5 - POWER SUPPLY CORD CH 2.65m 2 x 1.0mm H05VV-F
BSD-1604460430.A5
1604460430
|
£12.64
|
£15.17
|
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2600703017.A130
2600703017
|
£2.74
|
£3.29
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1967
2601035001
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601119594.A3
2601119594
|
-
|
|
|
|
13 - FLANGED BEARING
BSD-2605805008.A92
2605805008
|
£5.57
|
£6.68
|
|
|
14 - GROOVE BALL BEARING 9x24x7
BSD-2600905065.A16
2600905065
|
-
|
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1871
2603490022
|
£1.84
|
£2.21
|
|
|
25 - DAMPING RUBBER
BSD-2603100056.A30
2603100056
|
£1.84
|
£2.21
|
|
|
27 - CONTACT SPRING
BSD-2601329037.A119
2601329037
|
£1.75
|
£2.10
|
|
|
28 - SWITCH HANDLE
BSD-1602026057.A22
1602026057
|
£2.07
|
£2.48
|
|
|
29 - ADJUSTING SLIDE
BSD-2602319017.A11
2602319017
|
-
|
|
|
|
30 - COMPRESSION SPRING
BSD-1604611026.A209
1604611026
|
£1.84
|
£2.21
|
|
|
50 - COUNTERWEIGHT
BSD-2601098047.A6
2601098047
|
£8.49
|
£10.19
|
|
|
55 - FRICTION WASHER
BSD-2600100064.A13
2600100064
|
£2.05
|
£2.46
|
|
|
62 - CLAMPING RING
BSD-2600118010.A6
2600118010
|
£1.75
|
£2.10
|
|
|
68 - SHEET METAL COVER
BSD-2600101094.A7
2600101094
|
-
|
|
|
|
71 - PUSH-BUTTON
BSD-2600591012.A8
2600591012
|
-
|
|
|
|
72 - FELT SEAL
BSD-2601005020.A6
2601005020
|
£4.48
|
£5.37
|
|
|
75 - SUPPRESSION FILTER
BSD-2604465109.A41
2604465109
|
-
|
|
|
|
700 - CROSS CUTTING TABLE
BSD-0603999014.A2
0603999014
|
-
|
|
|
|
700/1 - CROSS CUTTING TABLE
BSD-2608190036.A5
2608190036
|
-
|
|
|
|
700/1/23 - WING SCREW M 6x77 MM
BSD-2603480010.A23
2603480010
|
£4.48
|
£5.37
|
|
|
700/1/804 - POINTER
BSD-2602123900.A12
2602123900
|
-
|
|
|
|
700/20 - ADJUSTABLE SCREW CLAMP
BSD-2607960008.A5
2607960008
|
£21.68
|
£26.01
|
|
|
702 - SAW BLADE SET FS 200 AB
BSD-2608661200.A6
2608661200
|
£8.59
|
£10.31
|
|
|
703 - SAW BLADE SET FS 200 ABU
BSD-2608661201.A15
2608661201
|
£9.09
|
£10.91
|
|
|
704 - SAW BLADE SET FS 180 AT
BSD-2608661202.A6
2608661202
|
£8.59
|
£10.31
|
|
|
705 - SAW BLADE SET FS 180 ATU
BSD-2608661203.A15
2608661203
|
£9.09
|
£10.91
|
|
|
706 - SAW BLADE SET FS 180 DT
BSD-2608661204.A6
2608661204
|
£8.59
|
£10.31
|
|
|
707 - SAW BLADE SET FS 180 DTU
BSD-2608661205.A15
2608661205
|
£9.09
|
£10.91
|
|
|
801 - HOUSING SECTION
BSD-2605104822.A4
2605104822
|
-
|
|
|
|
802 - FIELD 230-240V
BSD-2604220599.A7
2604220599
|
£21.68
|
£26.01
|
|
|
803 - ARMATURE 230-240V
BSD-2604010958.A11
2604010958
|
-
|
|
|
|
803/03/50 - FAN
BSD-2606610090.A4
2606610090
|
£1.75
|
£2.10
|
|
|
808 - NAMEPLATE
BSD-2601119842.A0
2601119842
|
-
|
|
|
|
816 - BRUSH PLATE
BSD-2604337903.A0
2604337903
|
-
|
|
|
|
816/04 - CARBON-BRUSH SET
BSD-2604321921.A24
2604321921
|
£14.91
|
£17.89
|
|
|
835/01 - GEAR SHAFT
BSD-2603100901.A12
2603100901
|
-
|
|
|
|
856 - CONNECTING ROD
BSD-2602001902.A3
2602001902
|
-
|
|
|
|
865 - FIXING PLATE
BSD-2608000919.A17
2608000919
|
£22.76
|
£27.31
|
|
|
873 - THRUST MEMBER
BSD-1600591019.A25
1600591019
|
£2.52
|
£3.02
|
|
