3 - BASE PLATE
BSD-3601329011.A2
3601329011
|
£61.98
|
£74.38
|
|
|
4 - SWIVELLING LEVER
BSD-3602013000.A0
3602013000
|
-
|
|
|
|
5 - COVERING HOOD
BSD-3605500101.A6
3605500101
|
-
|
|
|
|
6 - TORSION SPRING
BSD-3604651003.A23
3604651003
|
£4.75
|
£5.70
|
|
|
7 - SWIVELLING AXIS
BSD-3603120010.A7
3603120010
|
£12.04
|
£14.45
|
|
|
8 - ECCENTRIC DISC
BSD-3602200001.A12
3602200001
|
£5.30
|
£6.36
|
|
|
10 - THRUST MEMBER
BSD-3601000002.A14
3601000002
|
£2.33
|
£2.80
|
|
|
11 - PARALLEL-GUIDE
BSD-3601329004.A3
3601329004
|
-
|
|
|
|
12 - ROUND NUT M14
BSD-3603340009.A17
3603340009
|
-
|
|
|
|
13 - CLAMPING-FLANGE
BSD-3600328032.A9
3600328032
|
£8.49
|
£10.19
|
|
|
14 - DETENT PIN
BSD-2602305045.A15
2602305045
|
-
|
|
|
|
15 - STICKER
BSD-3601119024.A15
3601119024
|
£1.95
|
£2.34
|
|
|
16 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A9
1601110481
|
£2.16
|
£2.59
|
|
|
17 - KNURLED THUMBSCREW
BSD-3603490008.A18
3603490008
|
-
|
|
|
|
18 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x10-8.8
BSD-2910141152.A27
2910141152
|
£1.75
|
£2.10
|
|
|
19 - LOCKING WASHER DIN 6799-4-FSt
BSD-2916080007.A146
2916080007
|
£2.61
|
£3.13
|
|
|
20 - COMPRESSION SPRING
BSD-3604611018.A11
3604611018
|
-
|
|
|
|
21 - HEX NUT DIN 934-M 5-m-8
BSD-2915011006.A78
2915011006
|
-
|
|
|
|
22 - PAN HEAD SCREW DIN 85-M6x20-4.8
BSD-2910095201.A11
2910095201
|
-
|
|
|
|
23 - CARRIER BRACKET
BSD-3602380000.A11
3602380000
|
£7.78
|
£9.33
|
|
|
24 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x12-8.8
BSD-2910141154.A47
2910141154
|
£1.75
|
£2.10
|
|
|
25 - SUPPORT CLAMP
BSD-3602012000.A18
3602012000
|
£1.75
|
£2.10
|
|
|
26 - PAN HEAD SCREW DIN 922-M4x3x3-5.8
BSD-2910271900.A12
2910271900
|
£1.32
|
£1.58
|
|
|
31 - VERTEBRAS
BSD-3601251001.A20
3601251001
|
£3.34
|
£4.01
|
|
|
32 - TENSIONING LEVER
BSD-3601923000.A1
3601923000
|
£3.34
|
£4.01
|
|
|
33 - REFERENCE PLATE
BSD-3601119063.A3
3601119063
|
£1.95
|
£2.34
|
|
|
34 - ADJUSTING PLATE
BSD-3601032001.A2
3601032001
|
£1.75
|
£2.10
|
|
|
36 - THREAD-FORMING TAP. SCREW DIN 7500-TM4x12
BSD-2914471401.A67
2914471401
|
£1.75
|
£2.10
|
|
|
37 - LOCKING WASHER
BSD-3600190018.A3
3600190018
|
£1.32
|
£1.58
|
|
|
201 - MOTOR HOUSING
BSD-1605108127.A54
1605108127
|
-
|
|
|
|
202 - FIELD 230-240V
BSD-1604220224.A24
1604220224
|
-
|
|
|
|
204 - ON-OFF SWITCH
BSD-1607200086.A221
1607200086
|
£11.30
|
£13.56
|
|
|
204/10 - PAN HEAD SCREW DIN 85-AM3x6-CUZN
BSD-2910110048.A456
2910110048
|
£1.75
|
£2.10
|
|
|
205 - POWER SUPPLY CORD EU 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1607000386.A65
1607000386
|
£21.52
|
£25.83
|
|
|
206 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A130
2600703011
|
£2.80
|
£3.36
|
|
|
207 - FASTENING CLAMP
BSD-1601302017.A1066
1601302017
|
£1.75
|
£2.10
|
|
|
209 - MANUFACTURER'S NAMEPLATE
BSD-1601110736.A2
1601110736
|
-
|
|
|
|
212 - SUPPRESSION FILTER
BSD-2607329124.A25
2607329124
|
£10.10
|
£12.12
|
|
|
213 - BALL BEARING 7x19x6
BSD-2600905032.A1249
2600905032
|
£5.30
|
£6.36
|
|
|
214 - GROOVE BALL BEARING 8x22x7
BSD-1600905011.A115
1600905011
|
£5.58
|
£6.70
|
|
|
215 - FAN
BSD-1606610121.A144
1606610121
|
£1.75
|
£2.10
|
|
|
216 - BRUSH HOLDER
BSD-1600A003G4.A382
1600A003G4
|
£3.72
|
£4.47
|
|
|
217 - MANUFACTURER'S NAMEPLATE
BSD-1601110737.A4
1601110737
|
-
|
|
|
|
218 - COMPRESSION SPRING
BSD-1604611026.A646
1604611026
|
£1.75
|
£2.10
|
|
|
222 - ADJUSTING SLIDE
BSD-1602319002.A95
1602319002
|
£2.61
|
£3.13
|
|
|
223 - SWITCH HANDLE
BSD-1602026057.A357
1602026057
|
£1.97
|
£2.36
|
|
|
225 - HOUSING COVER
BSD-1600508005.A27
1600508005
|
£3.80
|
£4.56
|
|
|
226 - RUBBER BUSHING
BSD-1600502020.A20
1600502020
|
£2.61
|
£3.13
|
|
|
227 - RUBBER RING
BSD-1600206025.A910
1600206025
|
£2.16
|
£2.59
|
|
|
229 - AIR-DEFLECTOR RING
BSD-1601328005.A143
1601328005
|
£2.61
|
£3.13
|
|
|
231 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A28
2916660013
|
£2.16
|
£2.59
|
|
|
232 - GRINDING SPINDLE M14. SW17
BSD-1603523101.A2
1603523101
|
£18.96
|
£22.75
|
|
|
233 - O-RING 46.0x1.1 MM
BSD-3600210124.A276
3600210124
|
£2.80
|
£3.36
|
|
|
235 - SHIM 0.2 MM
BSD-1600136010.A165
1600136010
|
£2.61
|
£3.13
|
|
|
235 - SHIM 0.3 MM
BSD-1600136011.A164
1600136011
|
£2.16
|
£2.59
|
|
|
235 - SHIM 0.1 MM
BSD-1600136012.A159
1600136012
|
£1.75
|
£2.10
|
|
|
236 - SPRING WASHER
BSD-1600150011.A257
1600150011
|
£1.75
|
£2.10
|
|
|
237 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A44
1600290016
|
£2.61
|
£3.13
|
|
|
238 - CROWN GEAR Z=36
BSD-1606333601.A104
1606333601
|
£8.49
|
£10.19
|
|
|
239 - SPIRAL SPRING
BSD-1604652013.A1074
1604652013
|
£1.75
|
£2.10
|
|
|
240 - SPRING RETAINING RING DIN 472-25x1.2MM
BSD-2916660009.A10
2916660009
|
£2.16
|
£2.59
|
|
|
241 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A549
1600910018
|
£5.30
|
£6.36
|
|
|
242 - GROOVE BALL BEARING 12x32x10
BSD-1600905006.A83
1600905006
|
£12.04
|
£14.45
|
|
|
243 - BEVEL GEAR Z=11
BSD-1606333242.A153
1606333242
|
£48.38
|
£58.06
|
|
|
245 - HEX NUT M7. SW10
BSD-1603300016.A381
1603300016
|
£1.75
|
£2.10
|
|
|
247 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A187
2910211018
|
£1.75
|
£2.10
|
|
|
248 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A395
1613435034
|
£1.75
|
£2.10
|
|
|
249 - THREAD-FORMING TAP. SCREW
BSD-1603435026.A48
1603435026
|
£2.16
|
£2.59
|
|
|
250 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A908
2910211021
|
£1.75
|
£2.10
|
|
|
252 - SUPPRESSOR BOX
BSD-1604465104.A2
1604465104
|
-
|
|
|
|
253 - CONNECTING CABLE L=95 MM
BSD-1604448005.A102
1604448005
|
£2.80
|
£3.36
|
|
|
254 - CONNECTING CABLE L=40 MM
BSD-1604448006.A20
1604448006
|
£2.61
|
£3.13
|
|
|
255 - TORX OVAL-HEAD SCREW
BSD-2914201508.A137
2914201508
|
£1.75
|
£2.10
|
|
|
305 - REFERENCE PLATE
BSD-1601110470.A46
1601110470
|
£1.75
|
£2.10
|
|
|
307 - O-RING 4.5x1.0 MM
BSD-1600210044.A361
1600210044
|
£1.75
|
£2.10
|
|
|
650 - AUXILIARY HANDLE M10. dia32.5x105 MM
BSD-160202509T.A446
160202509T
|
£3.72
|
£4.47
|
|
|
651 - PIN-TYPE FACE-WRENCH
BSD-1607950052.A421
1607950052
|
£3.72
|
£4.47
|
|
|
652 - MOUNTING PLATE
BSD-3601012001.A8
3601012001
|
£4.26
|
£5.11
|
|
|
653/10 - FITTING
BSD-2605702009.A3
2605702009
|
£2.80
|
£3.36
|
|
|
653/20 - DUST BAG
BSD-2605411017.A4
2605411017
|
£6.61
|
£7.93
|
|
|
653/30 - ELBOW
BSD-2605702019.A12
2605702019
|
-
|
|
|
|
653/40 - O-RING 20.0x1.5 MM
BSD-1610210075.A24
1610210075
|
£2.61
|
£3.13
|
|
|
700 - SIDE-MILLING CUTTER Z=8
BSD-3608641008.A7
3608641008
|
£44.69
|
£53.63
|
|
|
700 - SIDE-MILLING CUTTER dia 105x20x2.2 MM. Z=12
BSD-3608641001.A7
3608641001
|
£26.66
|
£31.99
|
|
|
700 - SIDE-MILLING CUTTER dia 105x20x2.8 MM. Z=22
BSD-3608641002.A8
3608641002
|
£39.16
|
£46.99
|
|
|
702 - FITTING dia 25x35 MM
BSD-1600499005.A120
1600499005
|
£3.49
|
£4.19
|
|
|
703 - PARTS SET
BSD-3607030020.A10
3607030020
|
-
|
|
|
|
703/10 - PROTECTIVE COVER dia 115 MM(4 1/2)
BSD-2605510125.A111
2605510125
|
£27.23
|
£32.68
|
|
|
703/10/20 - SOCKET HEAD CAP SCREW DIN 84-M 6x16-8.8
BSD-2910022197.A231
2910022197
|
-
|
|
|
|
703/20 - ROUND NUT M14
BSD-1603340015.A39
1603340015
|
£3.87
|
£4.64
|
|
|
703/30 - FASTENING FLANGE
BSD-2605703023.A8
2605703023
|
-
|
|
|
|
703/40 - GRINDING WHEEL dia 115xdia 22.2x6 MM
BSD-2608600003.A8
2608600003
|
-
|
|
|
|
711 - PARALLEL-GUIDE
BSD-3601329013.A15
3601329013
|
£93.88
|
£112.65
|
|
|
711/10 - CARRIER
BSD-3601328004.A3
3601328004
|
£19.45
|
£23.34
|
|
|
711/20 - STOP PLATE
BSD-3601328005.A9
3601328005
|
£33.45
|
£40.14
|
|
|
711/30 - HANDLE
BSD-3601328006.A3
3601328006
|
£3.34
|
£4.01
|
|
|
711/40 - PLASTIC BAR
BSD-3601328007.A9
3601328007
|
£2.52
|
£3.02
|
|
|
711/50 - RUBBER BAR
BSD-3601006001.A4
3601006001
|
£2.52
|
£3.02
|
|
|
711/60 - RUBBER PLATE
BSD-3601006002.A8
3601006002
|
£3.80
|
£4.56
|
|
|
711/70 - WING NUT M6
BSD-1603339006.A150
1603339006
|
£2.52
|
£3.02
|
|
|
711/90 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A23
2916011014
|
£1.75
|
£2.10
|
|
|
711/100 - STRAIGHT PIN DIN 7-2m6x10-ST
BSD-2917510036.A4
2917510036
|
£1.75
|
£2.10
|
|
|
711/110 - O-RING 5x2 MM
BSD-1900210301.A5
1900210301
|
£1.32
|
£1.58
|
|
|
711/130 - ROUND-HEAD BOLT DIN 603-M6x20
BSD-2910281201.A187
2910281201
|
£1.75
|
£2.10
|
|
|
711/150 - COUNTERSUNK-HEAD SCREW DIN 7991-M6x12-8.8
BSD-2910545193.A10
2910545193
|
£1.75
|
£2.10
|
|
|
711/160 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A41
2910211020
|
£2.16
|
£2.59
|
|
|
711/170 - OFFSET SCREWDRIVER DIN 911-4
BSD-2607950004.A125
2607950004
|
£1.75
|
£2.10
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A2604
160111A3H3
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014116.A238
1607014116
|
£11.30
|
£13.56
|
|
|
813 - PUSH-BUTTON
BSD-1607000253.A262
1607000253
|
£2.49
|
£2.99
|
|
|
816 - PARTS SET
BSD-1607000244.A6
1607000244
|
£9.49
|
£11.39
|
|
|
821 - GEAR HOUSING
BSD-1605806480.A77
1605806480
|
£48.38
|
£58.06
|
|
|
828 - ASSEMBLY OF SERVICE PARTS
BSD-1607000937.A16
1607000937
|
-
|
|
|
|
830 - ARMATURE WITH FAN 230-240V
BSD-1604010259.A44
1604010259
|
-
|
|
|
