Bosch PWS 600 / 0603400032 / CH 230 Volt Spare Parts

An exploded drawing and listing for the Bosch PWS 600 / 0603400032 / CH 230 Volt

	Ex VAT	Inc VAT
5 - POWER SUPPLY CORD CH 230V 4.15m 2 x 1.0mm H05 RN-F BSD-1604460432.A66 1604460432	£11.87	£14.24
6 - GROMMET dia6.5-dia6.9x95 MM BSD-2600703012.A1357 2600703012	£2.94	£3.53
9 - MANUFACTURER'S NAMEPLATE BSD-1601118853.A4 1601118853	-
22 - ADJUSTING SLIDE BSD-1602319014.A0 1602319014	-
23 - SWITCH HANDLE BSD-1602026077.A61 1602026077	£1.75	£2.10
24 - COMPRESSION SPRING BSD-1604611026.A732 1604611026	£1.84	£2.21
26 - RUBBER BUSHING BSD-1600502020.A148 1600502020	£2.74	£3.29
28 - BALL BEARING BSD-1600905021.A16 1600905021	-
50 - TORX OVAL-HEAD SCREW 4x20 BSD-1619P00105.A80 1619P00105	£1.75	£2.10
51 - SCREW BSD-1619P00106.A13 1619P00106	£1.84	£2.21
105 - INTERMEDIATE PLATE BSD-1600591034.A77 1600591034	-
652 - PROTECTIVE GUARD BSD-2609000390.A14 2609000390	£13.12	£15.75
801 - AUXILIARY HANDLE M10. dia32.5x105 MM BSD-160202509T.A660 160202509T	£3.91	£4.69
802 - PIN-TYPE FACE-WRENCH BSD-1619P08927.A196 1619P08927	£4.26	£5.11
803 - CLAMPING FLANGE dia22.3xdia42 MM BSD-2605703014.A529 2605703014	£7.72	£9.27
803 - CLAMPING FLANGE dia 22.3 MM BSD-1605703119.A2 1605703119	-
804 - O-RING 20.35x1.78 MM BSD-1600210039.A1048 1600210039	£2.27	£2.72
805 - ROUND NUT M14 BSD-1603345043.A1372 1603345043	£9.11	£10.93
806 - CARBON-BRUSH SET BSD-1607000994.A24 1607000994	-
808 - NAMEPLATE BSD-1619P00517.A0 1619P00517	-
810 - MOTOR HOUSING BSD-1607000371.A17 1607000371	-
811 - FIELD 230-240V BSD-1607000723.A25 1607000723	-
818 - SPINDLE HOLDER BSD-1607000993.A7 1607000993	-
830 - ARMATURE 230-240V BSD-1607000990.A23 1607000990	£22.50	£27.00
832 - GRINDING SPINDLE M14 BSD-1607000992.A18 1607000992	-

Attribute Name	Value
Brand	Bosch
