1/01 - HANDLE
BSD-F016102487.A3
F016102487
|
-
|
|
|
|
1/02 - SCREW 5x30 MM
BSD-F016102523.A2
F016102523
|
-
|
|
|
|
1/03 - PIPE
BSD-F016102705.A2
F016102705
|
-
|
|
|
|
1/04 - COVER
BSD-F016102475.A2
F016102475
|
-
|
|
|
|
1/05 - INSERT
BSD-F016102485.A4
F016102485
|
-
|
|
|
|
1/06 - WHEEL
BSD-F016102706.A2
F016102706
|
-
|
|
|
|
1/07 - SLEEVE
BSD-F016102486.A0
F016102486
|
-
|
|
|
|
1/08 - SCREW 4.2x22 MM
BSD-F016102401.A9
F016102401
|
-
|
|
|
|
1/09 - WHEEL
BSD-F016102706.A3
F016102706
|
-
|
|
|
|
1/10 - INSERT
BSD-F016102489.A0
F016102489
|
-
|
|
|
|
1/11 - COVER
BSD-F016102497.A2
F016102497
|
-
|
|
|
|
2/01 - PLUG
BSD-F016102427.A7
F016102427
|
-
|
|
|
|
2/02 - DELIVERY VALVE
BSD-F016102428.A0
F016102428
|
-
|
|
|
|
2/03 - PLUG
BSD-F016102429.A7
F016102429
|
-
|
|
|
|
2/04 - O-RING 70.0x2.5 MM
BSD-F016102511.A3
F016102511
|
-
|
|
|
|
2/05 - BUSHING
BSD-F016102430.A0
F016102430
|
£2.52
|
£3.02
|
|
|
2/06 - VALVE
BSD-F016102431.A7
F016102431
|
-
|
|
|
|
2/07 - WASHER
BSD-F016102483.A3
F016102483
|
-
|
|
|
|
2/08 - GROOVED RING
BSD-F016102407.A11
F016102407
|
-
|
|
|
|
2/09 - CYLINDER HEAD
BSD-F016102432.A0
F016102432
|
-
|
|
|
|
2/10 - SOCKET HEAD CAP SCREW M8x50 MM
BSD-F016102443.A2
F016102443
|
-
|
|
|
|
3/03 - NON-RETURN VALVE
BSD-F016102421.A7
F016102421
|
-
|
|
|
|
3/04 - GUIDE PIECE
BSD-F016102422.A0
F016102422
|
-
|
|
|
|
3/05 - COMPRESSION SPRING
BSD-F016102423.A7
F016102423
|
£5.01
|
£6.01
|
|
|
3/06 - PISTON
BSD-F016102424.A0
F016102424
|
-
|
|
|
|
3/08 - GROOVED RING
BSD-F016102425.A11
F016102425
|
-
|
|
|
|
3/09 - VALVE SEAT
BSD-F016102707.A2
F016102707
|
-
|
|
|
|
3/10 - BYPASS VALVE
BSD-F016102454.A5
F016102454
|
-
|
|
|
|
3/11 - HOUSING
BSD-F016102455.A5
F016102455
|
-
|
|
|
|
3/12 - STRAINER
BSD-F016102411.A14
F016102411
|
-
|
|
|
|
3/14 - CLUTCH
BSD-F016102436.A3
F016102436
|
-
|
|
|
|
3/15 - THREADED CONNECTION 3/4
BSD-F016102409.A0
F016102409
|
-
|
|
|
|
3/17 - CLIP 17.12x2.62 MM
BSD-F016102441.A5
F016102441
|
-
|
|
|
|
3/18 - O-RING 17.12x2.62 MM
BSD-F016102403.A7
F016102403
|
-
|
|
|
|
3/19 - O-RING 10.78x2.62 MM
BSD-F016102414.A0
F016102414
|
-
|
|
|
|
4/01 - MOTOR
BSD-F016102648.A2
F016102648
|
-
|
|
|
|
4/02 - SCREW 48x45 MM
BSD-F016102434.A1
F016102434
|
-
|
|
|
|
4/03 - FAN WHEEL
BSD-F016102433.A6
F016102433
|
-
|
|
|
|
4/04 - PLATE
BSD-F016102645.A5
F016102645
|
-
|
|
|
|
4/05 - BALL BEARING 17x47x14 MM
BSD-F016102527.A3
F016102527
|
-
|
|
|
|
4/06 - SOCKET HEAD CAP SCREW M6x20-Z9
BSD-F016102402.A0
F016102402
|
-
|
|
|
|
4/07 - SELF-CUTTING SCREW M4x10 MM
BSD-F016102400.A1
F016102400
|
-
|
|
|
|
4/09 - FAN HOUSING
BSD-F016102437.A4
F016102437
|
-
|
|
|
|
4/10 - FAT OIL 50 ML
BSD-F016102438.A2
F016102438
|
-
|
|
|
|
4/14 - END SHIELD
BSD-F016102439.A9
F016102439
|
-
|
|
|
|
4/13 - BALL BEARING 6202-2RS
BSD-F016102446.A3
F016102446
|
-
|
|
|
|
4/15 - SHAFT SEAL 22x35x5MM
BSD-F016102440.A2
F016102440
|
-
|
|
|
|
5 - SPRAY GUN
BSD-1609350449.A0
1609350449
|
-
|
|
|
|
5/01 - SPECIAL SCREW
BSD-1609350480.A13
1609350480
|
-
|
|
|
|
5/02 - HANDLE COVER
BSD-1609350481.A2
1609350481
|
-
|
|
|
|
5/03 - COMPRESSION SPRING
BSD-1609350482.A13
1609350482
|
-
|
|
|
|
5/04 - PARTS SET
BSD-1609350483.A2
1609350483
|
-
|
|
|
|
5/05 - PUSH-BUTTON
BSD-1609350484.A13
1609350484
|
-
|
|
|
|
5/06 - MOLDED PART
BSD-1609350485.A2
1609350485
|
-
|
|
|
|
5/07 - MOLDED PART
BSD-1609350486.A13
1609350486
|
-
|
|
|
|
6/01 - HOSE
BSD-F016102514.A9
F016102514
|
-
|
|
|
|
6/02 - O-RING 8.9x2.7 MM
BSD-1609350487.A2
1609350487
|
-
|
|
|
|
6/03 - EXTENSION TUBE
BSD-1609350451.A15
1609350451
|
-
|
|
|
|
6/04 - PARTS SET
BSD-1609350491.A13
1609350491
|
-
|
|
|
|
6/05 - O-RING 9.25x1.78 MM
BSD-1609203577.A55
1609203577
|
-
|
|
|
|
6/07 - JET PIPE
BSD-F016102473.A3
F016102473
|
-
|
|
|
|
6/08 - SPRAY TUBE
BSD-F016102668.A10
F016102668
|
-
|
|
|
|
6/09 - CONTAINER
BSD-1609350492.A3
1609350492
|
-
|
|
|
|
6/10 - NOZZLE
BSD-F016102474.A19
F016102474
|
-
|
|
|
|
7/01 - HOUSING
BSD-F016102455.A4
F016102455
|
-
|
|
|
|
7/02 - CONDENSER
BSD-F016102642.A2
F016102642
|
-
|
|
|
|
7/03 - CELLULAR-RUBBER BAND
BSD-F016102415.A7
F016102415
|
-
|
|
|
|
7/05 - SCREW
BSD-F016102416.A0
F016102416
|
-
|
|
|
|
7/06 - O-RING 32.99x2.62 MM
BSD-F016102426.A0
F016102426
|
-
|
|
|
|
7/07 - PROTECTIVE COVER
BSD-F016102417.A6
F016102417
|
-
|
|
|
|
7/08 - SWITCH
BSD-F016102418.A1
F016102418
|
-
|
|
|
|
7/09 - SUPPORT
BSD-F016102419.A6
F016102419
|
-
|
|
|
|
7/10 - STRAIN-RELIEF CLAMP
BSD-F016102420.A1
F016102420
|
-
|
|
|
|
7/11 - POWER SUPPLY CORD
BSD-F016102689.A0
F016102689
|
-
|
|
|
|
7/12 - BUSHING
BSD-F016102507.A8
F016102507
|
-
|
|
|
|
8 - PRESSURE SWITCH
BSD-F016102456.A5
F016102456
|
-
|
|
|
|
8/01 - SWITCH
BSD-F016102519.A4
F016102519
|
-
|
|
|
|
8/04 - O-RING 17.17x1.78 MM
BSD-F016102405.A1
F016102405
|
-
|
|
|
|
8/05 - CLIP
BSD-F016102499.A3
F016102499
|
-
|
|
|
|
9 - HANDLE
BSD-F016102666.A13
F016102666
|
-
|
|
|
|
10/01 - HOSE
BSD-F016102667.A1
F016102667
|
-
|
|
|
|
10/02 - O-RING
BSD-F016102530.A6
F016102530
|
-
|
|
|
|
11 - JET PIPE
BSD-F016102473.A2
F016102473
|
-
|
|
|
|
11/01 - O-RING 9.25x1.78 MM
BSD-1609203577.A56
1609203577
|
-
|
|
|
|
12 - NOZZLE
BSD-F016102795.A4
F016102795
|
-
|
|
|
|
12/01 - O-RING 9.25x1.78 MM
BSD-1609203577.A57
1609203577
|
-
|
|
|
|
13 - NOZZLE
BSD-F016102474.A20
F016102474
|
-
|
|
|
|
13/01 - CONTAINER
BSD-1609350492.A4
1609350492
|
-
|
|
|
|
13/02 - O-RING 9.25x1.78 MM
BSD-1609203577.A58
1609203577
|
-
|
|
|
