1 - MOTOR HOUSING
BSD-1605108169.A9
1605108169
|
-
|
|
|
|
2 - FIELD 220-230V
BSD-1604220284.A0
1604220284
|
£31.79
|
£38.15
|
|
|
3/50 - FAN
BSD-1606610132.A264
1606610132
|
£2.27
|
£2.72
|
|
|
6 - GROMMET dia6.4-dia7.2x67 MM
BSD-1600703030.A52
1600703030
|
£2.74
|
£3.29
|
|
|
6 - GROMMET dia7.3-dia8.6x67 MM
BSD-1600703031.A90
1600703031
|
£2.94
|
£3.53
|
|
|
6 - GROMMET dia8.7-dia9.5x67 MM
BSD-1600703032.A23
1600703032
|
£2.61
|
£3.13
|
|
|
7 - FASTENING CLAMP
BSD-1601302017.A3
1601302017
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601118127.A3
1601118127
|
-
|
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A1510
2600905032
|
£5.57
|
£6.68
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-1600905011.A635
1600905011
|
£5.87
|
£7.04
|
|
|
16 - BRUSH HOLDER
BSD-1604336031.A5
1604336031
|
-
|
|
|
|
17 - SPIRAL SPRING
BSD-1604652013.A250
1604652013
|
£1.84
|
£2.21
|
|
|
18 - SWITCH-PAWL
BSD-1602319013.A59
1602319013
|
£8.49
|
£10.19
|
|
|
19 - COMPRESSION SPRING
BSD-1604611024.A10
1604611024
|
£1.75
|
£2.10
|
|
|
20 - SHIFT-LEVER KNOB
BSD-1602319007.A68
1602319007
|
£1.75
|
£2.10
|
|
|
25 - HOUSING COVER
BSD-1605500184.A3
1605500184
|
-
|
|
|
|
25 - HOUSING COVER
BSD-1605500179.A9
1605500179
|
-
|
|
|
|
26 - RUBBER RING
BSD-1600206036.A353
1600206036
|
£1.84
|
£2.21
|
|
|
27 - RUBBER RING
BSD-1600206025.A278
1600206025
|
£2.16
|
£2.59
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600591013.A54
1600591013
|
-
|
|
|
|
30 - AIR-DEFLECTOR RING
BSD-1600591014.A77
1600591014
|
£2.74
|
£3.29
|
|
|
31 - CLAMPING SPRING
BSD-1601290007.A117
1601290007
|
-
|
|
|
|
32 - GRINDING SPINDLE
BSD-1607000D6A.A757
1607000D6A
|
£7.36
|
£8.83
|
|
|
33 - O-RING 46.0x1.1 MM
BSD-1600210035.A312
1600210035
|
£1.84
|
£2.21
|
|
|
35 - SHIM 0.1 MM
BSD-1600136013.A183
1600136013
|
£2.74
|
£3.29
|
|
|
35 - SHIM 0.15 MM
BSD-1600136020.A420
1600136020
|
£3.72
|
£4.47
|
|
|
35 - SHIM 0.2 MM
BSD-1600136014.A337
1600136014
|
£2.74
|
£3.29
|
|
|
35 - SHIM 0.3 MM
BSD-1600136015.A183
1600136015
|
£2.74
|
£3.29
|
|
|
37 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A541
1600290016
|
£2.74
|
£3.29
|
|
|
40 - RETAINING CLIP
BSD-1600119011.A142
1600119011
|
£2.27
|
£2.72
|
|
|
41 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A94
1600910018
|
£5.57
|
£6.68
|
|
|
45 - HEX NUT M7. SW10
BSD-1603300016.A665
1603300016
|
£1.84
|
£2.21
|
|
|
47 - PLASTIC-CUTTING SCREW St3.9x12
BSD-1603435042.A658
1603435042
|
£1.84
|
£2.21
|
|
|
49 - THREAD-FORMING TAP. SCREW
BSD-1603435026.A200
1603435026
|
£2.27
|
£2.72
|
|
|
50 - PLASTIC-CUTTING SCREW
BSD-1603435037.A43
1603435037
|
£1.75
|
£2.10
|
|
|
51 - SPEED GOVERNOR 230V
BSD-1607233061.A3
1607233061
|
-
|
|
|
|
51 - SPEED GOVERNOR 230V
BSD-1607233056.A1
1607233056
|
-
|
|
|
|
55 - TAPPING SCREW DIN 7981-ST3.9x25-C-Z
BSD-2912401022.A17
2912401022
|
£1.84
|
£2.21
|
|
|
56 - PLASTIC-CUTTING SCREW
BSD-1603435044.A4
1603435044
|
-
|
|
|
|
57 - SOCKET HEAD CAP SCREW M3.5x7 MM
BSD-1603429002.A77
1603429002
|
£1.75
|
£2.10
|
|
|
80 - SEALING DISK
BSD-3600150021.A406
3600150021
|
£3.99
|
£4.79
|
|
|
104 - O-RING 4.5x1.0 MM
BSD-1600210044.A521
1600210044
|
£1.84
|
£2.21
|
|
|
650/50/20 - O-RING 20.35x1.78 MM
BSD-1600210039.A1145
1600210039
|
£2.27
|
£2.72
|
|
|
700 - PARTS SET dia 125 MM
BSD-2607001188.A66
2607001188
|
-
|
|
|
|
700/10 - PROTECTIVE COVER dia 125MM
BSD-2605510101.A38
2605510101
|
£23.33
|
£28.00
|
|
|
700/20 - GUIDE BLOCK
BSD-1608135004.A167
1608135004
|
-
|
|
|
|
700/20/30 - ROUND-HEAD BOLT DIN 603-M 5x16
BSD-2910281158.A149
2910281158
|
-
|
|
|
|
700/20/40 - WING NUT M 5 DIN 315-G-5
BSD-2915191105.A81
2915191105
|
-
|
|
|
|
700/20/50 - COMPRESSION SPRING
BSD-1604643004.A162
1604643004
|
-
|
|
|
|
750/10 - AUXILIARY HANDLE M10. dia32.5x105 MM
BSD-160202509T.A45
160202509T
|
£3.91
|
£4.69
|
|
|
750/20 - CLAMPING NUT M14
BSD-1603340040.A251
1603340040
|
£6.51
|
£7.81
|
|
|
750/30 - PIN-TYPE FACE-WRENCH
BSD-1607950043.A69
1607950043
|
£4.02
|
£4.83
|
|
|
750/50 - CLAMPING-FLANGE dia22.2x42 MM
BSD-1605703099.A5
1605703099
|
£7.82
|
£9.39
|
|
|
751 - PROTECTIVE COVER dia 125MM
BSD-2605510104.A58
2605510104
|
-
|
|
|
|
752 - FAST LOCKING FLANGE M14
BSD-1603340031.A23
1603340031
|
£21.12
|
£25.35
|
|
|
753 - CARRYING CASE
BSD-1605438089.A10
1605438089
|
-
|
|
|
|
767 - SUCTION HOOD dia115-125MM
BSD-2605510107.A50
2605510107
|
-
|
|
|
|
767/703 - BRUSH
BSD-2605730036.A63
2605730036
|
£21.53
|
£25.84
|
|
|
803 - ARMATURE WITH FAN 220-230V
BSD-1604010445.A0
1604010445
|
-
|
|
|
|
804 - SWITCH
BSD-1607200115.A103
1607200115
|
-
|
|
|
|
805 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A405
1607000227
|
£23.86
|
£28.63
|
|
|
805 - POWER SUPPLY CORD EU 4.15m 2 x 1.5mm H07 RN-F
BSD-1607000228.A299
1607000228
|
£23.86
|
£28.63
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A3373
160111A3H3
|
£2.74
|
£3.29
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014176.A100
1607014176
|
£13.78
|
£16.54
|
|
|
821 - GEAR HOUSING
BSD-1605806451.A84
1605806451
|
£39.13
|
£46.96
|
|
|
821/010 - PUSH-BUTTON
BSD-1607000253.A331
1607000253
|
£2.49
|
£2.99
|
|
|
828 - BEARING FLANGE
BSD-1605805079.A66
1605805079
|
£19.91
|
£23.89
|
|
|
838 - GEAR UNIT
BSD-1607000D4Y.A104
1607000D4Y
|
£21.42
|
£25.71
|
|
