
|
|
54 - O-RING
BSD-3609201147.A1
3609201147
|
£5.58
|
£6.70
|
|
|
95 - NAMEPLATE
BSD-3609201149.A0
3609201149
|
£2.80
|
£3.36
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A337
3601119236
|
£3.72
|
£4.47
|
|
|
650 - HOSE FITTING
BSD-3609201095.A4
3609201095
|
£5.58
|
£6.70
|
|
|
800 - SERVICE KIT
BSD-3609201150.A1
3609201150
|
-
|
|
|
|
801 - SERVICE KIT
BSD-3609201151.A0
3609201151
|
£208.91
|
£250.69
|
|
|
802 - SERVICE KIT
BSD-3609201152.A1
3609201152
|
£129.38
|
£155.25
|
|
|
803 - SERVICE KIT
BSD-3609201153.A0
3609201153
|
£72.18
|
£86.62
|
|
|
804 - SERVICE KIT
BSD-3609201154.A1
3609201154
|
£40.80
|
£48.96
|
|
|
805 - SERVICE KIT
BSD-3609201155.A0
3609201155
|
£23.86
|
£28.63
|
|
|
806 - SERVICE KIT
BSD-3609201179.A1
3609201179
|
£98.11
|
£117.73
|
|
|
807 - SERVICE KIT
BSD-3609201180.A0
3609201180
|
£46.37
|
£55.64
|
|
|
808 - SERVICE KIT
BSD-3609201181.A1
3609201181
|
£12.04
|
£14.45
|
|
|
809 - SERVICE KIT
BSD-3609202656.A0
3609202656
|
£13.12
|
£15.75
|
|
|
810 - SERVICE KIT
BSD-3609202670.A0
3609202670
|
£12.04
|
£14.45
|
|
|
811 - SERVICE KIT
BSD-3609202671.A1
3609202671
|
£16.41
|
£19.69
|
|
