1/1 - CHASSIS Bottom
BSD-F016L68948.A0
F016L68948
|
£37.27
|
£44.72
|
|
|
1/3 - COVER
BSD-F016L68949.A3
F016L68949
|
£27.23
|
£32.68
|
|
|
1/4 - COMPRESSION SPRING
BSD-F016L68899.A5
F016L68899
|
£2.16
|
£2.59
|
|
|
1/6 - WIRE HARNESS ASSEMBLY
BSD-F016L69221.A2
F016L69221
|
£14.22
|
£17.07
|
|
|
1/9 - SEAL HOUSING RING
BSD-F016L68966.A5
F016L68966
|
£1.75
|
£2.10
|
|
|
1/12 - PIVOTING BLADE GUARD
BSD-F016L68813.A0
F016L68813
|
-
|
|
|
|
1/23 - MOTOR HOUSING
BSD-F016L68952.A0
F016L68952
|
£7.36
|
£8.83
|
|
|
1/25 - CONTROL MAGNET
BSD-F016L69389.A3
F016L69389
|
£2.80
|
£3.36
|
|
|
1/28 - SCREW M4x20 PLASTIC
BSD-F016L67706.A59
F016L67706
|
£1.75
|
£2.10
|
|
|
1/30 - WEIGHT
BSD-F016L90439.A3
F016L90439
|
£14.75
|
£17.70
|
|
|
1/32 - PUSH BUTTON
BSD-F016L68978.A0
F016L68978
|
£3.72
|
£4.47
|
|
|
1/33 - COMPRESSION SPRING
BSD-F016L69569.A4
F016L69569
|
£1.75
|
£2.10
|
|
|
1/35 - LOCKING LEVER
BSD-F016L68980.A5
F016L68980
|
£1.75
|
£2.10
|
|
|
1/38 - WIRING HARNESS
BSD-F016L69388.A2
F016L69388
|
£11.30
|
£13.56
|
|
|
1/40 - PROFILE GASKET
BSD-F016L69212.A1
F016L69212
|
£4.26
|
£5.11
|
|
|
1/41 - SCREW AND WASHER ASSEMBLY
BSD-F016L67951.A20
F016L67951
|
£2.61
|
£3.13
|
|
|
1/43 - WIRE HARNESS ASSEMBLY
BSD-F016L69220.A4
F016L69220
|
£23.86
|
£28.63
|
|
|
1/44 - DATA COUPLER
BSD-F016L69178.A4
F016L69178
|
£21.52
|
£25.83
|
|
|
1/45 - PROFILE GASKET
BSD-F016L69106.A5
F016L69106
|
£10.10
|
£12.12
|
|
|
1/49 - WIRING HARNESS
BSD-F016L69592.A1
F016L69592
|
£11.30
|
£13.56
|
|
|
1/50 - CONTROL MAGNET
BSD-F016L69405.A1
F016L69405
|
£2.61
|
£3.13
|
|
|
1/52 - FASTENING SCREW
BSD-F016L67864.A0
F016L67864
|
£1.75
|
£2.10
|
|
|
1/53 - MEMBRANE Indego 350 Connect
BSD-F016L69432.A0
F016L69432
|
£18.96
|
£22.75
|
|
|
1/56 - WIRING HARNESS
BSD-F016L69247.A3
F016L69247
|
£21.52
|
£25.83
|
|
|
1/57 - PUSH BUTTON
BSD-F016L68981.A0
F016L68981
|
£2.61
|
£3.13
|
|
|
1/58 - BREATHER
BSD-F016L69597.A4
F016L69597
|
£6.52
|
£7.83
|
|
|
1/59 - SCREW M4x20 PLASTIC
BSD-F016L67706.A58
F016L67706
|
£1.75
|
£2.10
|
|
|
1/60 - SCREW CAP
BSD-F016L69179.A1
F016L69179
|
£1.75
|
£2.10
|
|
|
1/61 - PROFILE GASKET
BSD-F016L69180.A4
F016L69180
|
£4.26
|
£5.11
|
|
|
1/802 - CHASSIS Indego 350 Connect
BSD-F016105354.A0
F016105354
|
£58.76
|
£70.51
|
|
|
1/807 - DRIVE MOTOR
BSD-F016104901.A4
F016104901
|
£93.88
|
£112.65
|
|
|
1/813 - MOTOR ASSEMBLY
BSD-F016104897.A1
F016104897
|
£68.42
|
£82.10
|
|
|
1/817 - CUTTER BLADE
BSD-F016104903.A0
F016104903
|
£21.68
|
£26.01
|
|
|
1/818 - CUTTER BLADE
BSD-F016104255.A16
F016104255
|
£27.23
|
£32.68
|
|
|
1/821 - MOTOR COVER
BSD-F016104896.A4
F016104896
|
£14.75
|
£17.70
|
|
|
1/824 - CASTER WHEEL
BSD-1607000EE5.A5
1607000EE5
|
£31.64
|
£37.97
|
|
|
1/826 - SOCKET
BSD-F016104899.A1
F016104899
|
£6.52
|
£7.83
|
|
|
1/827 - DRIVE WHEEL
BSD-F016104902.A5
F016104902
|
£33.74
|
£40.49
|
|
|
1/847 - BATTERY PACK
BSD-F016104898.A4
F016104898
|
£135.25
|
£162.30
|
|
|
1/848 - PRINTED CIRCUIT BOARD
BSD-F016104900.A4
F016104900
|
£171.57
|
£205.88
|
|
|
1/854 - PRINTED CIRCUIT BOARD
BSD-F016104894.A1
F016104894
|
£81.81
|
£98.17
|
|
|
2/1/2 - BASEPLATE COMPLETE
BSD-F016L69194.A2
F016L69194
|
£40.80
|
£48.96
|
|
|
2/3 - COVER PLATE
BSD-F016L69193.A3
F016L69193
|
£6.52
|
£7.83
|
|
|
2/5 - PRINTED CIRCUIT BOARD
BSD-1600A02545.A0
1600A02545
|
£186.78
|
£224.13
|
|
|
805 - POWER SUPPLY UNIT EU
BSD-F016L69170.A3
F016L69170
|
£68.42
|
£82.10
|
|
|
805 - POWER SUPPLY UNIT UK
BSD-F016L69437.A1
F016L69437
|
£93.88
|
£112.65
|
|
|
805 - POWER SUPPLY UNIT CH
BSD-F016L69439.A4
F016L69439
|
£68.42
|
£82.10
|
|
