2 - FIELD 220-240V
BSD-1604220254.A32
1604220254
|
£22.76
|
£27.31
|
|
|
3 - ARMATURE 220V
BSD-2604010715.A6
2604010715
|
-
|
|
|
|
3/60 - FAN
BSD-2606610049.A431
2606610049
|
£2.27
|
£2.72
|
|
|
4 - ON-OFF SWITCH
BSD-2607200218.A11
2607200218
|
-
|
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1045
2600703012
|
£2.94
|
£3.53
|
|
|
7 - CABLE CLIP
BSD-2601035001.A707
2601035001
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601118349.A0
2601118349
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329114.A173
2607329114
|
-
|
|
|
|
13 - GROOVE BALL BEARING
BSD-2600905033.A11
2600905033
|
-
|
|
|
|
16 - BRUSH HOLDER
BSD-2604465094.A4
2604465094
|
-
|
|
|
|
17 - BRUSH HOLDER
BSD-2604465093.A17
2604465093
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A645
2603410001
|
£1.84
|
£2.21
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1464
2603490022
|
£1.84
|
£2.21
|
|
|
20 - STICKER
BSD-2601110672.A9
2601110672
|
-
|
|
|
|
21 - ROTARY HEAD
BSD-2602026045.A26
2602026045
|
-
|
|
|
|
22 - LOCKING LEVER
BSD-2602051001.A7
2602051001
|
-
|
|
|
|
23 - COMPRESSION SPRING
BSD-1604651007.A79
1604651007
|
-
|
|
|
|
24 - EARTH CONDUCTOR dia0.35 MM
BSD-2604448010.A22
2604448010
|
-
|
|
|
|
27 - THREAD-FORMING TAP. SCREW M4x8
BSD-2603410048.A213
2603410048
|
£1.84
|
£2.21
|
|
|
28 - MOTOR HOUSING
BSD-2605104885.A15
2605104885
|
-
|
|
|
|
29 - ADHESIVE TAPE
BSD-2601010041.A17
2601010041
|
-
|
|
|
|
30 - SHIM 0.5 MM
BSD-2600100588.A60
2600100588
|
£1.84
|
£2.21
|
|
|
31 - BASE PLATE
BSD-2608000074.A24
2608000074
|
-
|
|
|
|
32 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x10-8.8
BSD-2910141152.A17
2910141152
|
£1.84
|
£2.21
|
|
|
33 - PLAIN WASHER
BSD-3600100002.A43
3600100002
|
£1.75
|
£2.10
|
|
|
34 - COUNTERSUNK-HEAD SCREW DIN 7982-B3.9x13
BSD-2910601318.A24
2910601318
|
-
|
|
|
|
35 - LIFTING ROD
BSD-2600780047.A11
2600780047
|
-
|
|
|
|
36 - CLAMPING SADDLE
BSD-2601321012.A32
2601321012
|
-
|
|
|
|
37 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x12-12.9
BSD-2910405154.A6
2910405154
|
£2.05
|
£2.46
|
|
|
39 - SEALING DISK
BSD-2601334002.A3
2601334002
|
-
|
|
|
|
40 - FELT WASHER
BSD-2600108006.A13
2600108006
|
£1.75
|
£2.10
|
|
|
41 - SINTERED-METAL BUSHING
BSD-2600302003.A14
2600302003
|
-
|
|
|
|
43 - SLOTTED SPRING PIN DIN 1481-5x18
BSD-2917760121.A11
2917760121
|
-
|
|
|
|
44 - GUIDE BRACKET
BSD-2601321013.A9
2601321013
|
-
|
|
|
|
45 - NEEDLE BEARING
BSD-2600917900.A243
2600917900
|
£9.11
|
£10.93
|
|
|
46 - BEARING SLEEVE
BSD-2600400012.A18
2600400012
|
£4.48
|
£5.37
|
|
|
52 - BACKUP RING
BSD-2600200029.A18
2600200029
|
-
|
|
|
|
53 - SPACER RING
BSD-2600200028.A17
2600200028
|
-
|
|
|
|
54 - COUNTERWEIGHT
BSD-2601098008.A17
2601098008
|
-
|
|
|
|
55 - SHIM WASHER
BSD-2600200027.A18
2600200027
|
-
|
|
|
|
56 - SHIM 0.5 MM
BSD-2600101616.A339
2600101616
|
-
|
|
|
|
60 - SHIM 0.3 MM
BSD-2600100627.A127
2600100627
|
-
|
|
|
|
62 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A692
2916660008
|
£2.16
|
£2.59
|
|
|
65 - SHIM
BSD-2600100047.A18
2600100047
|
-
|
|
|
|
66 - CONTACT SPRING
BSD-2601329057.A32
2601329057
|
-
|
|
|
|
70 - BRUSH PLATE
BSD-2601015054.A46
2601015054
|
-
|
|
|
|
73 - O-RING 22x2 MM
BSD-1900210321.A126
1900210321
|
£5.57
|
£6.68
|
|
|
74 - SHIM
BSD-2600101603.A13
2600101603
|
-
|
|
|
|
74 - SHIM 0.2 MM
BSD-2600101613.A33
2600101613
|
-
|
|
|
|
74 - SHIM 0.3 MM
BSD-2600101604.A47
2600101604
|
-
|
|
|
|
76 - CONNECTING CABLE L=213 MM
BSD-2604448118.A22
2604448118
|
£1.75
|
£2.10
|
|
|
77 - CONNECTING CABLE L=162MM
BSD-2604448122.A12
2604448122
|
-
|
|
|
|
78 - DAMPING PLATE
BSD-2601022000.A540
2601022000
|
£1.75
|
£2.10
|
|
|
81 - CONNECTING CABLE L = 278 MM
BSD-2604448012.A16
2604448012
|
£1.38
|
£1.66
|
|
|
82 - CONNECTING CABLE L = 298 MM
BSD-2604448032.A38
2604448032
|
-
|
|
|
|
199 - STICKER
BSD-1601110265.A118
1601110265
|
-
|
|
|
|
700 - DRIVE-MACHINE HOLDER
BSD-0603095003.A10
0603095003
|
-
|
|
|
|
801 - MOTOR HOUSING
BSD-2605104885.A14
2605104885
|
-
|
|
|
|
805 - POWER SUPPLY CORD EU 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1607000386.A186
1607000386
|
£22.60
|
£27.12
|
|
|
814 - GROOVE BALL BEARING 9x24x7
BSD-2600905039.A73
2600905039
|
£12.64
|
£15.17
|
|
|
816/04 - CARBON-BRUSH SET
BSD-2607014009.A0
2607014009
|
-
|
|
|
|
816/06 - RATCHET CAP
BSD-2601322013.A91
2601322013
|
£1.84
|
£2.21
|
|
|
825 - GEAR HOUSING
BSD-2605806986.A17
2605806986
|
-
|
|
|
|
826 - GEAR COVER
BSD-2605500902.A16
2605500902
|
-
|
|
|
|
848 - ECCENTRIC COG WHEEL Z=45
BSD-2606320901.A20
2606320901
|
-
|
|
|
|
849 - NEEDLE-ROLLER CAGE
BSD-2607001130.A127
2607001130
|
£5.87
|
£7.04
|
|
|
859 - LOCKING WASHER DIN 6799-4-FSt
BSD-2916080007.A188
2916080007
|
£2.74
|
£3.29
|
|
|
864 - OFFSET SCREWDRIVER DIN 911-4
BSD-2607950004.A43
2607950004
|
£1.84
|
£2.21
|
|
|
871 - TAPPING SCREW DIN 7981-ST2.9x13-C-H
BSD-2910611006.A163
2910611006
|
£1.84
|
£2.21
|
|
|
880 - TAPPING SCREW DIN 7981-ST3.9x19-C-H
BSD-2910611020.A335
2910611020
|
£1.84
|
£2.21
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1530
160111A3H3
|
£2.74
|
£3.29
|
|
