Bosch PSR 72 / 0603937768 / GB 7.2 Volt Spare Parts

An exploded drawing and listing for the Bosch PSR 72 / 0603937768 / GB 7.2 Volt

	Ex VAT	Inc VAT
1 - HOUSING SECTION BSD-2605104509.A0 2605104509	-
2/10 - PINION Z=9 BSD-2606316158.A0 2606316158	-
5 - ADJUSTING SLIDE BSD-2601099055.A73 2601099055	-
25 - KEYLESS CHUCK BSD-2608572200.A6 2608572200	-
45 - PLANETARY GEAR TRAIN BSD-2606200054.A12 2606200054	-
93 - SCREWDRIVER BLADE 6 MM BSD-1609200147.A323 1609200147	£3.72	£4.47
96 - SUPPORT BSD-2608040079.A44 2608040079	£1.75	£2.10
101 - TORX OVAL-HEAD SCREW 3x18 BSD-2603490018.A700 2603490018	£1.75	£2.10
102 - RETAINING BRACKET BSD-2601329041.A118 2601329041	£2.33	£2.80
107 - COUNTERSUNK-HEAD SCREW M5x20 BSD-2609110721.A32 2609110721	£2.27	£2.72
653 - CHARGER GB 230/7.2V. 3h BSD-2607224329.A3 2607224329	£23.86	£28.63
797 - CARRYING LOOP BSD-2601398009.A157 2601398009	-
802 - DC MOTOR 7.2V BSD-2607022943.A4 2607022943	-
804 - ON-OFF SWITCH BSD-2607200351.A30 2607200351	-
809 - MANUFACTURER'S NAMEPLATE BSD-2601117368.A1 2601117368	-
820 - REFERENCE PLATE BSD-2601117369.A1 2601117369	-

Attribute Name	Value
Brand	Bosch
