1 - HOUSING SECTION
BSD-2605105081.A1
2605105081
|
£19.45
|
£23.34
|
|
|
2 - FIELD 230V
BSD-2604220710.A8
2604220710
|
£21.68
|
£26.01
|
|
|
3 - ARMATURE 230V
BSD-2604011339.A2
2604011339
|
£48.38
|
£58.06
|
|
|
4 - SWITCH
BSD-2607200627.A1
2607200627
|
£21.42
|
£25.71
|
|
|
5 - POWER SUPPLY CORD CH 4.15m 2 x 1.00mm H05 VV-F
BSD-2609001354.A1
2609001354
|
£11.78
|
£14.13
|
|
|
6 - GROMMET
BSD-2609002019.A133
2609002019
|
£2.61
|
£3.13
|
|
|
9 - MANUFACTURER'S NAMEPLATE PSB 1000-2 RCA
BSD-2601116999.A1
2601116999
|
£3.72
|
£4.47
|
|
|
16 - BRUSH PLATE
BSD-2604337061.A57
2604337061
|
£14.91
|
£17.89
|
|
|
21 - TAPPING SCREW DIN 7981-ST2.2x9.5-C-H
BSD-2910611002.A284
2910611002
|
£1.75
|
£2.10
|
|
|
22 - SCREW 4x16
BSD-2603490022.A798
2603490022
|
£1.75
|
£2.10
|
|
|
23 - O-RING 5.0x1.5 MM
BSD-1900210000.A406
1900210000
|
£1.75
|
£2.10
|
|
|
24 - SPEED GOVERNOR 230-240V
BSD-2607230108.A2
2607230108
|
£41.62
|
£49.95
|
|
|
25 - RETAINING ELEMENT
BSD-2609001536.A1
2609001536
|
£1.75
|
£2.10
|
|
|
27 - REVERSING SWITCH
BSD-2609001247.A8
2609001247
|
-
|
|
|
|
30 - DRILLING SPINDLE
BSD-2606135130.A37
2606135130
|
£21.68
|
£26.01
|
|
|
32 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A484
1900905163
|
£11.30
|
£13.56
|
|
|
33 - SPRING RETAINING RING DIN 471 17x1 MM
BSD-2916650008.A430
2916650008
|
£1.75
|
£2.10
|
|
|
34 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A288
2916660014
|
£1.75
|
£2.10
|
|
|
35 - SHIM 0.5 MM
BSD-2600100695.A250
2600100695
|
£1.75
|
£2.10
|
|
|
36 - CYLINDRICAL GEAR
BSD-2606317084.A3
2606317084
|
£13.12
|
£15.75
|
|
|
37 - CYLINDRICAL GEAR
BSD-2606317098.A100
2606317098
|
£12.04
|
£14.45
|
|
|
38 - CATCH DISK
BSD-2600190105.A12
2600190105
|
£2.61
|
£3.13
|
|
|
39 - COMPRESSION SPRING
BSD-2604616013.A86
2604616013
|
£2.61
|
£3.13
|
|
|
42 - SHIM WASHER 1.0 MM
BSD-2600000021.A20
2600000021
|
£1.75
|
£2.10
|
|
|
42 - SHIM WASHER 1.35 MM
BSD-2600000030.A112
2600000030
|
£1.75
|
£2.10
|
|
|
42 - SHIM WASHER 1.7 MM
BSD-2600000031.A22
2600000031
|
£1.75
|
£2.10
|
|
|
43 - BALL DIN 5401-5 G28
BSD-1903230009.A375
1903230009
|
£1.75
|
£2.10
|
|
|
43 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A442
1903230010
|
£1.75
|
£2.10
|
|
|
43 - BALL 5.25 MM
BSD-2603230007.A10
2603230007
|
£1.75
|
£2.10
|
|
|
44 - SHIM 0.2 MM
BSD-1600100632.A93
1600100632
|
£1.75
|
£2.10
|
|
|
46 - CARRIER
BSD-160312304U.A27
160312304U
|
£13.12
|
£15.75
|
|
|
47 - ECCENTRIC
BSD-2602210043.A9
2602210043
|
£2.80
|
£3.36
|
|
|
48 - SHIM 0.3 MM
BSD-2600100607.A787
2600100607
|
£1.75
|
£2.10
|
|
|
49 - ROLLER BODY
BSD-2609007376.A28
2609007376
|
£1.75
|
£2.10
|
|
|
50 - RETAINING SNAP RING
BSD-2600202008.A15
2600202008
|
£4.26
|
£5.11
|
|
|
63 - HOLDING PLATE
BSD-2601328003.A1
2601328003
|
£1.32
|
£1.58
|
|
|
64 - LINK GUIDE
BSD-2602033017.A7
2602033017
|
£1.75
|
£2.10
|
|
|
65 - FORK LEVER
BSD-2601990045.A1
2601990045
|
£1.75
|
£2.10
|
|
|
66 - RETAINING WASHER
BSD-2600101671.A283
2600101671
|
£1.75
|
£2.10
|
|
|
67 - FLAT KEY
BSD-2602300032.A120
2602300032
|
£3.72
|
£4.47
|
|
|
68 - COMPRESSION SPRING
BSD-2604616014.A1
2604616014
|
£1.75
|
£2.10
|
|
|
69 - ROTARY KNOB
BSD-2602026137.A1
2602026137
|
£3.34
|
£4.01
|
|
|
70 - O-RING 15.6x1.8 MM
BSD-3600210003.A117
3600210003
|
£1.75
|
£2.10
|
|
|
71 - RATCHET CAP
BSD-2600590006.A968
2600590006
|
£1.75
|
£2.10
|
|
|
75 - EXTENSION SPRING
BSD-2604690042.A1
2604690042
|
£1.32
|
£1.58
|
|
|
78 - CONTACT STRAP
BSD-2601329043.A37
2601329043
|
£1.32
|
£1.58
|
|
|
80 - GUIDING PLATE
BSD-2601990044.A8
2601990044
|
£1.75
|
£2.10
|
|
|
81 - CHANGEOVER LEVER
BSD-2602098021.A1
2602098021
|
£1.75
|
£2.10
|
|
|
82 - LEAF SPRING
BSD-2601290030.A7
2601290030
|
£1.75
|
£2.10
|
|
|
83 - COMPRESSION SPRING
BSD-2604610056.A1
2604610056
|
£1.75
|
£2.10
|
|
|
84 - BOLT
BSD-2603105115.A0
2603105115
|
£1.75
|
£2.10
|
|
|
85 - SEALING CAP
BSD-2605510222.A1
2605510222
|
£1.75
|
£2.10
|
|
|
90 - HEADLESS SCREW
BSD-2603435087.A0
2603435087
|
£1.75
|
£2.10
|
|
|
91 - THREAD-FORMING TAP. SCREW
BSD-2603435088.A8
2603435088
|
-
|
|
|
|
92 - PVC-INSULATED CABLE L=120 MM
BSD-2604448228.A108
2604448228
|
£2.16
|
£2.59
|
|
|
93 - AIR PATH
BSD-2601328077.A8
2601328077
|
£1.75
|
£2.10
|
|
|
94 - REFERENCE PLATE
BSD-2601116906.A2
2601116906
|
-
|
|
|
|
95 - PICKUP CLIP
BSD-2601250010.A2
2601250010
|
£1.32
|
£1.58
|
|
|
657/1 - FRICTION RING
BSD-2600206003.A25
2600206003
|
£2.52
|
£3.02
|
|
|
808 - NAMEPLATE
BSD-2601115038.A0
2601115038
|
£3.34
|
£4.01
|
|
|
829 - GEAR HOUSING
BSD-2605806887.A2
2605806887
|
£33.74
|
£40.49
|
|
|
831 - KEYLESS CHUCK HSB 4
BSD-2608572143.A1
2608572143
|
£63.50
|
£76.20
|
|
|
845 - TRANSMISSION
BSD-2606309940.A18
2606309940
|
£21.52
|
£25.83
|
|
|
855 - HANDLE
BSD-2602025904.A4
2602025904
|
-
|
|
|
|
860 - BEARING BRACKET
BSD-2605807940.A0
2605807940
|
£37.27
|
£44.72
|
|
|
872 - CONTROL LEVER
BSD-2602099900.A1
2602099900
|
£4.75
|
£5.70
|
|
|
877 - ROCKER
BSD-2602123902.A1
2602123902
|
£5.87
|
£7.04
|
|
|
880 - BOX
BSD-2605190921.A4
2605190921
|
£9.49
|
£11.39
|
|
|
883 - FILTER
BSD-2607030901.A4
2607030901
|
-
|
|
|
|
890 - FASTENING PARTS KIT
BSD-2607001305.A25
2607001305
|
£4.26
|
£5.11
|
|
