2 - FIELD 220-240V
BSD-1604220254.A10
1604220254
|
£21.68
|
£26.01
|
|
|
3 - ARMATURE 220V
BSD-2604010715.A15
2604010715
|
-
|
|
|
|
3/60 - FAN
BSD-2606610049.A417
2606610049
|
£2.16
|
£2.59
|
|
|
4 - ON-OFF SWITCH
BSD-2607200250.A1
2607200250
|
-
|
|
|
|
5 - POWER SUPPLY CORD CH 4.15m 2 x 1.0mm H05 VV-F
BSD-1604460015.A29
1604460015
|
-
|
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1037
2600703012
|
£2.80
|
£3.36
|
|
|
7 - CABLE CLIP
BSD-2601035001.A651
2601035001
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-2601110669.A8
2601110669
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329114.A199
2607329114
|
-
|
|
|
|
13 - GROOVE BALL BEARING
BSD-2600905033.A19
2600905033
|
-
|
|
|
|
16 - BRUSH HOLDER
BSD-2604465094.A13
2604465094
|
-
|
|
|
|
17 - BRUSH HOLDER
BSD-2604465093.A5
2604465093
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A648
2603410001
|
£1.75
|
£2.10
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1467
2603490022
|
£1.75
|
£2.10
|
|
|
20 - STICKER
BSD-2601110670.A0
2601110670
|
-
|
|
|
|
21 - ROTARY HEAD
BSD-2602026045.A28
2602026045
|
-
|
|
|
|
22 - LOCKING LEVER
BSD-2602051001.A5
2602051001
|
-
|
|
|
|
23 - COMPRESSION SPRING
BSD-1604651007.A81
1604651007
|
-
|
|
|
|
24 - EARTH CONDUCTOR dia0.35 MM
BSD-2604448010.A21
2604448010
|
-
|
|
|
|
27 - THREAD-FORMING TAP. SCREW M4x8
BSD-2603410048.A211
2603410048
|
£1.75
|
£2.10
|
|
|
28 - HOUSING COVER
BSD-2605500108.A4
2605500108
|
-
|
|
|
|
29 - ADHESIVE TAPE
BSD-2601010041.A19
2601010041
|
-
|
|
|
|
30 - SHIM 0.5 MM
BSD-2600100588.A61
2600100588
|
£1.75
|
£2.10
|
|
|
31 - BASE PLATE
BSD-2608000074.A22
2608000074
|
-
|
|
|
|
32 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x10-8.8
BSD-2910141152.A19
2910141152
|
£1.75
|
£2.10
|
|
|
33 - PLAIN WASHER
BSD-3600100002.A45
3600100002
|
£1.75
|
£2.10
|
|
|
34 - COUNTERSUNK-HEAD SCREW DIN 7982-B3.9x13
BSD-2910601318.A26
2910601318
|
-
|
|
|
|
35 - LIFTING ROD
BSD-2600780047.A9
2600780047
|
-
|
|
|
|
36 - CLAMPING SADDLE
BSD-2601321012.A30
2601321012
|
-
|
|
|
|
37 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x12-12.9
BSD-2910405154.A4
2910405154
|
£1.95
|
£2.34
|
|
|
39 - SEALING DISK
BSD-2601334002.A1
2601334002
|
-
|
|
|
|
40 - FELT WASHER
BSD-2600108006.A14
2600108006
|
£1.75
|
£2.10
|
|
|
41 - SINTERED-METAL BUSHING
BSD-2600302003.A15
2600302003
|
-
|
|
|
|
43 - SLOTTED SPRING PIN DIN 1481-5x18
BSD-2917760121.A9
2917760121
|
-
|
|
|
|
44 - GUIDE BRACKET
BSD-2601321013.A11
2601321013
|
-
|
|
|
|
45 - NEEDLE BEARING
BSD-2600917900.A241
2600917900
|
£8.67
|
£10.41
|
|
|
46 - BEARING SLEEVE
BSD-2600400012.A17
2600400012
|
£4.26
|
£5.11
|
|
|
52 - BACKUP RING
BSD-2600200029.A17
2600200029
|
-
|
|
|
|
53 - SPACER RING
BSD-2600200028.A18
2600200028
|
-
|
|
|
|
54 - COUNTERWEIGHT
BSD-2601098008.A19
2601098008
|
-
|
|
|
|
55 - SHIM WASHER
BSD-2600200027.A17
2600200027
|
-
|
|
|
|
56 - SHIM 0.5 MM
BSD-2600101616.A338
2600101616
|
-
|
|
|
|
60 - SHIM 0.3 MM
BSD-2600100627.A126
2600100627
|
-
|
|
|
|
62 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A694
2916660008
|
£2.16
|
£2.59
|
|
|
65 - SHIM
BSD-2600100047.A17
2600100047
|
-
|
|
|
|
66 - CONTACT SPRING
BSD-2601329057.A34
2601329057
|
-
|
|
|
|
70 - BRUSH PLATE
BSD-2601015054.A44
2601015054
|
-
|
|
|
|
73 - O-RING 22x2 MM
BSD-1900210321.A127
1900210321
|
£5.30
|
£6.36
|
|
|
74 - SHIM
BSD-2600101603.A14
2600101603
|
-
|
|
|
|
74 - SHIM 0.2 MM
BSD-2600101613.A34
2600101613
|
-
|
|
|
|
74 - SHIM 0.3 MM
BSD-2600101604.A46
2600101604
|
-
|
|
|
|
76 - CONNECTING CABLE L=213 MM
BSD-2604448118.A20
2604448118
|
£1.75
|
£2.10
|
|
|
77 - CONNECTING CABLE L=162MM
BSD-2604448122.A14
2604448122
|
-
|
|
|
|
78 - DAMPING PLATE
BSD-2601022000.A542
2601022000
|
£1.75
|
£2.10
|
|
|
81 - CONNECTING CABLE L = 278 MM
BSD-2604448012.A17
2604448012
|
£1.32
|
£1.58
|
|
|
82 - CONNECTING CABLE L = 298 MM
BSD-2604448032.A37
2604448032
|
-
|
|
|
|
84 - FELT WASHER
BSD-1600205023.A13
1600205023
|
£1.32
|
£1.58
|
|
|
199 - STICKER
BSD-1601110265.A115
1601110265
|
-
|
|
|
|
700 - DRIVE-MACHINE HOLDER
BSD-0603095003.A8
0603095003
|
-
|
|
|
|
801 - MOTOR HOUSING
BSD-2605104885.A10
2605104885
|
-
|
|
|
|
814 - GROOVE BALL BEARING 9x24x7
BSD-2600905039.A71
2600905039
|
£12.04
|
£14.45
|
|
|
816/04 - CARBON-BRUSH SET
BSD-2607014009.A3
2607014009
|
-
|
|
|
|
816/06 - RATCHET CAP
BSD-2601322013.A89
2601322013
|
£1.75
|
£2.10
|
|
|
825 - GEAR HOUSING
BSD-2605806986.A20
2605806986
|
-
|
|
|
|
826 - GEAR COVER
BSD-2605500902.A13
2605500902
|
-
|
|
|
|
848 - ECCENTRIC COG WHEEL Z=45
BSD-2606320901.A17
2606320901
|
-
|
|
|
|
849 - NEEDLE-ROLLER CAGE
BSD-2607001130.A124
2607001130
|
£5.58
|
£6.70
|
|
|
859 - LOCKING WASHER DIN 6799-4-FSt
BSD-2916080007.A186
2916080007
|
£2.61
|
£3.13
|
|
|
864 - OFFSET SCREWDRIVER DIN 911-4
BSD-2607950004.A45
2607950004
|
£1.75
|
£2.10
|
|
|
871 - TAPPING SCREW DIN 7981-ST2.9x13-C-H
BSD-2910611006.A161
2910611006
|
£1.75
|
£2.10
|
|
|
880 - TAPPING SCREW DIN 7981-ST3.9x19-C-H
BSD-2910611020.A337
2910611020
|
£1.75
|
£2.10
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1532
160111A3H3
|
£2.61
|
£3.13
|
|
