1 - MOTOR HOUSING
BSD-1605108127.A50
1605108127
|
-
|
|
|
|
2 - FIELD 230-240V
BSD-1604220224.A12
1604220224
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-1607200086.A206
1607200086
|
£11.30
|
£13.56
|
|
|
5 - POWER SUPPLY CORD EU 2.65m 2 x 1.0mm H05RN-F
BSD-1604460135.A10
1604460135
|
-
|
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1415
2600703012
|
£2.80
|
£3.36
|
|
|
6 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A111
2600703013
|
£2.61
|
£3.13
|
|
|
7 - FASTENING CLAMP
BSD-1601302017.A1111
1601302017
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601110472.A4
1601110472
|
-
|
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A1189
2600905032
|
£5.30
|
£6.36
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-1600905011.A135
1600905011
|
£5.58
|
£6.70
|
|
|
15 - FAN
BSD-1606610121.A157
1606610121
|
£1.75
|
£2.10
|
|
|
17 - MANUFACTURER'S NAMEPLATE
BSD-1601110783.A15
1601110783
|
-
|
|
|
|
18 - COMPRESSION SPRING
BSD-1604611026.A688
1604611026
|
£1.75
|
£2.10
|
|
|
22 - ADJUSTING SLIDE
BSD-1602319002.A121
1602319002
|
£2.61
|
£3.13
|
|
|
23 - SWITCH HANDLE
BSD-1602026057.A403
1602026057
|
£1.97
|
£2.36
|
|
|
25 - HOUSING COVER
BSD-1600508009.A1
1600508009
|
-
|
|
|
|
26 - RUBBER BUSHING
BSD-1600502020.A43
1600502020
|
£2.61
|
£3.13
|
|
|
27 - RUBBER RING
BSD-1600206025.A953
1600206025
|
£2.16
|
£2.59
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1601328005.A105
1601328005
|
£2.61
|
£3.13
|
|
|
31 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A59
2916660013
|
£2.16
|
£2.59
|
|
|
33 - O-RING 46.0x1.1 MM
BSD-3600210124.A291
3600210124
|
£2.80
|
£3.36
|
|
|
35 - SHIM 0.2 MM
BSD-1600136010.A196
1600136010
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.3 MM
BSD-1600136011.A133
1600136011
|
£2.16
|
£2.59
|
|
|
35 - SHIM 0.1 MM
BSD-1600136012.A190
1600136012
|
£1.75
|
£2.10
|
|
|
36 - SPRING WASHER
BSD-1600150011.A232
1600150011
|
£1.75
|
£2.10
|
|
|
37 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A93
1600290016
|
£2.61
|
£3.13
|
|
|
38 - CROWN GEAR Z=36
BSD-1606333601.A95
1606333601
|
£8.49
|
£10.19
|
|
|
39 - SPIRAL SPRING
BSD-1604652013.A1022
1604652013
|
£1.75
|
£2.10
|
|
|
40 - SPRING RETAINING RING DIN 472-25x1.2MM
BSD-2916660009.A26
2916660009
|
£2.16
|
£2.59
|
|
|
41 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A612
1600910018
|
£5.30
|
£6.36
|
|
|
42 - GROOVE BALL BEARING 12x32x10
BSD-1600905006.A68
1600905006
|
£12.04
|
£14.45
|
|
|
43 - BEVEL GEAR Z=11
BSD-1606333242.A134
1606333242
|
£48.38
|
£58.06
|
|
|
45 - HEX NUT M7. SW10
BSD-1603300016.A349
1603300016
|
£1.75
|
£2.10
|
|
|
47 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A150
2910211018
|
£1.75
|
£2.10
|
|
|
48 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A175
2910211005
|
£1.75
|
£2.10
|
|
|
49 - SOCKET HEAD CAP SCREW M4x15 MM
BSD-1603412008.A6
1603412008
|
-
|
|
|
|
50 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A977
2910211021
|
£1.75
|
£2.10
|
|
|
51 - SPEED GOVERNOR 230-240V
BSD-1607233024.A1
1607233024
|
-
|
|
|
|
54 - CONNECTING CABLE L=40 MM
BSD-1604448006.A1
1604448006
|
£2.61
|
£3.13
|
|
|
54/20 - RECEPTACLE B2.8-1DIN46 247BZ-BD
BSD-1904478007.A1
1904478007
|
-
|
|
|
|
55 - TAPPING SCREW DIN7981-ST3.9x22-C-Z
BSD-2912401021.A86
2912401021
|
£1.75
|
£2.10
|
|
|
107 - O-RING 4.5x1.0 MM
BSD-1600210044.A337
1600210044
|
£1.75
|
£2.10
|
|
|
650/10 - AUXILIARY HANDLE M10. dia32.5x105 MM
BSD-160202509T.A502
160202509T
|
£3.72
|
£4.47
|
|
|
650/30 - PIN-TYPE FACE-WRENCH
BSD-1607950052.A410
1607950052
|
£3.72
|
£4.47
|
|
|
650/50 - CLAMPING-FLANGE dia22.2x42 MM
BSD-1605703099.A311
1605703099
|
£7.45
|
£8.94
|
|
|
650/50/20 - O-RING 20.35x1.78 MM
BSD-1600210039.A1002
1600210039
|
£2.16
|
£2.59
|
|
|
652/20 - SOCKET HEAD CAP SCREW DIN 84-M 6x16-8.8
BSD-2910022197.A217
2910022197
|
-
|
|
|
|
700 - SUCTION HOOD dia 125 MM
BSD-2605510066.A0
2605510066
|
-
|
|
|
|
700/10 - PROTECTIVE COVER dia 115 MM
BSD-1605510201.A23
1605510201
|
-
|
|
|
|
700/10/20 - SOCKET HEAD CAP SCREW DIN 84-M 6x16-8.8
BSD-2910022197.A216
2910022197
|
-
|
|
|
|
700/20 - GUIDE BLOCK
BSD-1608135004.A55
1608135004
|
-
|
|
|
|
700/20/30 - ROUND-HEAD BOLT DIN 603-M 5x16
BSD-2910281158.A41
2910281158
|
-
|
|
|
|
700/20/40 - WING NUT M 5 DIN 315-G-5
BSD-2915191105.A25
2915191105
|
-
|
|
|
|
700/20/50 - COMPRESSION SPRING
BSD-1604643004.A57
1604643004
|
-
|
|
|
|
700/30 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A31
1907950006
|
£4.26
|
£5.11
|
|
|
750/20 - ROUND NUT M14
BSD-1603340015.A27
1603340015
|
£3.87
|
£4.64
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014116.A205
1607014116
|
£11.30
|
£13.56
|
|
|
813 - PUSH-BUTTON
BSD-1607000253.A291
1607000253
|
£2.49
|
£2.99
|
|
|
816 - BRUSH HOLDER
BSD-1600A003G4.A343
1600A003G4
|
£3.72
|
£4.47
|
|
|
821 - GEAR HOUSING
BSD-1605806480.A66
1605806480
|
£48.38
|
£58.06
|
|
|
828 - BEARING FLANGE
BSD-1607000936.A1
1607000936
|
£27.23
|
£32.68
|
|
|
830 - ARMATURE WITH FAN 230-240V
BSD-1604010259.A19
1604010259
|
-
|
|
|
|
832 - GRINDING SPINDLE
BSD-1607000D6A.A401
1607000D6A
|
£7.36
|
£8.83
|
|
|
870 - PROTECTIVE COVER dia 115 MM(4 1/2)
BSD-2605510125.A76
2605510125
|
£27.23
|
£32.68
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A2525
160111A3H3
|
£2.61
|
£3.13
|
|
