1 - TABLE TOP
BSD-1608000077.A1
1608000077
|
-
|
|
|
|
2 - COVER PLATE
BSD-1608000078.A0
1608000078
|
-
|
|
|
|
3 - STOP BRACKET
BSD-1601334001.A0
1601334001
|
-
|
|
|
|
4 - TABLE TOP
BSD-1608000073.A1
1608000073
|
-
|
|
|
|
5 - STAR KNOB
BSD-1603349015.A0
1603349015
|
-
|
|
|
|
6 - STOP BRACKET
BSD-1601332016.A6
1601332016
|
-
|
|
|
|
7 - PARALLEL-GUIDE
BSD-1601334003.A0
1601334003
|
-
|
|
|
|
8 - SPACER BUSHING
BSD-1600300085.A0
1600300085
|
-
|
|
|
|
9 - TABLE LEG
BSD-1601334002.A2
1601334002
|
-
|
|
|
|
10 - RUBBER RING
BSD-1602380012.A25
1602380012
|
£1.32
|
£1.58
|
|
|
11 - MOUNTING BRACKET
BSD-1601321034.A0
1601321034
|
-
|
|
|
|
12 - GUIDE
BSD-1601098004.A3
1601098004
|
-
|
|
|
|
13 - PLAIN WASHER
BSD-1600100022.A1
1600100022
|
-
|
|
|
|
14 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A518
2916011014
|
£1.75
|
£2.10
|
|
|
15 - COUNTERSUNK-HEAD SCREW
BSD-1603421000.A2
1603421000
|
-
|
|
|
|
16 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A476
2915011007
|
-
|
|
|
|
17 - WING NUT M6 DIN 315-G-GTW-40
BSD-2915191006.A10
2915191006
|
-
|
|
|
|
18 - ROUND-HEAD BOLT M5x12 MM
BSD-1603434004.A12
1603434004
|
-
|
|
|
|
19 - HEX SCREW DIN 933 M6x12-5.6
BSD-2911051193.A2
2911051193
|
-
|
|
|
|
20 - ROUND-HEAD BOLT DIN 603-M6x35
BSD-2910281207.A59
2910281207
|
£1.75
|
£2.10
|
|
|
21 - GUIDE ROD
BSD-1603052011.A0
1603052011
|
-
|
|
|
|
22 - COUNTERSUNK-HEAD SCREW DIN 963-M4x6-4.8
BSD-2910761116.A6
2910761116
|
-
|
|
|
|
23 - HEX NUT DIN 934-M 5-m-8
BSD-2915011006.A144
2915011006
|
-
|
|
|
|
24 - LOCKING WASHER
BSD-2916070232.A9
2916070232
|
£1.75
|
£2.10
|
|
|
25 - PARTS SET
BSD-1607000185.A3
1607000185
|
-
|
|
|
|
25 - MANUFACTURER'S NAMEPLATE
BSD-1601110008.A0
1601110008
|
-
|
|
|
|
26 - PLAIN WASHER DIN 9021-A6.4-ST
BSD-2916011884.A9
2916011884
|
-
|
|
|
|
27 - STRAP
BSD-1601021004.A5
1601021004
|
-
|
|
|
|
28 - ROUND-HEAD BOLT DIN 603-M5x20
BSD-2910281162.A1
2910281162
|
-
|
|
|
|
29 - SPACER
BSD-1601329011.A2
1601329011
|
-
|
|
|
|
30 - PLAIN WASHER A 5.3 DIN 9021-ST
BSD-2916011883.A5
2916011883
|
-
|
|
|
|
31 - PALM GRIP M5
BSD-1603349016.A0
1603349016
|
-
|
|
|
|
32 - GUIDE TUBE
BSD-1600795006.A0
1600795006
|
-
|
|
|
|
101 - COUNTERSUNK-HEAD SCREW DIN 963-M 5x25-5.8
BSD-2910775164.A1
2910775164
|
-
|
|
|
|
102 - MOUNTING BRACKET
BSD-1601329012.A3
1601329012
|
-
|
|
|
|
104 - ROUND-HEAD BOLT M5x12 MM
BSD-1603434004.A15
1603434004
|
-
|
|
|
|
105 - HEX NUT DIN 934-M 5-m-8
BSD-2915011006.A145
2915011006
|
-
|
|
|
|
107 - PLAIN WASHER DIN 433-5.3-ST
BSD-2916011011.A7
2916011011
|
£1.75
|
£2.10
|
|
|
108 - SOCKET HEAD CAP SCREW M5x35 DIN 84-5.8
BSD-2910011168.A26
2910011168
|
-
|
|
|
|
109 - MANUFACTURER'S NAMEPLATE
BSD-1601110016.A5
1601110016
|
-
|
|
|
|
110 - PROTECTIVE COVER
BSD-1609255009.A2
1609255009
|
-
|
|
|
|
111 - SLOTTED SPRING PIN DIN 1481-3x24
BSD-2917760083.A1
2917760083
|
-
|
|
|
|
112 - WING NUT M6 DIN 315-G-GTW-40
BSD-2915191006.A7
2915191006
|
-
|
|
|
|
113 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A516
2916011014
|
£1.75
|
£2.10
|
|
|
114 - ROUND-HEAD BOLT DIN 603-M6x35
BSD-2910281207.A55
2910281207
|
£1.75
|
£2.10
|
|
|
115 - RIVING KNIFE
BSD-1609200813.A0
1609200813
|
-
|
|
|
|
650 - PARTS SET
BSD-1607000185.A4
1607000185
|
-
|
|
|
|
651 - DOUBLE HEAD ENGIN WRENCH SW8/10
BSD-1607950524.A6
1607950524
|
-
|
|
|
|
652 - COVER PLATE
BSD-1608000079.A0
1608000079
|
-
|
|
|
|
653 - PROTECTIVE COVER
BSD-1609200539.A4
1609200539
|
-
|
|
|
|
702 - STOP PLATE
BSD-1602388019.A1
1602388019
|
-
|
|
|
|
702/02 - TORX FLAT-HEAD SCREW M4x20
BSD-3603435051.A140
3603435051
|
£1.75
|
£2.10
|
|
|
702/03 - WING NUT DIN 315-M4-GT-C
BSD-2915191004.A2
2915191004
|
-
|
|
|
|
704 - PARTS SET
BSD-1607000104.A0
1607000104
|
-
|
|
|
|
705 - PARTS SET
BSD-1609200821.A1
1609200821
|
-
|
|
|
|
706 - FIXING PLATE
BSD-1607000103.A1
1607000103
|
-
|
|
|
