2 - FIELD 230V
BSD-2604220555.A10
2604220555
|
£14.91
|
£17.89
|
|
|
3 - ARMATURE 220-240V
BSD-2604011007.A1
2604011007
|
-
|
|
|
|
3/60 - FAN
BSD-1606610116.A24
1606610116
|
£2.52
|
£3.02
|
|
|
4 - SWITCH
BSD-2607200260.A59
2607200260
|
£11.30
|
£13.56
|
|
|
5 - ELEC. CABLE W/CONNECTION CH 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460053.A18
2604460053
|
-
|
|
|
|
6 - GROMMET dia6.9 MM
BSD-2600707059.A412
2600707059
|
£3.72
|
£4.47
|
|
|
7 - CABLE CLIP
BSD-2601035001.A513
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601118371.A0
2601118371
|
-
|
|
|
|
12 - SUPPRESSION CAPACITOR
BSD-2607329138.A104
2607329138
|
-
|
|
|
|
13 - GROOVE BALL BEARING 8x19x6
BSD-2600905046.A10
2600905046
|
£11.30
|
£13.56
|
|
|
14 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A594
2600917003
|
£2.80
|
£3.36
|
|
|
16 - BRUSH PLATE
BSD-2609992607.A7
2609992607
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A448
2603410001
|
£1.75
|
£2.10
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1389
2603490022
|
£1.75
|
£2.10
|
|
|
20 - REFERENCE PLATE
BSD-2601118372.A0
2601118372
|
-
|
|
|
|
26 - DAMPING PLATE
BSD-2601022000.A502
2601022000
|
£1.75
|
£2.10
|
|
|
29 - O-RING 5.0x1.5 MM
BSD-1900210000.A480
1900210000
|
£1.75
|
£2.10
|
|
|
30 - INDEXING DISK
BSD-2601990000.A33
2601990000
|
£1.75
|
£2.10
|
|
|
31 - SUPPORTING DISC
BSD-2600100034.A49
2600100034
|
£1.75
|
£2.10
|
|
|
32 - PRESSURE PLATE
BSD-2600025005.A31
2600025005
|
£1.75
|
£2.10
|
|
|
33 - BALL DIN 5401-6 G28
BSD-1903230011.A177
1903230011
|
£2.61
|
£3.13
|
|
|
35 - OVAL-HEAD SCREW DIN 7985-M4x25-8.8
BSD-2910951132.A33
2910951132
|
-
|
|
|
|
38 - SINTERED-METAL BUSHING
BSD-2600301013.A19
2600301013
|
-
|
|
|
|
40 - PRESSURE PLATE
BSD-2601330005.A14
2601330005
|
-
|
|
|
|
41 - DISC SPRING
BSD-2601290014.A48
2601290014
|
£1.75
|
£2.10
|
|
|
42 - SPACER RING
BSD-2600209004.A23
2600209004
|
-
|
|
|
|
46 - CONNECTING CABLE L=162MM
BSD-2604448122.A4
2604448122
|
-
|
|
|
|
47 - CABLE L=98 MM
BSD-2604448045.A118
2604448045
|
-
|
|
|
|
48 - CONNECTING CABLE L=88 MM
BSD-2604448130.A16
2604448130
|
£1.75
|
£2.10
|
|
|
52 - CONNECTING CABLE L=73 MM
BSD-2604448123.A62
2604448123
|
-
|
|
|
|
739 - KEY CHUCK dia1.5-10 MM. 3/8
BSD-1608571053.A43
1608571053
|
£20.99
|
£25.19
|
|
|
739/700 - CHUCK WRENCH SG2
BSD-2607950007.A1587
2607950007
|
£6.52
|
£7.83
|
|
|
780 - AUXILIARY HANDLE dia43 MM
BSD-2602025032.A151
2602025032
|
-
|
|
|
|
801 - HOUSING SECTION
BSD-2605104493.A0
2605104493
|
-
|
|
|
|
813 - NEEDLE BEARING
BSD-2600917901.A7
2600917901
|
-
|
|
|
|
816/04 - CARBON-BRUSH SET
BSD-2604321915.A18
2604321915
|
-
|
|
|
|
816/06 - RATCHET CAP
BSD-2601322017.A156
2601322017
|
£1.75
|
£2.10
|
|
|
816/06 - RATCHET CAP
BSD-2601322013.A57
2601322013
|
£1.75
|
£2.10
|
|
|
834 - BEARING BRACKET
BSD-2605807917.A46
2605807917
|
-
|
|
|
|
836 - DRILLING SPINDLE Z= 45
BSD-2606135908.A2
2606135908
|
-
|
|
|
|
843 - TAPPING SCREW DIN 7981-ST2.9x13-C-H
BSD-2910611006.A123
2910611006
|
£1.75
|
£2.10
|
|
|
888 - NAMEPLATE
BSD-160111A3HC.A14
160111A3HC
|
£2.61
|
£3.13
|
|
