1 - MOTOR HOUSING
BSD-1605108127.A37
1605108127
|
-
|
|
|
|
2 - FIELD 240V
BSD-1604220257.A2
1604220257
|
-
|
|
|
|
3/50 - FAN
BSD-1606610121.A173
1606610121
|
£1.75
|
£2.10
|
|
|
4 - ON-OFF SWITCH
BSD-1607200086.A198
1607200086
|
£11.30
|
£13.56
|
|
|
4/10 - PAN HEAD SCREW DIN 85-AM3x6-CUZN
BSD-2910110048.A478
2910110048
|
£1.75
|
£2.10
|
|
|
5 - POWER SUPPLY CORD GB 240V 2.65m 2 x 1.0mm H05 VV-F
BSD-1604460150.A10
1604460150
|
£16.41
|
£19.69
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1406
2600703012
|
£2.80
|
£3.36
|
|
|
7 - FASTENING CLAMP
BSD-1601302017.A1097
1601302017
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601110475.A9
1601110475
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328029.A54
1607328029
|
-
|
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A1178
2600905032
|
£5.30
|
£6.36
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-1600905032.A459
1600905032
|
£5.58
|
£6.70
|
|
|
18 - COMPRESSION SPRING
BSD-1604611026.A697
1604611026
|
£1.75
|
£2.10
|
|
|
21 - GEAR HOUSING
BSD-1605806429.A10
1605806429
|
£7.36
|
£8.83
|
|
|
22 - ADJUSTING SLIDE
BSD-1602319002.A130
1602319002
|
£2.61
|
£3.13
|
|
|
23 - SWITCH HANDLE
BSD-1602026057.A394
1602026057
|
£1.97
|
£2.36
|
|
|
25 - HOUSING COVER
BSD-1600508005.A57
1600508005
|
£3.80
|
£4.56
|
|
|
26 - RUBBER BUSHING
BSD-1600502020.A36
1600502020
|
£2.61
|
£3.13
|
|
|
27 - RUBBER RING
BSD-1600206025.A966
1600206025
|
£2.16
|
£2.59
|
|
|
28 - BEARING FLANGE
BSD-1605805061.A63
1605805061
|
£10.10
|
£12.12
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1601328005.A119
1601328005
|
£2.61
|
£3.13
|
|
|
32 - GRINDING SPINDLE
BSD-1607000D6A.A396
1607000D6A
|
£7.36
|
£8.83
|
|
|
35 - SHIM 0.2 MM
BSD-1600136010.A209
1600136010
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.3 MM
BSD-1600136011.A120
1600136011
|
£2.16
|
£2.59
|
|
|
35 - SHIM 0.1 MM
BSD-1600136012.A203
1600136012
|
£1.75
|
£2.10
|
|
|
36 - SPRING WASHER
BSD-1600150011.A219
1600150011
|
£1.75
|
£2.10
|
|
|
37 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A97
1600290016
|
£2.61
|
£3.13
|
|
|
38 - CROWN GEAR Z=36
BSD-1606333601.A87
1606333601
|
£8.49
|
£10.19
|
|
|
39 - SPIRAL SPRING
BSD-1604652013.A1035
1604652013
|
£1.75
|
£2.10
|
|
|
40 - SPRING RETAINING RING DIN 472-25x1.2MM
BSD-2916660009.A34
2916660009
|
£2.16
|
£2.59
|
|
|
41 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A600
1600910018
|
£5.30
|
£6.36
|
|
|
43 - BEVEL GEAR Z=11
BSD-1606333242.A141
1606333242
|
£48.38
|
£58.06
|
|
|
45 - HEX NUT M7. SW10
BSD-1603300016.A340
1603300016
|
£1.75
|
£2.10
|
|
|
47 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A157
2910211018
|
£1.75
|
£2.10
|
|
|
48 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A168
2910211005
|
£1.75
|
£2.10
|
|
|
49 - TAPPING SCREW DIN7981-ST3.9x19-F-Z
BSD-2912401420.A166
2912401420
|
£1.75
|
£2.10
|
|
|
50 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A969
2910211021
|
£1.75
|
£2.10
|
|
|
53 - CONNECTING CABLE
BSD-1604448015.A57
1604448015
|
£1.75
|
£2.10
|
|
|
54 - CONNECTING CABLE
BSD-1604448016.A90
1604448016
|
£1.75
|
£2.10
|
|
|
55 - TAPPING SCREW DIN7981-ST3.9x22-C-Z
BSD-2912401021.A94
2912401021
|
£1.75
|
£2.10
|
|
|
650/10 - AUXILIARY HANDLE M10. dia32.5x105 MM
BSD-160202509T.A486
160202509T
|
£3.72
|
£4.47
|
|
|
650/20 - ROUND NUT M14
BSD-1603345043.A1173
1603345043
|
£8.67
|
£10.41
|
|
|
650/30 - PIN-TYPE FACE-WRENCH
BSD-1607950052.A400
1607950052
|
£3.72
|
£4.47
|
|
|
650/40 - CLAMPING FLANGE dia22.3xdia42 MM
BSD-2605703014.A410
2605703014
|
£7.36
|
£8.83
|
|
|
650/40/20 - O-RING 20.35x1.78 MM
BSD-1600210039.A988
1600210039
|
£2.16
|
£2.59
|
|
|
650/50 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A488
2607950511
|
£4.26
|
£5.11
|
|
|
652 - PROTECTIVE COVER dia 115 MM(4 1/2)
BSD-2605510125.A88
2605510125
|
£27.23
|
£32.68
|
|
|
652/20 - SOCKET HEAD CAP SCREW DIN 84-M 6x16-8.8
BSD-2910022197.A200
2910022197
|
-
|
|
|
|
803 - ARMATURE WITH FAN 240V
BSD-1604010262.A13
1604010262
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A2538
160111A3H3
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014116.A219
1607014116
|
£11.30
|
£13.56
|
|
|
816 - BRUSH HOLDER
BSD-1600A003G4.A360
1600A003G4
|
£3.72
|
£4.47
|
|
|
838 - PARTS SET
BSD-1607000942.A5
1607000942
|
-
|
|
|
