1 - MOTOR HOUSING
BSD-3600760011.A14
3600760011
|
£66.68
|
£80.01
|
|
|
2 - STATOR 120W
BSD-3604090014.A0
3604090014
|
£85.90
|
£103.08
|
|
|
3 - ROTOR
BSD-3604220013.A7
3604220013
|
£102.57
|
£123.08
|
|
|
5 - BEARING FLANGE
BSD-3605700023.A7
3605700023
|
£23.86
|
£28.63
|
|
|
6 - BALL BEARING 7x19x6
BSD-2600905032.A1276
2600905032
|
£5.57
|
£6.68
|
|
|
7 - BEARING FLANGE
BSD-3605700021.A3
3605700021
|
£62.51
|
£75.01
|
|
|
8 - GROOVE BALL BEARING 7x14x5
BSD-1900905030.A28
1900905030
|
£33.74
|
£40.49
|
|
|
11 - PLAIN WASHER DIN 433-5.3-ST
BSD-2916011011.A228
2916011011
|
£1.75
|
£2.10
|
|
|
12 - HEX SCREW DIN 933-M5x8-8.8
BSD-2911061150.A208
2911061150
|
£2.74
|
£3.29
|
|
|
26 - PINION Z=15
BSD-3606300018.A13
3606300018
|
£28.68
|
£34.41
|
|
|
27 - STOP DISC
BSD-3600101008.A76
3600101008
|
£1.75
|
£2.10
|
|
|
28 - RING GEAR Z=42
BSD-3606334011.A34
3606334011
|
£66.68
|
£80.01
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337057.A7
3606337057
|
£50.80
|
£60.96
|
|
|
31 - CYLINDRICAL GEAR Z=13
BSD-3606316010.A45
3606316010
|
-
|
|
|
|
32 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A435
3600913000
|
£4.26
|
£5.11
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A28
3603201000
|
£1.84
|
£2.21
|
|
|
34 - STOP DISC
BSD-3600103003.A12
3600103003
|
£2.80
|
£3.36
|
|
|
35 - RETAINING RING
BSD-3600224002.A24
3600224002
|
£1.84
|
£2.21
|
|
|
36 - GROOVE BALL BEARING 12x21x5
BSD-3600905002.A129
3600905002
|
£16.41
|
£19.69
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337035.A0
3606337035
|
£135.25
|
£162.30
|
|
|
39 - CYLINDRICAL GEAR
BSD-3606316114.A27
3606316114
|
£13.78
|
£16.54
|
|
|
41 - GROOVE BALL BEARING 10x22x6
BSD-3600905003.A1
3600905003
|
-
|
|
|
|
43 - SPRING RETAINING RING
BSD-3600119001.A13
3600119001
|
-
|
|
|
|
44 - THREADED BUSHING
BSD-3600390003.A80
3600390003
|
£12.64
|
£15.17
|
|
|
45 - RADIAL SEAL
BSD-3600283003.A1
3600283003
|
-
|
|
|
|
46 - THREADED RING
BSD-3603344005.A2
3603344005
|
£14.91
|
£17.89
|
|
|
56 - CONNECTION HOUSING
BSD-3605190040.A2
3605190040
|
-
|
|
|
|
66 - STRAIGHT PIN
BSD-3603201001.A43
3603201001
|
£4.26
|
£5.11
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A195
160111A3HF
|
£3.91
|
£4.69
|
|
|
97 - GROOVED NAIL
BSD-3603133000.A41
3603133000
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1814
3601119236
|
£3.91
|
£4.69
|
|
|
700 - HOSE FITTING
BSD-3603386002.A30
3603386002
|
£3.34
|
£4.01
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031058.A1
3607031058
|
£321.98
|
£386.38
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030259.A23
3607030259
|
£33.22
|
£39.87
|
|
