1 - HOUSING SECTION
BSD-2605104185.A0
2605104185
|
-
|
|
|
|
2 - FIELD 220-240V
BSD-2604220423.A9
2604220423
|
£25.68
|
£30.81
|
|
|
3 - ARMATURE 220-240V
BSD-2604010547.A9
2604010547
|
-
|
|
|
|
4 - SWITCH
BSD-2607200084.A21
2607200084
|
£10.10
|
£12.12
|
|
|
8 - SINTERED-METAL BUSHING
BSD-2600301021.A11
2600301021
|
-
|
|
|
|
9 - ADJUSTING SLIDE
BSD-2601020006.A12
2601020006
|
-
|
|
|
|
10 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A387
2600917003
|
£2.94
|
£3.53
|
|
|
11 - SINTERED-METAL BUSHING
BSD-1900301004.A20
1900301004
|
£14.08
|
£16.89
|
|
|
13 - GROMMET dia6.9 MM
BSD-2600707059.A574
2600707059
|
£3.91
|
£4.69
|
|
|
13 - GROMMET dia8.8 MM
BSD-2600707061.A292
2600707061
|
£2.80
|
£3.36
|
|
|
16 - SUPPRESSION CAPACITOR
BSD-2607329095.A43
2607329095
|
-
|
|
|
|
21 - CONNECTING CABLE L=154 MM
BSD-2604448000.A5
2604448000
|
-
|
|
|
|
22 - SUPPRESSOR BOX
BSD-2604465030.A7
2604465030
|
-
|
|
|
|
23 - PRESSURE PLATE 1.5 MM
BSD-1601000013.A47
1601000013
|
-
|
|
|
|
24 - INTERMEDIATE PLATE 0.3 MM
BSD-2601000018.A80
2601000018
|
-
|
|
|
|
25 - BALL DIN 5401-5 G28
BSD-1903230009.A25
1903230009
|
£1.84
|
£2.21
|
|
|
26 - O-RING 8.0x2.5 MM
BSD-1610210014.A373
1610210014
|
-
|
|
|
|
27 - LUBRICATING FELT
BSD-2601020005.A32
2601020005
|
-
|
|
|
|
28 - BALL DIN 5401-6 G28
BSD-1903230011.A25
1903230011
|
£2.74
|
£3.29
|
|
|
29 - INTERMEDIATE PLATE
BSD-2601000032.A19
2601000032
|
-
|
|
|
|
32 - MANUFACTURER'S NAMEPLATE
BSD-2601110470.A3
2601110470
|
-
|
|
|
|
33 - DAMPING PLATE
BSD-2601022000.A631
2601022000
|
£1.75
|
£2.10
|
|
|
34 - TORX OVAL-HEAD SCREW 3x18
BSD-2603490018.A101
2603490018
|
£1.75
|
£2.10
|
|
|
35 - TAPPING SCREW DIN 7981-ST3.9x16-C-H
BSD-2910611019.A156
2910611019
|
£2.94
|
£3.53
|
|
|
36 - TORX OVAL-HEAD SCREW 4x30
BSD-2603490025.A243
2603490025
|
£1.84
|
£2.21
|
|
|
37 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1204
2603410001
|
£1.84
|
£2.21
|
|
|
38 - KEY CHUCK dia1.5-10 MM. 3/8
BSD-1608571053.A63
1608571053
|
£20.99
|
£25.19
|
|
|
38/800 - CHUCK WRENCH SG2
BSD-2607950007.A1190
2607950007
|
£6.85
|
£8.22
|
|
|
39 - CABLE CLIP
BSD-2601035001.A1402
2601035001
|
£1.84
|
£2.21
|
|
|
40 - PRESSURE PLATE 0.5 MM
BSD-2601000019.A6
2601000019
|
-
|
|
|
|
41 - SHIM 0.3 MM
BSD-2600101604.A37
2600101604
|
-
|
|
|
|
41 - SHIM dia14.5x21.5x0.5 MM
BSD-2000101600.A56
2000101600
|
-
|
|
|
|
41 - SHIM 0.2 MM
BSD-2600101613.A0
2600101613
|
-
|
|
|
|
42 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A750
2915011007
|
-
|
|
|
|
44 - PRESSURE PLATE 1.5 MM
BSD-2601074001.A14
2601074001
|
-
|
|
|
|
45 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A580
2912401020
|
£2.16
|
£2.59
|
|
|
49 - BRUSH HOLDER
BSD-2604330016.A39
2604330016
|
-
|
|
|
|
51 - DISC SPRING
BSD-2601290014.A12
2601290014
|
£1.84
|
£2.21
|
|
|
52 - BALL 2 MM III DIN 5401 ST
BSD-1903230002.A8
1903230002
|
£2.27
|
£2.72
|
|
|
55 - FAN
BSD-2606610047.A35
2606610047
|
-
|
|
|
|
56 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A580
1900452012
|
£1.75
|
£2.10
|
|
|
805 - BEARING BRACKET
BSD-2605807901.A23
2605807901
|
-
|
|
|
|
806 - DRILLING SPINDLE SW 10
BSD-2606135903.A6
2606135903
|
-
|
|
|
|
817 - CARBON-BRUSH SET
BSD-2604321904.A92
2604321904
|
£10.61
|
£12.73
|
|
|
835 - POWER SUPPLY CORD EU 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1607000386.A76
1607000386
|
£22.60
|
£27.12
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A2581
160111A3H3
|
£2.74
|
£3.29
|
|
