1/17 - DRIVE SHAFT
BSD-F016L65108.A28
F016L65108
|
£13.78
|
£16.54
|
|
|
1/21 - DRIVE BELT
BSD-F016L65109.A73
F016L65109
|
£17.22
|
£20.67
|
|
|
32 - SELF-CUTTING SCREW
BSD-F016L37433.A104
F016L37433
|
£1.75
|
£2.10
|
|
|
40 - MOWER DECK
BSD-F016L66159.A11
F016L66159
|
£37.27
|
£44.72
|
|
|
41/01/02 - BEARING 6003
BSD-F016L64387.A28
F016L64387
|
£5.57
|
£6.68
|
|
|
42 - COVER PANEL
BSD-F016L66041.A15
F016L66041
|
-
|
|
|
|
43 - MOTOR HOOD
BSD-F016L65159.A55
F016L65159
|
£30.28
|
£36.33
|
|
|
52/01 - AXLE
BSD-F016L66467.A17
F016L66467
|
£5.26
|
£6.31
|
|
|
52/02 - LEVER
BSD-F016L90582.A47
F016L90582
|
-
|
|
|
|
52/03 - SPACER
BSD-F016L90583.A145
F016L90583
|
£2.45
|
£2.94
|
|
|
55 - CUTTER BLADE
BSD-F016L65924.A7
F016L65924
|
£35.42
|
£42.51
|
|
|
59 - SCREW AND WASHER ASSEMBLY
BSD-F016104350.A26
F016104350
|
£2.05
|
£2.46
|
|
|
61/01 - AXLE
BSD-F016L66466.A12
F016L66466
|
£6.16
|
£7.39
|
|
|
61/02 - LEVER
BSD-F016L90581.A145
F016L90581
|
£8.17
|
£9.80
|
|
|
61/03 - SPACER
BSD-F016L90585.A47
F016L90585
|
£1.75
|
£2.10
|
|
|
64 - RATCHET CAP 9 MM
BSD-F016F05700.A105
F016F05700
|
£1.95
|
£2.34
|
|
|
75/2/1 - SWITCH HOUSING
BSD-F016L67217.A92
F016L67217
|
£5.87
|
£7.04
|
|
|
75/2/5 - CABLE GUIDE
BSD-F016104213.A4
F016104213
|
£9.11
|
£10.93
|
|
|
75/4/1 - PUSH-BUTTON
BSD-F016L67150.A48
F016L67150
|
£2.19
|
£2.63
|
|
|
75/4/2 - BUTTON SPRING
BSD-F016L67151.A93
F016L67151
|
£1.75
|
£2.10
|
|
|
75/4/9 - SELF-CUTTING SCREW 4x19 MM
BSD-F016T49429.A299
F016T49429
|
£1.84
|
£2.21
|
|
|
80 - COLLECTOR BOX BOTTOM L/H
BSD-F016L64304.A41
F016L64304
|
£22.76
|
£27.31
|
|
|
81 - COLLECTOR BOX BOTTOM R/H
BSD-F016L64338.A41
F016L64338
|
£17.22
|
£20.67
|
|
|
82 - GUARD FLAP
BSD-F016L66137.A45
F016L66137
|
£13.32
|
£15.99
|
|
|
83/84 - HANDLE
BSD-F016L66441.A135
F016L66441
|
£4.99
|
£5.99
|
|
|
85 - SPRING
BSD-F016L66165.A141
F016L66165
|
£2.97
|
£3.56
|
|
|
99 - SPRING
BSD-F016L59327.A121
F016L59327
|
£2.94
|
£3.53
|
|
|
100 - SPRING
BSD-F016L65790.A87
F016L65790
|
£2.05
|
£2.46
|
|
|
101 - LINK PIECE
BSD-F016L65971.A35
F016L65971
|
-
|
|
|
|
106 - WIRE GUIDE
BSD-F016L90579.A6
F016L90579
|
£35.12
|
£42.15
|
|
|
107 - FILTER HOUSING
BSD-F016L65539.A11
F016L65539
|
£11.87
|
£14.24
|
|
|
108 - BEARING COVER
BSD-F016L67627.A8
F016L67627
|
£2.71
|
£3.25
|
|
|
110 - FILTER HOUSING
BSD-F016L65709.A56
F016L65709
|
£5.87
|
£7.04
|
|
|
452 - COMPANY LOGO ROTAK 43
BSD-F016L67544.A0
F016L67544
|
£2.33
|
£2.80
|
|
|
501 - PLAIN WASHER dia8.15
BSD-F016T48185.A73
F016T48185
|
£3.91
|
£4.69
|
|
|
504 - SELF-CUTTING SCREW 4x19 MM
BSD-F016T49429.A298
F016T49429
|
£1.84
|
£2.21
|
|
|
505 - SCREW M5x8 Csk Hd.
BSD-F016L36542.A82
F016L36542
|
£2.62
|
£3.14
|
|
|
681 - STRAIN-RELIEF CLAMP
BSD-3601398000.A69
3601398000
|
£5.57
|
£6.68
|
|
|
801 - MOTOR
BSD-F016103596.A5
F016103596
|
£140.87
|
£169.04
|
|
|
801/1/20 - BEARING
BSD-F016L64594.A50
F016L64594
|
£3.94
|
£4.73
|
|
|
841 - HOUSING
BSD-F016103600.A0
F016103600
|
-
|
|
|
|
841/1 - COVER
BSD-F016104318.A0
F016104318
|
£6.16
|
£7.39
|
|
|
850 - WHEEL
BSD-F016103992.A84
F016103992
|
-
|
|
|
|
860 - WHEEL
BSD-F016103994.A4
F016103994
|
-
|
|
|
|
875/1 - HANDLE
BSD-F016L67133.A25
F016L67133
|
£9.97
|
£11.96
|
|
|
875/2/2 - CONNECTING CABLE EU
BSD-F016104214.A36
F016104214
|
£8.92
|
£10.70
|
|
|
875/2/3 - CONNECTING CABLE
BSD-F016104164.A34
F016104164
|
£12.37
|
£14.84
|
|
|
875/2/4 - SWITCH KIT
BSD-F016104162.A35
F016104162
|
£13.12
|
£15.75
|
|
|
875/4/3 - HOUSING SET
BSD-F016104159.A61
F016104159
|
£22.60
|
£27.12
|
|
|
875/4/4 - SWITCH SEGMENT
BSD-F016104160.A71
F016104160
|
£11.37
|
£13.64
|
|
|
875/50 - SLEEVE
BSD-F016104161.A60
F016104161
|
£5.58
|
£6.70
|
|
|
878 - BOTTOM HANDLE
BSD-F016L67209.A3
F016L67209
|
-
|
|
|
|
879 - BOTTOM HANDLE
BSD-F016L67210.A37
F016L67210
|
-
|
|
|
|
883 - COVER
BSD-F016103608.A50
F016103608
|
£28.59
|
£34.31
|
|
|
893 - THERMAL PROTECTOR
BSD-F016103605.A5
F016103605
|
£12.64
|
£15.17
|
|
|
894 - CLAMPING LEVER
BSD-F016L67530.A44
F016L67530
|
£11.87
|
£14.24
|
|
|
895 - CABLE CLIP
BSD-F016L66895.A84
F016L66895
|
£1.84
|
£2.21
|
|
