1 - HOUSING SECTION
BSD-2609002944.A6
2609002944
|
-
|
|
|
|
2 - FIELD 230V
BSD-2604220669.A21
2604220669
|
£21.68
|
£26.01
|
|
|
3 - ARMATURE 230V
BSD-2609002946.A0
2609002946
|
£40.80
|
£48.96
|
|
|
4 - SWITCH
BSD-1607200518.A7
1607200518
|
£21.68
|
£26.01
|
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2609003080.A20
2609003080
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE PSB 850-2 RE
BSD-2609002966.A0
2609002966
|
£2.61
|
£3.13
|
|
|
9 - MANUFACTURER'S NAMEPLATE PSB 850-2 RA
BSD-2609002968.A1
2609002968
|
£2.45
|
£2.94
|
|
|
16 - BRUSH HOLDER
BSD-2609002949.A3
2609002949
|
£11.78
|
£14.13
|
|
|
21 - SCREW 4x16
BSD-2603490022.A803
2603490022
|
£1.84
|
£2.21
|
|
|
23 - O-RING 5.0x1.5 MM
BSD-1900210000.A405
1900210000
|
£1.84
|
£2.21
|
|
|
24 - COVER PANEL
BSD-2609002956.A0
2609002956
|
£3.72
|
£4.47
|
|
|
28 - COVER
BSD-2609002957.A14
2609002957
|
£11.87
|
£14.24
|
|
|
29 - SCREW 4x16
BSD-2603490022.A804
2603490022
|
£1.84
|
£2.21
|
|
|
30 - DRILLING SPINDLE
BSD-2606135130.A34
2606135130
|
£21.68
|
£26.01
|
|
|
31 - KEYLESS CHUCK
BSD-2609003251.A5
2609003251
|
£47.95
|
£57.54
|
|
|
32 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A485
1900905163
|
£11.30
|
£13.56
|
|
|
33 - SPRING RETAINING RING DIN 471 17x1 MM
BSD-2916650008.A433
2916650008
|
£1.84
|
£2.21
|
|
|
35 - SHIM 0.5 MM
BSD-2600100695.A249
2600100695
|
£1.84
|
£2.21
|
|
|
36 - CYLINDRICAL GEAR
BSD-2606317084.A0
2606317084
|
£13.78
|
£16.54
|
|
|
37 - CYLINDRICAL GEAR
BSD-2606317085.A17
2606317085
|
£10.61
|
£12.73
|
|
|
38 - CATCH DISK
BSD-2600190105.A11
2600190105
|
£2.74
|
£3.29
|
|
|
39 - COMPRESSION SPRING
BSD-2604616013.A88
2604616013
|
£2.74
|
£3.29
|
|
|
42 - SHIM WASHER 1.0 MM
BSD-2600000021.A19
2600000021
|
£1.84
|
£2.21
|
|
|
42 - SHIM WASHER 1.35 MM
BSD-2600000030.A113
2600000030
|
£1.75
|
£2.10
|
|
|
42 - SHIM WASHER 1.7 MM
BSD-2600000031.A21
2600000031
|
£1.75
|
£2.10
|
|
|
43 - BALL DIN 5401-5 G28
BSD-1903230009.A374
1903230009
|
£1.84
|
£2.21
|
|
|
43 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A443
1903230010
|
£1.84
|
£2.21
|
|
|
43 - BALL 5.25 MM
BSD-2603230007.A11
2603230007
|
£1.75
|
£2.10
|
|
|
44 - SHIM 0.3 MM
BSD-2600100607.A788
2600100607
|
£1.75
|
£2.10
|
|
|
46 - CARRIER
BSD-160312304U.A25
160312304U
|
£13.78
|
£16.54
|
|
|
47 - ECCENTRIC
BSD-2602210043.A11
2602210043
|
£2.80
|
£3.36
|
|
|
48 - SHIM 0.2 MM
BSD-1600100632.A95
1600100632
|
£1.84
|
£2.21
|
|
|
49 - ROLLER BODY
BSD-2609007376.A26
2609007376
|
£1.84
|
£2.21
|
|
|
50 - RETAINING SNAP RING
BSD-2600202008.A16
2600202008
|
£4.48
|
£5.37
|
|
|
52 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A840
2600914010
|
£2.94
|
£3.53
|
|
|
54 - ROTARY KNOB
BSD-2609002959.A0
2609002959
|
£4.48
|
£5.37
|
|
|
62 - RATCHET CAP
BSD-2600590006.A969
2600590006
|
£1.84
|
£2.21
|
|
|
63 - TORSION SPRING
BSD-2609004109.A16
2609004109
|
£1.84
|
£2.21
|
|
|
64 - O-RING 14.0x1.3 MM
BSD-3600210014.A8
3600210014
|
£1.84
|
£2.21
|
|
|
65 - FORK LEVER
BSD-2609002961.A16
2609002961
|
£2.27
|
£2.72
|
|
|
66 - RETAINING WASHER
BSD-2600101671.A284
2600101671
|
£1.84
|
£2.21
|
|
|
67 - FLAT KEY
BSD-2602300032.A118
2602300032
|
£3.72
|
£4.47
|
|
|
69 - CHANGEOVER LEVER
BSD-2609002962.A0
2609002962
|
£2.27
|
£2.72
|
|
|
70 - GUIDING PLATE
BSD-2601990044.A11
2601990044
|
£1.75
|
£2.10
|
|
|
71 - RATCHET CAP
BSD-2600590006.A970
2600590006
|
£1.84
|
£2.21
|
|
|
72 - SHUT-OFF VALVE
BSD-2609002963.A14
2609002963
|
£4.48
|
£5.37
|
|
|
75 - CHANGE-OVER SWITCH
BSD-2609002954.A0
2609002954
|
£2.27
|
£2.72
|
|
|
77 - INDICATOR BUTTON
BSD-2609002955.A14
2609002955
|
£2.74
|
£3.29
|
|
|
82 - LEAF SPRING
BSD-2601290030.A9
2601290030
|
£1.75
|
£2.10
|
|
|
654 - AUXILIARY HANDLE
BSD-2609002967.A14
2609002967
|
£12.64
|
£15.17
|
|
|
655 - DEPTH-GAUGE
BSD-2609005615.A16
2609005615
|
£4.48
|
£5.37
|
|
|
656/9 - FILTER
BSD-2609002929.A17
2609002929
|
£7.36
|
£8.83
|
|
|
656/14 - LOCK
BSD-2609003805.A30
2609003805
|
£2.16
|
£2.59
|
|
|
656/810 - DUST CONTAINER
BSD-2609003983.A1
2609003983
|
-
|
|
|
|
656/812 - FRICTION RING
BSD-2600206003.A22
2600206003
|
£2.64
|
£3.17
|
|
|
805 - POWER SUPPLY CORD CN 2.65m 2 x 0.75mm H05 W-F
BSD-1607000387.A34
1607000387
|
£11.30
|
£13.56
|
|
|
808 - NAMEPLATE
BSD-2609003474.A0
2609003474
|
£2.74
|
£3.29
|
|
|
810 - CARBON-BRUSH SET
BSD-2609004163.A8
2609004163
|
£9.11
|
£10.93
|
|
|
845 - TRANSMISSION
BSD-2606309940.A22
2606309940
|
£21.52
|
£25.83
|
|
|
860 - BEARING BRACKET
BSD-2609002984.A14
2609002984
|
£22.76
|
£27.31
|
|
|
890 - FASTENING PARTS KIT
BSD-2607001305.A27
2607001305
|
£4.48
|
£5.37
|
|
