2/1 - PIVOT PLATE
BSD-2609003822.A5
2609003822
|
£37.27
|
£44.72
|
|
|
2/2 - BEARING
BSD-2609003823.A4
2609003823
|
£7.36
|
£8.83
|
|
|
2/3 - SCREW
BSD-2609003824.A5
2609003824
|
£1.75
|
£2.10
|
|
|
2/4 - SPRING WASHER
BSD-2609003825.A13
2609003825
|
£1.75
|
£2.10
|
|
|
2/8 - CONNECTING PLATE
BSD-2609003828.A13
2609003828
|
£12.04
|
£14.45
|
|
|
2/9 - PLATE
BSD-2609003829.A5
2609003829
|
£6.52
|
£7.83
|
|
|
2/10 - SCREW
BSD-2609003830.A13
2609003830
|
£1.75
|
£2.10
|
|
|
2/11 - CUTTING HEAD
BSD-2609003831.A5
2609003831
|
£63.50
|
£76.20
|
|
|
2/13 - SPRING RETAINING RING
BSD-2609004198.A1
2609004198
|
£1.75
|
£2.10
|
|
|
2/14 - HOUSING
BSD-2609003833.A6
2609003833
|
£81.81
|
£98.17
|
|
|
2/15 - INSERT
BSD-2609003834.A12
2609003834
|
£5.58
|
£6.70
|
|
|
2/17 - FLANGED BEARING
BSD-2609003836.A6
2609003836
|
£14.91
|
£17.89
|
|
|
2/19 - SEAL RING
BSD-2609003838.A12
2609003838
|
£1.75
|
£2.10
|
|
|
2/22 - POROUS BEARING
BSD-2609003841.A6
2609003841
|
£1.75
|
£2.10
|
|
|
2/23 - PLANET GEAR
BSD-2609003842.A12
2609003842
|
£23.86
|
£28.63
|
|
|
2/24 - WASHER
BSD-2609003843.A6
2609003843
|
£2.61
|
£3.13
|
|
|
2/25 - DRIVE PLATE
BSD-2609003844.A6
2609003844
|
£1.95
|
£2.34
|
|
|
2/26 - BOLT
BSD-2609003845.A2
2609003845
|
£1.75
|
£2.10
|
|
|
2/27 - PLANETARY-GEAR CARRIER
BSD-2609003846.A6
2609003846
|
£12.04
|
£14.45
|
|
|
2/28 - PINION
BSD-2609003847.A2
2609003847
|
£8.67
|
£10.41
|
|
|
2/29 - NEEDLE-ROLLER BEARING
BSD-2609003848.A6
2609003848
|
£2.16
|
£2.59
|
|
|
2/30 - PLANET GEAR
BSD-2609003849.A2
2609003849
|
£14.91
|
£17.89
|
|
|
2/31 - SPRING RETAINING RING
BSD-2609003850.A6
2609003850
|
£1.75
|
£2.10
|
|
|
2/36 - FAN
BSD-2609003854.A12
2609003854
|
£8.67
|
£10.41
|
|
|
2/37 - SPRING RETAINING RING
BSD-2609003855.A6
2609003855
|
£1.75
|
£2.10
|
|
|
2/38 - CLAMPING PIECE
BSD-2609002792.A4
2609002792
|
-
|
|
|
|
2/39 - MOTOR CAPACITOR
BSD-2609007667.A9
2609007667
|
£21.68
|
£26.01
|
|
|
2/40 - PLATE
BSD-2609004396.A8
2609004396
|
£7.36
|
£8.83
|
|
|
5 - APPLIANCE INLET SET EU
BSD-2609003149.A2
2609003149
|
£31.64
|
£37.97
|
|
|
5/2 - SWITCH
BSD-2609003145.A17
2609003145
|
£7.36
|
£8.83
|
|
|
5/3 - SWITCH ROCKER
BSD-2609003517.A16
2609003517
|
£7.36
|
£8.83
|
|
|
9 - MANUFACTURER'S NAMEPLATE AXT 25 D
BSD-2609003151.A2
2609003151
|
£2.80
|
£3.36
|
|
|
21 - TORX OVAL-HEAD SCREW 4x25
BSD-2603490024.A1003
2603490024
|
£1.75
|
£2.10
|
|
|
22 - HOUSING
BSD-2609002554.A4
2609002554
|
£36.63
|
£43.96
|
|
|
23 - UPPER HOUSING
BSD-2609002555.A4
2609002555
|
£14.75
|
£17.70
|
|
|
24 - REAR HOUSING SECTION
BSD-2609004513.A1
2609004513
|
£21.52
|
£25.83
|
|
|
25 - FLAP
BSD-2609002557.A4
2609002557
|
-
|
|
|
|
26 - SPRING
BSD-2609003144.A2
2609003144
|
£1.75
|
£2.10
|
|
|
27 - BOLT
BSD-2609002795.A10
2609002795
|
£2.16
|
£2.59
|
|
|
29 - BOLT
BSD-2609002791.A4
2609002791
|
£7.78
|
£9.33
|
|
|
31 - SPRING RETAINING RING DIN 471-8x0.8 FSt
BSD-2916640005.A86
2916640005
|
£1.75
|
£2.10
|
|
|
32 - KNOB
BSD-2609004515.A1
2609004515
|
£2.16
|
£2.59
|
|
|
35 - KNOB
BSD-2609002804.A4
2609002804
|
-
|
|
|
|
36 - TERMINAL LUG
BSD-2609002805.A4
2609002805
|
-
|
|
|
|
37 - BOLT
BSD-2609002806.A4
2609002806
|
£1.75
|
£2.10
|
|
|
38 - ADJUSTING SCREW
BSD-2609003539.A3
2609003539
|
£7.78
|
£9.33
|
|
|
39 - RING
BSD-2609002754.A0
2609002754
|
-
|
|
|
|
40 - HOLDER
BSD-2609003140.A7
2609003140
|
£3.34
|
£4.01
|
|
|
41 - CAP
BSD-2609003399.A10
2609003399
|
£1.75
|
£2.10
|
|
|
42 - CAP
BSD-2609003400.A8
2609003400
|
£1.75
|
£2.10
|
|
|
43 - CAP
BSD-2609003401.A10
2609003401
|
£1.75
|
£2.10
|
|
|
44 - RUBBER PAD
BSD-2609002755.A17
2609002755
|
£12.04
|
£14.45
|
|
|
45 - COVER PLATE
BSD-2609002683.A4
2609002683
|
£4.75
|
£5.70
|
|
|
46 - OVAL-HEAD SCREW M4x8
BSD-2603413035.A29
2603413035
|
£1.75
|
£2.10
|
|
|
47 - SOCKET HOUSING
BSD-2609004519.A9
2609004519
|
£3.72
|
£4.47
|
|
|
48 - RELAY
BSD-2609005130.A1
2609005130
|
£12.04
|
£14.45
|
|
|
49 - REED SWITCH
BSD-2609003540.A10
2609003540
|
£21.52
|
£25.83
|
|
|
50 - ROCKER ROD
BSD-2609004603.A9
2609004603
|
£2.61
|
£3.13
|
|
|
51 - BOLT
BSD-2609002846.A8
2609002846
|
£5.30
|
£6.36
|
|
|
52 - SPRING
BSD-2609002847.A10
2609002847
|
£1.75
|
£2.10
|
|
|
53 - SLOTTED SPRING PIN
BSD-2609002793.A8
2609002793
|
£1.75
|
£2.10
|
|
|
55 - SUPPORTING FRAME
BSD-2609004244.A1
2609004244
|
£102.57
|
£123.08
|
|
|
56 - HOLDING PIN
BSD-2609003267.A10
2609003267
|
£5.30
|
£6.36
|
|
|
57 - HOLDING PIN
BSD-2609003268.A8
2609003268
|
£5.58
|
£6.70
|
|
|
58 - NUT
BSD-2609003551.A16
2609003551
|
£1.75
|
£2.10
|
|
|
59 - WHEEL
BSD-2609002790.A1
2609002790
|
£7.78
|
£9.33
|
|
|
60 - TORX OVAL-HEAD SCREW 4x40
BSD-2603490027.A41
2603490027
|
£1.75
|
£2.10
|
|
|
61 - PLAIN WASHER DIN 9021-B 4.3-ST
BSD-2916011892.A55
2916011892
|
£1.75
|
£2.10
|
|
|
62 - RETAINING PIN
BSD-F016L64669.A31
F016L64669
|
£1.75
|
£2.10
|
|
|
63 - THREAD-FORMING TAP. SCREW 4.8x22
BSD-2609003552.A2
2609003552
|
£1.75
|
£2.10
|
|
|
65 - CATCHER CONTAINER
BSD-2609006904.A9
2609006904
|
£40.80
|
£48.96
|
|
|
66 - PUSHER
BSD-2609002752.A18
2609002752
|
£6.52
|
£7.83
|
|
|
68 - HANDLE
BSD-2609002560.A2
2609002560
|
£16.74
|
£20.09
|
|
|
69 - COMPANY LOGO AXT 25 D
BSD-2609002685.A0
2609002685
|
£6.52
|
£7.83
|
|
|
70 - HOPPER
BSD-2609002561.A2
2609002561
|
-
|
|
|
|
71 - CHUTE
BSD-2609002564.A4
2609002564
|
-
|
|
|
|
72 - MAGNET
BSD-2609002799.A8
2609002799
|
£4.26
|
£5.11
|
|
|
76 - TOOTHED LOCK WASHER DIN 6797-A4.3-FST
BSD-2916030006.A31
2916030006
|
£1.75
|
£2.10
|
|
|
77 - COMPRESSION SPRING
BSD-2609003683.A10
2609003683
|
£1.75
|
£2.10
|
|
|
80 - WASHER DIN 9021-6.4x18x1.6
BSD-2610386712.A26
2610386712
|
£2.61
|
£3.13
|
|
|
802 - MOTOR
BSD-2609004911.A7
2609004911
|
-
|
|
|
|
804 - ELECTRONIC ASSEMBLY
BSD-1600A00H67.A12
1600A00H67
|
£81.81
|
£98.17
|
|
|
805 - GUIDE-PLATE
BSD-2609004912.A0
2609004912
|
£31.64
|
£37.97
|
|
|
807 - SCREW
BSD-2609003827.A8
2609003827
|
£1.75
|
£2.10
|
|
|
808 - NAMEPLATE
BSD-2609003520.A0
2609003520
|
£2.33
|
£2.80
|
|
|
816 - SPLIT PIN
BSD-2609004989.A2
2609004989
|
£2.16
|
£2.59
|
|
|
820 - SHAFT
BSD-2609006273.A9
2609006273
|
£37.27
|
£44.72
|
|
