4 - SWITCH
BSD-1607200116.A39
1607200116
|
-
|
|
|
|
5 - POWER SUPPLY CORD GB 240V 10.2m 2 x 1.0mm H05 VV-F
BSD-1604460184.A4
1604460184
|
£33.73
|
£40.48
|
|
|
6 - GROMMET dia7.2-dia9.5x81 MM
BSD-1600703026.A18
1600703026
|
£2.16
|
£2.59
|
|
|
7 - CABLE CLIP
BSD-2601035001.A160
2601035001
|
£1.75
|
£2.10
|
|
|
8 - NAMEPLATE
BSD-1601118432.A0
1601118432
|
-
|
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601118434.A0
1601118434
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A570
1607328028
|
£5.30
|
£6.36
|
|
|
22 - SLOTTED SPRING PIN 3x16 DIN 1481
BSD-2917760079.A18
2917760079
|
-
|
|
|
|
23 - PUSHER
BSD-1601099025.A4
1601099025
|
-
|
|
|
|
25 - SEALING CAP
BSD-1605500191.A4
1605500191
|
£2.52
|
£3.02
|
|
|
26 - PLASTIC NUT M6
BSD-1603349020.A0
1603349020
|
-
|
|
|
|
29 - OVAL-HEAD SCREW 4x18 MM.TORX T20
BSD-2914201506.A109
2914201506
|
£1.75
|
£2.10
|
|
|
30 - CUTTER PLATE
BSD-1608635042.A4
1608635042
|
-
|
|
|
|
40 - RELEASE LEVER
BSD-1601990003.A0
1601990003
|
-
|
|
|
|
41 - COMPRESSION SPRING
BSD-1604610017.A6
1604610017
|
-
|
|
|
|
55 - HANDLE COVER
BSD-1605133043.A2
1605133043
|
-
|
|
|
|
58 - GUIDE SLEEVE
BSD-1600499008.A4
1600499008
|
-
|
|
|
|
59 - STOP PLATE
BSD-1602388032.A6
1602388032
|
-
|
|
|
|
60 - SPRING SLEEVE
BSD-1600499009.A6
1600499009
|
-
|
|
|
|
61 - COMPRESSION SPRING
BSD-1604615013.A0
1604615013
|
-
|
|
|
|
62 - GUIDE BRACKET
BSD-1604690011.A2
1604690011
|
-
|
|
|
|
63 - SPACER
BSD-1604690013.A4
1604690013
|
-
|
|
|
|
64 - SUPPORT CLAMP
BSD-1608640080.A2
1608640080
|
-
|
|
|
|
720 - CUTTING LINE CARTRIDGE
BSD-1608190020.A4
1608190020
|
-
|
|
|
|
750 - GUIDE BLOCK
BSD-1608190023.A2
1608190023
|
-
|
|
|
|
801 - MOTOR HOUSING
BSD-1607000325.A4
1607000325
|
-
|
|
|
|
815 - FAN
BSD-1606610139.A3
1606610139
|
-
|
|
|
|
821 - PROTECTIVE COVER
BSD-1605510247.A3
1605510247
|
£27.31
|
£32.77
|
|
|
842 - CATCH DISK
BSD-1600190033.A6
1600190033
|
-
|
|
|
|
848 - RUBBER PLATE
BSD-1601006009.A2
1601006009
|
-
|
|
|
|
852 - GUIDE TUBE
BSD-1607000868.A2
1607000868
|
-
|
|
|
|
853 - ROUND-HEAD BOLT
BSD-1607000255.A10
1607000255
|
-
|
|
|
