1 - MOTOR HOUSING
BSD-3605108059.A2
3605108059
|
£27.23
|
£32.68
|
|
|
2 - STATOR 550W
BSD-3604090049.A20
3604090049
|
£98.57
|
£118.28
|
|
|
3 - ROTOR
BSD-3604220078.A2
3604220078
|
£164.02
|
£196.83
|
|
|
5 - BEARING FLANGE
BSD-3605700074.A19
3605700074
|
£28.59
|
£34.31
|
|
|
7 - GROOVE BALL BEARING
BSD-3600905038.A50
3600905038
|
£15.65
|
£18.78
|
|
|
8 - GROOVE BALL BEARING DIN 625-7x19x6
BSD-3600905148.A128
3600905148
|
£8.92
|
£10.70
|
|
|
10 - O-RING 28x2 MM
BSD-1900210127.A68
1900210127
|
£5.57
|
£6.68
|
|
|
11 - O-RING 20x2 MM
BSD-1900210118.A17
1900210118
|
£2.80
|
£3.36
|
|
|
22 - PLAIN WASHER DIN 9021-B 4.3-ST
BSD-2916011892.A60
2916011892
|
£1.84
|
£2.21
|
|
|
23 - O-RING 39.0x2.0 MM
BSD-3600210022.A4
3600210022
|
£3.72
|
£4.47
|
|
|
24 - GUIDE SLEEVE
BSD-3600327000.A22
3600327000
|
£3.72
|
£4.47
|
|
|
31 - INTERMEDIATE RING
BSD-3600200016.A1
3600200016
|
-
|
|
|
|
49 - SILENCER
BSD-3601010027.A1
3601010027
|
£2.74
|
£3.29
|
|
|
50 - SILENCER
BSD-3601010006.A54
3601010006
|
£1.84
|
£2.21
|
|
|
55 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A328
2910211021
|
£1.75
|
£2.10
|
|
|
56 - TAPPING SCREW DIN 7971-3.9x38
BSD-2910215093.A54
2910215093
|
-
|
|
|
|
58 - CONNECTION COVER
BSD-3605500032.A41
3605500032
|
£9.11
|
£10.93
|
|
|
59 - FITTING
BSD-3603462011.A15
3603462011
|
£15.65
|
£18.78
|
|
|
60 - FILTER SCREEN
BSD-3600002004.A83
3600002004
|
£2.80
|
£3.36
|
|
|
61 - O-RING 6.0x2.0 MM
BSD-3600210023.A38
3600210023
|
£3.91
|
£4.69
|
|
|
62 - COMPRESSION SPRING
BSD-2604611025.A52
2604611025
|
£2.80
|
£3.36
|
|
|
63 - STRAIGHT PIN
BSD-3604710054.A40
3604710054
|
£3.72
|
£4.47
|
|
|
64 - O-RING 5.94x3.53 MM
BSD-3600210024.A5
3600210024
|
£2.27
|
£2.72
|
|
|
65 - O-RING 2.7x1.5 MM
BSD-3600210025.A38
3600210025
|
£2.16
|
£2.59
|
|
|
66 - BALL DIN 5401-3 MM-III-ST
BSD-1903230004.A293
1903230004
|
£2.27
|
£2.72
|
|
|
69 - COMPRESSION SPRING
BSD-3604610024.A5
3604610024
|
£1.84
|
£2.21
|
|
|
70 - HEX SCREW
BSD-3603450006.A6
3603450006
|
£5.30
|
£6.36
|
|
|
71 - O-RING 15x2 MM
BSD-1900210112.A76
1900210112
|
£2.61
|
£3.13
|
|
|
77 - TOGGLE SWITCH
BSD-3602033001.A36
3602033001
|
£3.91
|
£4.69
|
|
|
78 - HOLDING PLATE
BSD-3601100021.A1
3601100021
|
£5.30
|
£6.36
|
|
|
79 - COMPRESSION SPRING
BSD-3604610008.A37
3604610008
|
£1.75
|
£2.10
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A366
160111A3HF
|
£3.91
|
£4.69
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A567
1601110481
|
£2.27
|
£2.72
|
|
|
98 - REFERENCE PLATE
BSD-3601119237.A8
3601119237
|
£3.91
|
£4.69
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A896
3601119236
|
£3.91
|
£4.69
|
|
|
102 - GROOVE BALL BEARING
BSD-3600900020.A1
3600900020
|
£13.12
|
£15.75
|
|
|
103 - GRINDING SPINDLE M15x1. SW17
BSD-3603523008.A4
3603523008
|
£81.81
|
£98.17
|
|
|
104 - GROOVE BALL BEARING
BSD-3600900021.A25
3600900021
|
£22.60
|
£27.12
|
|
|
105 - COUPLING HALF
BSD-2606446002.A10
2606446002
|
£8.67
|
£10.41
|
|
|
112 - RECEPTACLE
BSD-3600400012.A4
3600400012
|
£11.87
|
£14.24
|
|
|
113 - INTERMEDIATE FLANGE
BSD-3605700082.A5
3605700082
|
£33.22
|
£39.87
|
|
|
114 - COMPRESSION SPRING
BSD-2604630001.A0
2604630001
|
£2.16
|
£2.59
|
|
|
115 - SPRING RETAINING RING DIN 472-26x1.2 MM
BSD-2916660010.A0
2916660010
|
£1.75
|
£2.10
|
|
|
117 - SPRING RETAINING RING DIN 471-12x1-FSTM
BSD-2916650903.A70
2916650903
|
£1.75
|
£2.10
|
|
|
118 - SHIM
BSD-3600150011.A10
3600150011
|
£1.84
|
£2.21
|
|
|
119 - COVER RING
BSD-3600300074.A3
3600300074
|
£15.65
|
£18.78
|
|
|
120 - COLLET dia 6 MM
BSD-2608570129.A16
2608570129
|
£19.91
|
£23.89
|
|
|
121 - ROUND NUT
BSD-3603342009.A123
3603342009
|
£14.91
|
£17.89
|
|
|
123 - SHIM 0.10 MM
BSD-1710102601.A3
1710102601
|
£1.75
|
£2.10
|
|
|
124 - GROOVE BALL BEARING 9x24x7 MM
BSD-3600905039.A7
3600905039
|
£12.04
|
£14.45
|
|
|
650 - SILENCER
BSD-3607000073.A30
3607000073
|
£19.91
|
£23.89
|
|
|
652 - HOSE FITTING
BSD-3603386068.A22
3603386068
|
£22.60
|
£27.12
|
|
|
653 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A373
2607950511
|
£4.48
|
£5.37
|
|
|
801 - GRINDING SPINDLE
BSD-3607031168.A3
3607031168
|
£218.41
|
£262.09
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030260.A65
3607030260
|
£21.68
|
£26.01
|
|
|
810 - PISTON ASSEMBLY GROUP
BSD-3607030494.A38
3607030494
|
£18.96
|
£22.75
|
|
|
819 - SPINDLE BEARING
BSD-3607030418.A9
3607030418
|
£62.51
|
£75.01
|
|
|
819/1 - COVER RING 8.5 mm
BSD-2600501001.A18
2600501001
|
-
|
|
|
