1 - HOUSING HALF
BSD-1609201439.A1
1609201439
|
-
|
|
|
|
2 - HOUSING HALF
BSD-1609201440.A6
1609201440
|
-
|
|
|
|
3 - ROTOR WITHOUT WINDING
BSD-1609201441.A1
1609201441
|
-
|
|
|
|
4 - POWER SUPPLY CORD
BSD-1609202680.A5
1609202680
|
-
|
|
|
|
4/10 - GROMMET dia6.4-dia7.5x75 MM
BSD-1600703016.A258
1600703016
|
£1.66
|
£1.99
|
|
|
4/100 - SOCKET HEAD CAP SCREW DIN 84-AM3x12-8.8
BSD-2910021054.A39
2910021054
|
£1.66
|
£1.99
|
|
|
4/200 - HEX NUT DIN 934-M 3-m-8
BSD-2915011003.A2
2915011003
|
£1.66
|
£1.99
|
|
|
4/400 - SLEEVE TERMINAL
BSD-1609201562.A1
1609201562
|
-
|
|
|
|
4/500 - SOCKET HEAD CAP SCREW DIN 84-AM3X14-5.8
BSD-2910011058.A1
2910011058
|
-
|
|
|
|
4/600 - CONNECTING CABLE
BSD-1609201563.A6
1609201563
|
-
|
|
|
|
4/700 - CONNECTING CABLE
BSD-1609201564.A1
1609201564
|
-
|
|
|
|
5 - SECURING STRIP
BSD-1609201446.A1
1609201446
|
-
|
|
|
|
6 - PROTECTIVE COVER
BSD-1609201444.A0
1609201444
|
-
|
|
|
|
7 - COVER DISC
BSD-1609201445.A3
1609201445
|
-
|
|
|
|
11 - REFERENCE PLATE
BSD-1601110299.A0
1601110299
|
-
|
|
|
|
12 - STICKER
BSD-1601110300.A3
1601110300
|
-
|
|
|
|
13 - INTERMEDIATE FLANGE
BSD-1609201447.A2
1609201447
|
-
|
|
|
|
14 - PROTECTIVE COVER
BSD-1609201448.A1
1609201448
|
-
|
|
|
|
15 - HOLDING PLATE
BSD-1609201449.A2
1609201449
|
-
|
|
|
|
16 - NAMEPLATE
BSD-1601107016.A0
1601107016
|
-
|
|
|
|
17 - GUIDE BUSHING
BSD-1609201450.A1
1609201450
|
-
|
|
|
|
18 - CONICAL SPRING WASHER
BSD-1609201451.A2
1609201451
|
-
|
|
|
|
20 - HEX SOCKET HEAD CAP SCREW
BSD-1617000121.A31
1617000121
|
-
|
|
|
|
21 - HEX SOCKET HEAD CAP SCREW DIN 912-M5X16-8.8
BSD-2910141158.A8
2910141158
|
£1.66
|
£1.99
|
|
|
22 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-5.8
BSD-2910011157.A129
2910011157
|
-
|
|
|
|
23 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A703
2910021122
|
£1.66
|
£1.99
|
|
|
25 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-CuZn
BSD-2910034118.A5
2910034118
|
-
|
|
|
|
26 - ON-OFF SWITCH
BSD-1609201452.A2
1609201452
|
-
|
|
|
|
26/30 - SOCKET HEAD CAP SCREW DIN 84-AM3x8-8.8
BSD-2910021050.A292
2910021050
|
£1.66
|
£1.99
|
|
|
27 - KNURLED THUMBSCREW M 4x6 DIN 464-5.8
BSD-2912501116.A3
2912501116
|
-
|
|
|
|
30 - HEX NUT DIN 934-M12
BSD-1609201457.A2
1609201457
|
-
|
|
|
|
31 - HEX NUT DIN 934-M12-m-8
BSD-2915011011.A7
2915011011
|
-
|
|
|
|
32 - HEX NUT DIN 934-M 5-m-8
BSD-2915011006.A14
2915011006
|
-
|
|
|
|
34 - SPRING WASHER DIN 137-A5-FST
BSD-2916060006.A43
2916060006
|
£1.32
|
£1.58
|
|
|
35 - SPRING WASHER DIN 137-A 4-ST
BSD-2916060005.A181
2916060005
|
£1.66
|
£1.99
|
|
|
37 - TAB WASHER
BSD-1609201453.A2
1609201453
|
-
|
|
|
|
40 - MOTOR CAPACITOR
BSD-1609202554.A5
1609202554
|
-
|
|
|
|
41 - EARTH TERMINAL
BSD-1609202381.A7
1609202381
|
-
|
|
|
|
42 - FELT WASHER
BSD-1609201458.A5
1609201458
|
-
|
|
|
|
43 - ABRASIVE PRODUCT dia 125x20x20 MM. DIN 69120
BSD-1609201402.A10
1609201402
|
-
|
|
|
|
44 - ABRASIVE PRODUCT dia 125x20x20 MM. DIN 69120
BSD-1609201403.A0
1609201403
|
-
|
|
|
|
45 - GROOVE BALL BEARING 12x32x10
BSD-1900905231.A42
1900905231
|
-
|
|
|
|
47 - RUBBER RING
BSD-1609201454.A1
1609201454
|
-
|
|
|
|
48 - POLE SHOE 220-240V
BSD-1609201456.A5
1609201456
|
-
|
|
|
|
49 - PROTECTING ANGLE
BSD-1609201455.A2
1609201455
|
-
|
|
|
|
50 - PAN HEAD SCREW DIN 85-AM6x8-4.8
BSD-2910095189.A3
2910095189
|
-
|
|
|
|
51 - SPRING WASHER DIN 137-A 6-ST
BSD-2916060007.A57
2916060007
|
£1.66
|
£1.99
|
|
|
52 - SPRING WASHER DIN 6797-J8.2-FST
BSD-2916040008.A5
2916040008
|
-
|
|
|
|
53 - HEX NUT DIN 439-BM8-04
BSD-2915051107.A62
2915051107
|
£1.66
|
£1.99
|
|
|
54 - SUPPORT PLATE
BSD-1609201443.A3
1609201443
|
-
|
|
|
|
54/10 - ROUND-HEAD BOLT DIN 603-M5x20
BSD-2910281162.A25
2910281162
|
-
|
|
|
|
54/10 - ROUND-HEAD BOLT M 5x25 DIN 603
BSD-2910281164.A1
2910281164
|
-
|
|
|
|
54/40 - PLAIN WASHER DIN 433-5.3-ST
BSD-2916011011.A165
2916011011
|
£1.66
|
£1.99
|
|
|
54/50 - PALM GRIP M5
BSD-1603349016.A23
1603349016
|
-
|
|
|
|
55 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A262
2916660013
|
£1.95
|
£2.34
|
|
|
56 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1465
2910021118
|
£1.66
|
£1.99
|
|
|
57 - SPACER BUSHING
BSD-1609201560.A0
1609201560
|
-
|
|
|
|
58 - CLAMPING FLANGE
BSD-1609201561.A3
1609201561
|
-
|
|
|
|
59 - SECURING STRIP
BSD-1609201565.A3
1609201565
|
-
|
|
|
|
750 - ABRASIVE PRODUCT dia 125x20x20 MM. DIN 69120
BSD-1609201402.A9
1609201402
|
-
|
|
|
|
751 - ABRASIVE PRODUCT dia 125x20x20 MM. DIN 69120
BSD-1609201403.A1
1609201403
|
-
|
|
|
|
752 - ABRASIVE PRODUCT dia 125x20x20 MM. DIN 69120
BSD-1609201404.A6
1609201404
|
-
|
|
|
|
753 - WHETSTONE
BSD-1607929000.A18
1607929000
|
-
|
|
|
