2 - FIELD 220-240V
BSD-2604220601.A13
2604220601
|
-
|
|
|
|
3 - ARMATURE 230-240V
BSD-2604011241.A0
2604011241
|
-
|
|
|
|
3/50 - ARMATURE WITH FAN
BSD-2606610097.A26
2606610097
|
£3.72
|
£4.47
|
|
|
4 - ON-OFF SWITCH
BSD-2607200581.A20
2607200581
|
£23.86
|
£28.63
|
|
|
5 - POWER SUPPLY CORD GB 230V 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460243.A19
2604460243
|
£13.12
|
£15.75
|
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2600703017.A737
2600703017
|
£2.61
|
£3.13
|
|
|
9 - MANUFACTURER'S NAMEPLATE PST 650 PE
BSD-2601117237.A2
2601117237
|
-
|
|
|
|
13 - GROOVE BALL BEARING 9x24x7
BSD-2600905039.A39
2600905039
|
£12.04
|
£14.45
|
|
|
14 - FLANGED BEARING
BSD-2605805008.A14
2605805008
|
£5.30
|
£6.36
|
|
|
16 - BRUSH PLATE
BSD-1600A012AZ.A44
1600A012AZ
|
£11.30
|
£13.56
|
|
|
25 - BEARING BOLT
BSD-2603105080.A2
2603105080
|
£2.61
|
£3.13
|
|
|
29 - NEEDLE BEARING
BSD-2600914022.A80
2600914022
|
£6.52
|
£7.83
|
|
|
30 - SHIM 0.5 MM
BSD-2600101048.A62
2600101048
|
£1.75
|
£2.10
|
|
|
32 - SHIM 0.5 MM
BSD-2600101077.A75
2600101077
|
£1.75
|
£2.10
|
|
|
33 - FORK LEVER
BSD-2601923012.A2
2601923012
|
£4.26
|
£5.11
|
|
|
35 - BEARING BOLT
BSD-2603105091.A46
2603105091
|
£2.61
|
£3.13
|
|
|
36 - SHIM 0.5 MM
BSD-2600100588.A85
2600100588
|
£1.75
|
£2.10
|
|
|
37 - COUNTERWEIGHT
BSD-2601098060.A4
2601098060
|
£9.49
|
£11.39
|
|
|
38 - NEEDLE ROLLER 4x15.8 MM
BSD-1903201054.A6
1903201054
|
£1.75
|
£2.10
|
|
|
40 - LIFTING ROD
BSD-2600780147.A2
2600780147
|
-
|
|
|
|
41 - PLAIN BEARING
BSD-2605801038.A10
2605801038
|
£5.30
|
£6.36
|
|
|
42 - COMPRESSION SPRING
BSD-160461201E.A63
160461201E
|
£1.75
|
£2.10
|
|
|
43 - NEEDLE ROLLER
BSD-2603201089.A50
2603201089
|
£5.58
|
£6.70
|
|
|
44 - BEARING BOLT
BSD-2603105084.A5
2603105084
|
£2.16
|
£2.59
|
|
|
45 - BASE PLATE
BSD-2601016080.A12
2601016080
|
-
|
|
|
|
46 - PROFILE BEADING
BSD-2602317037.A4
2602317037
|
-
|
|
|
|
47 - FIXING PLATE
BSD-2600040003.A56
2600040003
|
£2.16
|
£2.59
|
|
|
48 - SOCKET HEAD CAP SCREW
BSD-2603413034.A45
2603413034
|
£1.75
|
£2.10
|
|
|
58 - ROLLER LEVER
BSD-2601321051.A9
2601321051
|
-
|
|
|
|
59 - STRAIGHT PIN
BSD-2609002725.A37
2609002725
|
£1.75
|
£2.10
|
|
|
60 - SEALING PLATE
BSD-2601015077.A4
2601015077
|
£1.75
|
£2.10
|
|
|
64 - RATCHET CAP
BSD-2600590006.A889
2600590006
|
£1.75
|
£2.10
|
|
|
65 - LOCKING ELEMENT
BSD-2601038111.A31
2601038111
|
-
|
|
|
|
69 - SCREW 4x16
BSD-2603490022.A1297
2603490022
|
£1.75
|
£2.10
|
|
|
75 - COVERING HOOD
BSD-2605510169.A17
2605510169
|
-
|
|
|
|
78 - LOCKING PIN
BSD-2603105088.A30
2603105088
|
£1.75
|
£2.10
|
|
|
81 - CONNECTING CABLE L=243 MM
BSD-2604448033.A2
2604448033
|
-
|
|
|
|
82 - CONNECTING CABLE L=220 MM
BSD-2604448232.A2
2604448232
|
£2.16
|
£2.59
|
|
|
219 - SCREW 4x16
BSD-2603490022.A1298
2603490022
|
£1.75
|
£2.10
|
|
|
801 - HOUSING SECTION
BSD-2605104790.A0
2605104790
|
-
|
|
|
|
808 - REFERENCE PLATE
BSD-2601117228.A0
2601117228
|
-
|
|
|
|
816/070 - CARBON-BRUSH SET
BSD-2604321925.A21
2604321925
|
£8.67
|
£10.41
|
|
|
826 - BEARING BRACKET
BSD-2605807936.A4
2605807936
|
-
|
|
|
|
827 - ECCENTRIC COG WHEEL
BSD-2606320904.A3
2606320904
|
-
|
|
|
|
834 - SPRING RETAINING RING DIN 471-4x0.4-FSt
BSD-2916640001.A3
2916640001
|
£1.75
|
£2.10
|
|
|
839 - SPRING RETAINING RING DIN 471-8x0.8 FSt
BSD-2916640005.A3
2916640005
|
£1.75
|
£2.10
|
|
|
891 - CROSS RECESSED-HEAD SCREW M3x5
BSD-2603410046.A144
2603410046
|
£2.16
|
£2.59
|
|
