1 - HOUSING SECTION
BSD-2605104344.A0
2605104344
|
-
|
|
|
|
2 - FIELD 220-240V
BSD-1604220254.A79
1604220254
|
£22.76
|
£27.31
|
|
|
3 - ARMATURE 230-240V
BSD-2604010863.A1
2604010863
|
-
|
|
|
|
3/60 - FAN
BSD-2606610029.A117
2606610029
|
£2.74
|
£3.29
|
|
|
4 - ON-OFF SWITCH
BSD-2607200282.A1
2607200282
|
-
|
|
|
|
5 - POWER SUPPLY CORD CH 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1604460432.A86
1604460432
|
£11.87
|
£14.24
|
|
|
6 - GROMMET dia6.9 MM
BSD-2600707059.A544
2600707059
|
£3.91
|
£4.69
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1453
2601035001
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601118149.A1
2601118149
|
-
|
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601118151.A0
2601118151
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329114.A50
2607329114
|
-
|
|
|
|
16 - BRUSH PLATE
BSD-2605807060.A132
2605807060
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1219
2603410001
|
£1.84
|
£2.21
|
|
|
19 - TAPPING SCREW DIN 7981-ST3.9x16-C-H
BSD-2910611019.A178
2910611019
|
£2.94
|
£3.53
|
|
|
20 - REFERENCE PLATE
BSD-2601118150.A0
2601118150
|
-
|
|
|
|
21 - INSERT PIECE
BSD-2605190019.A1
2605190019
|
-
|
|
|
|
22 - INSERT PIECE
BSD-2605190020.A2
2605190020
|
-
|
|
|
|
24 - PLUG
BSD-2603126011.A1
2603126011
|
-
|
|
|
|
25 - CONTROL UNIT
BSD-2607230018.A1
2607230018
|
-
|
|
|
|
27 - TAPPING SCREW DIN 7981-B2.9x16-C-H
BSD-2910611007.A47
2910611007
|
£1.84
|
£2.21
|
|
|
28 - SOCKET HEAD CAP SCREW DIN 84-BM4x30-8.8
BSD-2910021134.A31
2910021134
|
£1.75
|
£2.10
|
|
|
29 - DAMPING PLATE
BSD-2601022000.A662
2601022000
|
£1.75
|
£2.10
|
|
|
30 - DRILLING SPINDLE 1/2
BSD-2606135045.A2
2606135045
|
-
|
|
|
|
31 - LOCKING WASHER 0.6 MM
BSD-2600118001.A66
2600118001
|
£1.75
|
£2.10
|
|
|
31 - LOCKING WASHER 0.8 MM
BSD-2600118002.A135
2600118002
|
£1.84
|
£2.21
|
|
|
31 - LOCKING WASHER 0.3 MM
BSD-2600118006.A93
2600118006
|
-
|
|
|
|
32 - COMPRESSION SPRING
BSD-2604617000.A224
2604617000
|
£2.61
|
£3.13
|
|
|
33 - GROOVE BALL BEARING 15x32x9
BSD-1900905122.A48
1900905122
|
£10.61
|
£12.73
|
|
|
34 - CYLINDRICAL GEAR Z=37
BSD-2606320047.A1
2606320047
|
-
|
|
|
|
35 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A681
1903230010
|
£1.84
|
£2.21
|
|
|
36 - INDEXING DISK
BSD-2601990003.A2
2601990003
|
-
|
|
|
|
37 - PRESSURE PLATE
BSD-2601074003.A7
2601074003
|
£1.75
|
£2.10
|
|
|
38 - MAGNET
BSD-2600239018.A1
2600239018
|
-
|
|
|
|
39 - CONTROL LEVER
BSD-2602099006.A1
2602099006
|
-
|
|
|
|
41 - CATCH DISK
BSD-2600190057.A122
2600190057
|
-
|
|
|
|
42 - NEEDLE BEARING
BSD-2600917902.A136
2600917902
|
-
|
|
|
|
43 - FELT DISC
BSD-2600108000.A275
2600108000
|
-
|
|
|
|
44 - CUPPED WASHER
BSD-2600500014.A107
2600500014
|
-
|
|
|
|
45 - O-RING 18x3 MM
BSD-1900210117.A2
1900210117
|
£3.91
|
£4.69
|
|
|
46 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A1002
2916660008
|
£2.16
|
£2.59
|
|
|
48 - RECEPTACLE
BSD-2600400008.A372
2600400008
|
£1.75
|
£2.10
|
|
|
50 - O-RING 5.0x1.5 MM
BSD-1900210000.A526
1900210000
|
£1.84
|
£2.21
|
|
|
51 - FELT STRIP
BSD-2601005011.A55
2601005011
|
-
|
|
|
|
52 - ECCENTRIC
BSD-2602210011.A2
2602210011
|
-
|
|
|
|
53 - CONNECTING CABLE L=184 MM
BSD-2604448001.A104
2604448001
|
£2.05
|
£2.46
|
|
|
54 - CONNECTING CABLE L=85 MM
BSD-2604448147.A35
2604448147
|
£1.84
|
£2.21
|
|
|
55 - CONNECTING CABLE L=115MM
BSD-2604448096.A55
2604448096
|
-
|
|
|
|
56 - CONNECTING CABLE L=88 MM
BSD-2604448034.A309
2604448034
|
£1.75
|
£2.10
|
|
|
57 - EARTH CONDUCTOR
BSD-2604448103.A110
2604448103
|
-
|
|
|
|
59 - FLYWHEEL
BSD-2600327006.A2
2600327006
|
-
|
|
|
|
60 - COMPRESSION SPRING dia 1.2 MM
BSD-2604619011.A1
2604619011
|
-
|
|
|
|
61 - COUNTERSUNK-HEAD SCREW M 6x33 MM
BSD-2603421212.A1
2603421212
|
-
|
|
|
|
753 - AUXILIARY HANDLE dia43 MM
BSD-1619P10682.A324
1619P10682
|
£12.49
|
£14.99
|
|
|
753/20 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A690
2915011007
|
-
|
|
|
|
753/30 - WING SCREW M6x(15)55
BSD-1613480007.A334
1613480007
|
£1.75
|
£2.10
|
|
|
753/50 - CLAMPING PLATE M6
BSD-2608040014.A286
2608040014
|
-
|
|
|
|
753/60 - WING SCREW M6x20 MM
BSD-1613480008.A76
1613480008
|
£1.84
|
£2.21
|
|
|
755 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001005.A39
1613001005
|
-
|
|
|
|
756 - DRILL HOLDER
BSD-2607000122.A221
2607000122
|
-
|
|
|
|
813 - NEEDLE BEARING
BSD-2600917902.A135
2600917902
|
-
|
|
|
|
814 - GROOVE BALL BEARING 9x24x7
BSD-2600905039.A104
2600905039
|
£12.64
|
£15.17
|
|
|
816/01/40 - CARBON-BRUSH SET
BSD-2604321905.A323
2604321905
|
£11.87
|
£14.24
|
|
|
816/01/60 - RATCHET CAP
BSD-2601322013.A188
2601322013
|
£1.84
|
£2.21
|
|
|
826 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A619
2912401020
|
£2.16
|
£2.59
|
|
|
840 - BEARING BRACKET
BSD-2605807923.A3
2605807923
|
-
|
|
|
|
858 - CHUCK dia1.5-13 MM.1/2
BSD-1608571087.A2
1608571087
|
-
|
|
|
|
858/800 - CHUCK WRENCH SG2
BSD-2607950007.A1132
2607950007
|
£6.85
|
£8.22
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A2668
160111A3H3
|
£2.74
|
£3.29
|
|
