32 - SCREW
BSD-F016L66162.A35
F016L66162
|
£1.66
|
£1.99
|
|
|
39/16 - CABLE CLIP
BSD-F016L66895.A34
F016L66895
|
£1.66
|
£1.99
|
|
|
39/17 - SCREW
BSD-F016L36542.A450
F016L36542
|
£2.33
|
£2.80
|
|
|
39/20 - CLAMPING LEVER
BSD-F016L67530.A17
F016L67530
|
£11.30
|
£13.56
|
|
|
40 - MOWER DECK
BSD-F016L68051.A1
F016L68051
|
£33.74
|
£40.49
|
|
|
40/2 - COMB
BSD-F016L66697.A18
F016L66697
|
£1.66
|
£1.99
|
|
|
43 - MOTOR HOOD
BSD-F016L68000.A3
F016L68000
|
£40.80
|
£48.96
|
|
|
43/1 - MOTOR HOOD
BSD-F016L68001.A4
F016L68001
|
£16.41
|
£19.69
|
|
|
43/2 - COVER
BSD-F016L68002.A3
F016L68002
|
£1.66
|
£1.99
|
|
|
43/3 - KEY
BSD-F016L68003.A5
F016L68003
|
£2.49
|
£2.99
|
|
|
43/4 - RELEASE LEVER
BSD-F016L68004.A40
F016L68004
|
£1.95
|
£2.34
|
|
|
43/5 - SPRING
BSD-F016L66108.A34
F016L66108
|
£1.66
|
£1.99
|
|
|
43/6 - WIRING HARNESS
BSD-F016104654.A8
F016104654
|
-
|
|
|
|
43/7 - CABLE ROUTING
BSD-F016L68017.A5
F016L68017
|
£1.66
|
£1.99
|
|
|
43/8 - SELF-CUTTING SCREW 4x19 MM
BSD-F016T49429.A636
F016T49429
|
£1.66
|
£1.99
|
|
|
43/9 - SWITCH
BSD-F016104250.A8
F016104250
|
£8.67
|
£10.41
|
|
|
44 - GRILLE
BSD-F016L68075.A0
F016L68075
|
£5.30
|
£6.36
|
|
|
45 - CARRYING HANDLE
BSD-F016L66654.A25
F016L66654
|
£2.80
|
£3.36
|
|
|
46 - BATTERY COVER
BSD-F016L68006.A3
F016L68006
|
£6.52
|
£7.83
|
|
|
52/1 - AXLE
BSD-F016L68031.A8
F016L68031
|
£2.80
|
£3.36
|
|
|
52/2 - LEVER
BSD-F016L68050.A7
F016L68050
|
£6.52
|
£7.83
|
|
|
55 - CUTTER BLADE
BSD-1600A025F8.A8
1600A025F8
|
£16.74
|
£20.09
|
|
|
58 - ADAPTOR PLATE
BSD-F016L68024.A0
F016L68024
|
£5.30
|
£6.36
|
|
|
59 - HEX SCREW M8x20 MM
BSD-F016T48547.A29
F016T48547
|
£2.33
|
£2.80
|
|
|
61/1 - AXLE
BSD-F016L68029.A8
F016L68029
|
£2.33
|
£2.80
|
|
|
61/2 - LEVER
BSD-F016L68012.A11
F016L68012
|
£2.80
|
£3.36
|
|
|
61/3 - SPRING
BSD-F016L68027.A8
F016L68027
|
£2.33
|
£2.80
|
|
|
75/1 - HANDLE
BSD-F016L90608.A96
F016L90608
|
£16.41
|
£19.69
|
|
|
75/2 - CONNECTING CABLE
BSD-F016104165.A3
F016104165
|
£13.41
|
£16.09
|
|
|
75/3/1 - CONNECTOR HOUSING
BSD-F016L67218.A23
F016L67218
|
£5.30
|
£6.36
|
|
|
75/4/1 - PUSH-BUTTON
BSD-F016L67150.A22
F016L67150
|
£2.08
|
£2.50
|
|
|
75/4/2 - BUTTON SPRING
BSD-F016L67151.A119
F016L67151
|
£1.66
|
£1.99
|
|
|
75/6 - HOUSING SET
BSD-F016104159.A12
F016104159
|
£21.52
|
£25.83
|
|
|
75/7 - SWITCH SEGMENT
BSD-F016104160.A129
F016104160
|
£10.82
|
£12.99
|
|
|
75/8 - SWITCH KIT
BSD-F016104163.A1
F016104163
|
£14.91
|
£17.89
|
|
|
75/9 - SLEEVE
BSD-F016104161.A11
F016104161
|
£5.58
|
£6.70
|
|
|
75/10 - CABLE GUIDE
BSD-F016104213.A66
F016104213
|
£8.67
|
£10.41
|
|
|
75/14 - SELF-CUTTING SCREW 4x19 MM
BSD-F016T49429.A630
F016T49429
|
£1.66
|
£1.99
|
|
|
78 - BOTTOM HANDLE
BSD-F016L66682.A5
F016L66682
|
£8.67
|
£10.41
|
|
|
79 - BOTTOM HANDLE
BSD-F016L66655.A9
F016L66655
|
£8.67
|
£10.41
|
|
|
80 - COLLECTOR BOX BOTTOM
BSD-F016L66683.A27
F016L66683
|
£14.91
|
£17.89
|
|
|
82 - GUARD FLAP
BSD-F016L66686.A27
F016L66686
|
£4.26
|
£5.11
|
|
|
84 - CARRYING HANDLE
BSD-F016L66685.A5
F016L66685
|
£3.49
|
£4.19
|
|
|
85 - CLOSING SPRING
BSD-F016L66687.A5
F016L66687
|
£1.66
|
£1.99
|
|
|
90 - LINKAGE PART
BSD-F016L68025.A7
F016L68025
|
£7.36
|
£8.83
|
|
|
91 - INSERT
BSD-F016L68007.A6
F016L68007
|
£2.49
|
£2.99
|
|
|
92 - INSERT
BSD-F016L68008.A10
F016L68008
|
£1.66
|
£1.99
|
|
|
93 - INSERT
BSD-F016L68009.A6
F016L68009
|
£1.66
|
£1.99
|
|
|
94 - INSERT
BSD-F016L68010.A10
F016L68010
|
£1.66
|
£1.99
|
|
|
95 - INSERT
BSD-F016L68011.A6
F016L68011
|
£1.66
|
£1.99
|
|
|
96 - GRILLE
BSD-F016L68018.A3
F016L68018
|
£1.66
|
£1.99
|
|
|
97 - CLIP
BSD-F016L68014.A5
F016L68014
|
£1.66
|
£1.99
|
|
|
99 - BALANCE WEIGHTS
BSD-F016L68034.A0
F016L68034
|
£8.67
|
£10.41
|
|
|
150/1 - ROLLER
BSD-F016L66853.A5
F016L66853
|
-
|
|
|
|
150/2 - ROLLER CARRIER L/H
BSD-F016L68019.A0
F016L68019
|
£1.95
|
£2.34
|
|
|
150/3 - ROLLER CARRIER R/H
BSD-F016L68020.A5
F016L68020
|
£1.95
|
£2.34
|
|
|
150/4 - SPINDLE
BSD-F016L66854.A5
F016L66854
|
£5.58
|
£6.70
|
|
|
150/5 - SPRING
BSD-F016L68033.A3
F016L68033
|
£1.66
|
£1.99
|
|
|
150/6 - SECURING CAP dia8 MM
BSD-F016T48990.A66
F016T48990
|
£1.66
|
£1.99
|
|
|
452 - COMPANY LOGO Rotak 32 LI
BSD-F016L68022.A0
F016L68022
|
£2.80
|
£3.36
|
|
|
501 - PLAIN WASHER dia8.15 MM
BSD-F016T40590.A27
F016T40590
|
£1.66
|
£1.99
|
|
|
502 - SPACER dia8.15 MM
BSD-F016L68015.A11
F016L68015
|
£1.66
|
£1.99
|
|
|
503 - SECURING CAP dia8 MM
BSD-F016T48990.A65
F016T48990
|
£1.66
|
£1.99
|
|
|
504 - SELF-CUTTING SCREW 4x19 MM
BSD-F016T49429.A631
F016T49429
|
£1.66
|
£1.99
|
|
|
650 - BATTERY PACK 36V. 1.3Ah. LI
BSD-2607336631.A1
2607336631
|
£134.16
|
£160.99
|
|
|
651 - CHARGER GB 230/10.8-36V
BSD-2607226275.A12
2607226275
|
£57.05
|
£68.46
|
|
|
801 - DC MOTOR
BSD-F016104219.A3
F016104219
|
£186.77
|
£224.12
|
|
|
801/1/18 - CAP
BSD-F016L64499.A28
F016L64499
|
£1.66
|
£1.99
|
|
|
802 - PRINTED-BOARD ASSEMBLY
BSD-F016104596.A1
F016104596
|
£89.79
|
£107.75
|
|
|
883 - COLLECTOR BOX TOP
BSD-F016104032.A25
F016104032
|
£21.68
|
£26.01
|
|
|
887 - WHEEL
BSD-F016104220.A5
F016104220
|
£11.30
|
£13.56
|
|
