2 - FIELD 220-230V
BSD-2604220491.A3
2604220491
|
£21.68
|
£26.01
|
|
|
3 - ARMATURE 220-230V
BSD-2604010769.A1
2604010769
|
£63.50
|
£76.20
|
|
|
4 - ON-OFF SWITCH
BSD-1607200086.A385
1607200086
|
£11.30
|
£13.56
|
|
|
5 - POWER SUPPLY CORD I / BR 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460275.A1
2604460275
|
-
|
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A997
2600703012
|
£2.80
|
£3.36
|
|
|
7 - FASTENING CLAMP
BSD-1601302017.A433
1601302017
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-2601118932.A2
2601118932
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329124.A39
2607329124
|
£10.10
|
£12.12
|
|
|
13 - GROOVE BALL BEARING 7x22x7
BSD-2600905018.A8
2600905018
|
-
|
|
|
|
16 - BRUSH HOLDER
BSD-2601323022.A109
2601323022
|
£2.80
|
£3.36
|
|
|
16 - BRUSH HOLDER
BSD-1600A003G4.A220
1600A003G4
|
£3.72
|
£4.47
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A489
2603410001
|
£1.75
|
£2.10
|
|
|
19 - TORX OVAL-HEAD SCREW 4x12
BSD-2603490021.A222
2603490021
|
£1.75
|
£2.10
|
|
|
20 - STICKER
BSD-2601118932.A3
2601118932
|
-
|
|
|
|
25 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A1047
2603490017
|
£2.16
|
£2.59
|
|
|
26 - SPIRAL SPRING
BSD-2604652009.A199
2604652009
|
£1.75
|
£2.10
|
|
|
27 - SHIM
BSD-2600150033.A38
2600150033
|
£2.16
|
£2.59
|
|
|
28 - SHIM WASHER 0.3 MM
BSD-2600101027.A87
2600101027
|
£1.75
|
£2.10
|
|
|
28 - SHIM WASHER 0.5 MM
BSD-2600101667.A135
2600101667
|
£1.75
|
£2.10
|
|
|
28 - SHIM WASHER 0.2 MM
BSD-2600101665.A83
2600101665
|
£1.75
|
£2.10
|
|
|
29 - SHRINKABLE TUBE
BSD-1610712034.A48
1610712034
|
£1.66
|
£1.99
|
|
|
31 - HOUSING COVER
BSD-1600508009.A9
1600508009
|
-
|
|
|
|
33 - SWITCH HANDLE
BSD-1602026060.A9
1602026060
|
£2.33
|
£2.80
|
|
|
34 - ADJUSTING SLIDE
BSD-1602319002.A143
1602319002
|
£2.61
|
£3.13
|
|
|
35 - COVER DISC
BSD-2601328045.A79
2601328045
|
£2.16
|
£2.59
|
|
|
37 - CONNECTING CABLE L=52MM
BSD-2604448016.A5
2604448016
|
£1.75
|
£2.10
|
|
|
38 - CABLE
BSD-2604448149.A25
2604448149
|
£1.75
|
£2.10
|
|
|
39 - SUPPRESSION FILTER
BSD-2604465096.A0
2604465096
|
£5.30
|
£6.36
|
|
|
40 - COMPRESSION SPRING
BSD-1604611026.A436
1604611026
|
£1.75
|
£2.10
|
|
|
41 - SPEED GOVERNOR 230V
BSD-2607230013.A2
2607230013
|
£54.42
|
£65.30
|
|
|
42 - SPINDLE HOUSING
BSD-2605806376.A12
2605806376
|
-
|
|
|
|
43 - UNION NUT SW 17. dia 18.5 MM
BSD-2603312006.A23
2603312006
|
£6.52
|
£7.83
|
|
|
45 - SEAL BUSHING
BSD-2600300073.A30
2600300073
|
£6.52
|
£7.83
|
|
|
46 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A258
2916660013
|
£2.16
|
£2.59
|
|
|
47 - RETAINING CLIP DIN 471-15x1-FSt
BSD-2916650006.A516
2916650006
|
£1.75
|
£2.10
|
|
|
48 - CUPPED WASHER
BSD-2600500033.A125
2600500033
|
£2.61
|
£3.13
|
|
|
49 - FELT WASHER
BSD-2600108033.A54
2600108033
|
£1.75
|
£2.10
|
|
|
50 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A826
2603490023
|
£1.75
|
£2.10
|
|
|
51 - GROOVE BALL BEARING 15x32x9
BSD-2600905017.A47
2600905017
|
£10.10
|
£12.12
|
|
|
52 - SHIM 0.1 MM
BSD-1600102626.A57
1600102626
|
£2.16
|
£2.59
|
|
|
199 - STICKER
BSD-1601110265.A130
1601110265
|
-
|
|
|
|
200 - MILLING FIXTURE
BSD-2607030004.A12
2607030004
|
-
|
|
|
|
201 - BASE PLATE
BSD-2608000014.A23
2608000014
|
-
|
|
|
|
202 - COMPRESSION SPRING
BSD-2604615011.A8
2604615011
|
-
|
|
|
|
203 - DEPTH MEASURE
BSD-2601010052.A11
2601010052
|
-
|
|
|
|
204 - WING SCREW
BSD-1603480003.A28
1603480003
|
-
|
|
|
|
205 - GUIDE PLATE
BSD-2608005014.A2
2608005014
|
-
|
|
|
|
206 - KNURLED THUMBSCREW
BSD-1603501018.A18
1603501018
|
£2.52
|
£3.02
|
|
|
207 - ADJUSTING NUT
BSD-2603345015.A25
2603345015
|
-
|
|
|
|
208 - COMPRESSION SPRING
BSD-2604611008.A24
2604611008
|
-
|
|
|
|
209 - DETENT PIN
BSD-2602305044.A11
2602305044
|
£1.75
|
£2.10
|
|
|
210 - HEX SCREW DIN 931-M8x60-8.8
BSD-2911001258.A13
2911001258
|
-
|
|
|
|
211 - STAR KNOB
BSD-1613349015.A28
1613349015
|
£2.80
|
£3.36
|
|
|
212 - PRESSURE SPINDLE
BSD-2603200020.A9
2603200020
|
-
|
|
|
|
213 - HANDLE
BSD-2602026001.A16
2602026001
|
£5.30
|
£6.36
|
|
|
214 - MANUFACTURER'S NAMEPLATE
BSD-2601118933.A2
2601118933
|
-
|
|
|
|
215 - PLAIN WASHER DIN 9021-A6.4-ST
BSD-2916011884.A59
2916011884
|
-
|
|
|
|
216 - SOCKET HEAD CAP SCREW DIN 84-AM6x16-5.8
BSD-2910011191.A65
2910011191
|
-
|
|
|
|
218 - STICKER
BSD-2601110137.A6
2601110137
|
-
|
|
|
|
219 - PERFORATED PANEL
BSD-2601031002.A5
2601031002
|
-
|
|
|
|
651 - STRAIGHT PIN 4x60 MM
BSD-2603101035.A123
2603101035
|
£2.80
|
£3.36
|
|
|
654 - TOOL GUIDE
BSD-2602053000.A7
2602053000
|
-
|
|
|
|
655 - GUIDE PLATE
BSD-2607000032.A14
2607000032
|
-
|
|
|
|
656 - COUNTERSUNK-HEAD SCREW M 6x16 DIN 963-4.8
BSD-2910761197.A7
2910761197
|
-
|
|
|
|
657 - SOCKET HEAD CAP SCREW DIN 84-AM6x16-5.8
BSD-2910011191.A60
2910011191
|
-
|
|
|
|
658 - GUIDING BOLT
BSD-2603102007.A7
2603102007
|
-
|
|
|
|
659 - EDGE GUIDE
BSD-2607000067.A14
2607000067
|
-
|
|
|
|
660 - WING SCREW
BSD-1603480003.A29
1603480003
|
-
|
|
|
|
661 - FLUID-LEVEL GAUGE
BSD-2607000033.A11
2607000033
|
-
|
|
|
|
662 - GUIDE ROLLER
BSD-2607000031.A11
2607000031
|
-
|
|
|
|
663 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A1258
2915011007
|
-
|
|
|
|
665 - GUIDE-PLATE
BSD-2601332007.A22
2601332007
|
-
|
|
|
|
666 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A1257
2915011007
|
-
|
|
|
|
671 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A601
2607950511
|
£4.26
|
£5.11
|
|
|
672 - EXTRACTOR HEAD
BSD-2608190008.A17
2608190008
|
-
|
|
|
|
673 - PROTECTIVE RING
BSD-2605730034.A17
2605730034
|
-
|
|
|
|
744 - COLLET dia 6 MM / dia 10 MM
BSD-2608570047.A36
2608570047
|
£10.82
|
£12.99
|
|
|
744 - COLLET dia 6.4MM=1/4 / dia 10MM
BSD-2608570048.A9
2608570048
|
£12.49
|
£14.99
|
|
|
744 - COLLET dia 8 MM / dia 10 MM
BSD-2608570049.A36
2608570049
|
£12.49
|
£14.99
|
|
|
801 - MOTOR HOUSING
BSD-2605108907.A1
2605108907
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-2604320910.A52
2604320910
|
£10.10
|
£12.12
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1335
160111A3H3
|
£2.61
|
£3.13
|
|
