1 - HOUSING SECTION
BSD-2605104730.A0
2605104730
|
£23.86
|
£28.63
|
|
|
2 - FIELD 230V
BSD-1604220365.A0
1604220365
|
£23.86
|
£28.63
|
|
|
3 - ARMATURE 220-240V
BSD-2604011265.A0
2604011265
|
£33.45
|
£40.14
|
|
|
3/50 - FAN
BSD-2606610077.A0
2606610077
|
£4.99
|
£5.99
|
|
|
4 - SWITCH
BSD-2607200260.A63
2607200260
|
£11.87
|
£14.24
|
|
|
5 - POWER SUPPLY CORD GB 240V 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460124.A56
2604460124
|
-
|
|
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2600703017.A710
2600703017
|
£2.74
|
£3.29
|
|
|
7 - CABLE CLIP
BSD-2601035001.A868
2601035001
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE PEX 420 AE
BSD-2601116753.A1
2601116753
|
£3.51
|
£4.21
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A767
1607328028
|
£5.57
|
£6.68
|
|
|
14 - GROOVE BALL BEARING
BSD-2600905034.A17
2600905034
|
£13.12
|
£15.75
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A52
2603410001
|
£1.84
|
£2.21
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1059
2603490022
|
£1.84
|
£2.21
|
|
|
32 - CONTACT SPRING
BSD-2601329057.A41
2601329057
|
-
|
|
|
|
33 - BACKING PAD
BSD-2608601177.A1
2608601177
|
£23.86
|
£28.63
|
|
|
35 - HEX SOCKET HEAD CAP SCREW
BSD-2603414061.A1
2603414061
|
£3.80
|
£4.56
|
|
|
36 - RUBBER BUFFER
BSD-1603100036.A103
1603100036
|
£1.84
|
£2.21
|
|
|
39 - CONNECTING CABLE L=233 MM
BSD-2604448181.A25
2604448181
|
£2.16
|
£2.59
|
|
|
43 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A927
2603490023
|
£1.84
|
£2.21
|
|
|
44 - SEAL STRIP
BSD-2602380003.A43
2602380003
|
£1.32
|
£1.58
|
|
|
45 - HANDLE
BSD-2602025068.A1
2602025068
|
-
|
|
|
|
46 - ROUND-HEAD BOLT DIN 603-M6x110
BSD-2910285226.A47
2910285226
|
£1.84
|
£2.21
|
|
|
47 - WING NUT M6
BSD-1603339006.A25
1603339006
|
£2.64
|
£3.17
|
|
|
48 - PUSHER
BSD-2608005043.A0
2608005043
|
£1.75
|
£2.10
|
|
|
50 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A631
1907950006
|
£4.48
|
£5.37
|
|
|
51 - FRICTION RING
BSD-2600206015.A26
2600206015
|
-
|
|
|
|
52 - DAMPING PLATE
BSD-2601022000.A423
2601022000
|
£1.75
|
£2.10
|
|
|
54 - LOCKING WASHER
BSD-2600550029.A0
2600550029
|
£1.75
|
£2.10
|
|
|
56 - RPM ACTUATOR 230V
BSD-2607233066.A1
2607233066
|
£28.59
|
£34.31
|
|
|
654 - DUST CHAMBER
BSD-2605411210.A1
2605411210
|
-
|
|
|
|
808 - NAMEPLATE
BSD-2601116755.A0
2601116755
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-2607014001.A0
2607014001
|
-
|
|
|
|
813 - CARTRIDGE BEARING
BSD-2605805005.A55
2605805005
|
-
|
|
|
|
816 - BRUSH PLATE
BSD-2604337911.A1
2604337911
|
£15.49
|
£18.59
|
|
|
826 - FAN
BSD-2606610904.A1
2606610904
|
£27.31
|
£32.77
|
|
