40/3 - COMB
BSD-F016L66697.A10
F016L66697
|
£1.75
|
£2.10
|
|
|
41 - SUPPORT ELEMENT
BSD-F016L67976.A11
F016L67976
|
£1.75
|
£2.10
|
|
|
45 - CARRYING HANDLE
BSD-F016L66654.A28
F016L66654
|
£2.80
|
£3.36
|
|
|
52/1 - AXLE
BSD-F016L68031.A5
F016L68031
|
£2.80
|
£3.36
|
|
|
52/2 - LEVER
BSD-F016L68050.A11
F016L68050
|
£6.52
|
£7.83
|
|
|
55 - CUTTER BLADE 320 MM
BSD-F016L64191.A34
F016L64191
|
£14.75
|
£17.70
|
|
|
59 - HEX SCREW M8x20 MM
BSD-F016T48547.A33
F016T48547
|
£2.61
|
£3.13
|
|
|
61/1 - AXLE
BSD-F016L68029.A11
F016L68029
|
£2.61
|
£3.13
|
|
|
61/2 - LEVER
BSD-F016L68012.A5
F016L68012
|
£2.80
|
£3.36
|
|
|
61/3 - SPRING
BSD-F016L68027.A5
F016L68027
|
£2.61
|
£3.13
|
|
|
75/1 - HANDLE
BSD-F016L90608.A33
F016L90608
|
£16.41
|
£19.69
|
|
|
75/3/802 - CONNECTING CABLE EU
BSD-F016104214.A17
F016104214
|
£8.49
|
£10.19
|
|
|
75/3/803 - CONNECTING CABLE
BSD-F016104164.A45
F016104164
|
£11.78
|
£14.13
|
|
|
75/3/804 - SWITCH KIT
BSD-F016104162.A24
F016104162
|
£13.12
|
£15.75
|
|
|
75/3/805 - CABLE GUIDE
BSD-F016104213.A70
F016104213
|
£8.67
|
£10.41
|
|
|
75/4/1 - PUSH-BUTTON
BSD-F016L67150.A19
F016L67150
|
£2.08
|
£2.50
|
|
|
75/4/2 - BUTTON SPRING
BSD-F016L67151.A122
F016L67151
|
£1.75
|
£2.10
|
|
|
75/4/803 - HOUSING SET
BSD-F016104159.A6
F016104159
|
£21.52
|
£25.83
|
|
|
75/4/804 - SWITCH SEGMENT
BSD-F016104160.A135
F016104160
|
£10.82
|
£12.99
|
|
|
75/14 - SELF-CUTTING SCREW 4x19 MM
BSD-F016T49429.A643
F016T49429
|
£1.75
|
£2.10
|
|
|
75/805 - SLEEVE
BSD-F016104161.A6
F016104161
|
£5.58
|
£6.70
|
|
|
78 - BOTTOM HANDLE
BSD-F016L66682.A4
F016L66682
|
£8.67
|
£10.41
|
|
|
79 - BOTTOM HANDLE
BSD-F016L66655.A4
F016L66655
|
£8.67
|
£10.41
|
|
|
80 - COLLECTOR BOX BOTTOM
BSD-F016L66683.A28
F016L66683
|
£14.91
|
£17.89
|
|
|
82 - GUARD FLAP
BSD-F016L66686.A28
F016L66686
|
£4.26
|
£5.11
|
|
|
84 - CARRYING HANDLE
BSD-F016L66685.A4
F016L66685
|
£3.49
|
£4.19
|
|
|
85 - CLOSING SPRING
BSD-F016L66687.A4
F016L66687
|
£1.75
|
£2.10
|
|
|
90 - LINKAGE PART
BSD-F016L68025.A10
F016L68025
|
£7.36
|
£8.83
|
|
|
92 - DRIVE BELT
BSD-F016L66677.A20
F016L66677
|
£11.78
|
£14.13
|
|
|
93 - THERMAL PROTECTOR
BSD-F016L66958.A2
F016L66958
|
£8.67
|
£10.41
|
|
|
96 - BELT TENSIONER
BSD-F016L68711.A9
F016L68711
|
£6.25
|
£7.50
|
|
|
97 - CLIP
BSD-F016L68014.A11
F016L68014
|
£1.75
|
£2.10
|
|
|
98 - BAFFLE
BSD-F016L66688.A20
F016L66688
|
£5.30
|
£6.36
|
|
|
99 - BALANCE WEIGHTS
BSD-F016L68420.A6
F016L68420
|
£13.12
|
£15.75
|
|
|
100 - INSERT
BSD-F016L68007.A11
F016L68007
|
£2.49
|
£2.99
|
|
|
101 - INSERT
BSD-F016L68008.A5
F016L68008
|
£1.75
|
£2.10
|
|
|
102 - INSERT
BSD-F016L68009.A11
F016L68009
|
£1.75
|
£2.10
|
|
|
103 - INSERT
BSD-F016L68010.A5
F016L68010
|
£1.75
|
£2.10
|
|
|
104 - INSERT
BSD-F016L68011.A11
F016L68011
|
£1.75
|
£2.10
|
|
|
108 - BEARING COVER
BSD-F016L66689.A3
F016L66689
|
£1.75
|
£2.10
|
|
|
452 - COMPANY LOGO Rotak 32 Ergoflex H
BSD-F016L68425.A0
F016L68425
|
£2.61
|
£3.13
|
|
|
501 - PLAIN WASHER dia8.15 MM
BSD-F016T40590.A19
F016T40590
|
£1.75
|
£2.10
|
|
|
503 - SECURING CAP dia8 MM
BSD-F016T48990.A61
F016T48990
|
£1.75
|
£2.10
|
|
|
504 - SELF-CUTTING SCREW 4x19 MM
BSD-F016T49429.A642
F016T49429
|
£1.75
|
£2.10
|
|
|
506 - SPACER dia8.15 MM
BSD-F016L68015.A5
F016L68015
|
£1.75
|
£2.10
|
|
|
801 - MOTOR
BSD-F016104035.A22
F016104035
|
£93.88
|
£112.65
|
|
|
801/1/18 - CAP
BSD-F016L64499.A23
F016L64499
|
£1.75
|
£2.10
|
|
|
805 - SCREW M5x8 Csk Hd.
BSD-F016L36542.A45
F016L36542
|
£1.63
|
£1.96
|
|
|
840 - MOWER DECK
BSD-F016104246.A16
F016104246
|
£31.64
|
£37.97
|
|
|
840/1/2 - BEARING 6002-2RS
BSD-F016L67442.A50
F016L67442
|
£4.22
|
£5.06
|
|
|
843 - MOTOR HOOD
BSD-F016104033.A2
F016104033
|
£21.52
|
£25.83
|
|
|
876 - CLAMPING LEVER
BSD-F016L67530.A13
F016L67530
|
£11.30
|
£13.56
|
|
|
883 - COLLECTOR BOX TOP
BSD-F016104032.A32
F016104032
|
£21.68
|
£26.01
|
|
|
887 - WHEEL
BSD-F016104220.A8
F016104220
|
£11.30
|
£13.56
|
|
|
891 - DRIVE SHAFT
BSD-F016104155.A18
F016104155
|
£14.91
|
£17.89
|
|
|
895 - CABLE CLIP
BSD-F016L66895.A39
F016L66895
|
£1.75
|
£2.10
|
|
