2 - SPRING
BDE-1004526-01.A3
1004526-01
|
£1.50
|
£1.80
|
|
|
3 - BALL STEEL
BDE-1004526-02.A4
1004526-02
|
£1.50
|
£1.80
|
|
|
4 - SPRING
BDE-1004526-03.A3
1004526-03
|
£1.50
|
£1.80
|
|
|
5 - DIAL PLATE
BDE-1004526-97.A0
1004526-97
|
-
|
|
|
|
6 - KNOB LOWER
BDE-1004526-05.A1
1004526-05
|
£1.50
|
£1.80
|
|
|
7 - COVER
BDE-1004526-98.A4
1004526-98
|
£1.50
|
£1.80
|
|
|
8 - SCREW
BDE-1004526-07.A1
1004526-07
|
£1.50
|
£1.80
|
|
|
9 - COVER
BDE-1004526-08.A4
1004526-08
|
£1.50
|
£1.80
|
|
|
10 - SCREW
BDE-1004526-09.A1
1004526-09
|
£1.50
|
£1.80
|
|
|
11 - SPRING
BDE-1004526-10.A6
1004526-10
|
£1.50
|
£1.80
|
|
|
12 - GUARD COVER
BDE-1004526-11.A1
1004526-11
|
£1.50
|
£1.80
|
|
|
13 - CLAMSHELL SA
BDE-1004526-13
1004526-13
|
£44.00
|
£52.80
|
|
|
14 - BRUSH CAP
BDE-1004526-14.A0
1004526-14
|
£1.50
|
£1.80
|
|
|
15 - CORD CLAMP
BDE-1004526-17.A7
1004526-17
|
£1.50
|
£1.80
|
|
|
16 - SCREW
BDE-1004526-18.A0
1004526-18
|
£1.50
|
£1.80
|
|
|
17 - SWITCH
BDE-1004526-20
1004526-20
|
£7.01
|
£8.41
|
|
|
18 - CAPACITOR
BDE-1004526-21.A0
1004526-21
|
£1.50
|
£1.80
|
|
|
20 - MOTOR COVER
BDE-1004526-23.A6
1004526-23
|
£3.30
|
£3.96
|
|
|
21 - CORD PROTECTOR
BDE-1004526-24.A0
1004526-24
|
£1.50
|
£1.80
|
|
|
23 - BEARING
BDE-1004526-26.A7
1004526-26
|
£2.78
|
£3.34
|
|
|
25 - WASHER LOCK
BDE-1004526-29.A7
1004526-29
|
£1.50
|
£1.80
|
|
|
27 - KNOB SA
BDE-1004526-31.A0
1004526-31
|
£1.50
|
£1.80
|
|
|
28 - NUT M6
BDE-1004526-32.A4
1004526-32
|
£1.50
|
£1.80
|
|
|
29 - LEVER
BDE-1004526-33.A0
1004526-33
|
£1.50
|
£1.80
|
|
|
30 - DEFLECTOR
BDE-1004526-34.A7
1004526-34
|
£1.50
|
£1.80
|
|
|
32 - SPRING
BDE-1004526-36.A0
1004526-36
|
£1.50
|
£1.80
|
|
|
33 - BEARING
BDE-1004526-37.A7
1004526-37
|
£3.30
|
£3.96
|
|
|
34 - BLADEDRUM SA Incl. 33
BDE-1004526-39.A3
1004526-39
|
£50.60
|
£60.72
|
|
|
35 - PIN
BDE-1004526-46.A0
1004526-46
|
£4.69
|
£5.63
|
|
|
37 - BAFFLE FAN
BDE-1004526-49.A1
1004526-49
|
£1.50
|
£1.80
|
|
|
38 - SPRING
BDE-1004526-50.A6
1004526-50
|
£1.50
|
£1.80
|
|
|
39 - CLAMPING BAR
BDE-1004526-51.A1
1004526-51
|
£1.50
|
£1.80
|
|
|
40 - STAND
BDE-1004526-52.A6
1004526-52
|
£1.50
|
£1.80
|
|
|
41 - SHOE
BDE-1004526-53.A1
1004526-53
|
£12.17
|
£14.60
|
|
|
42 - SCREW
BDE-1004526-54.A6
1004526-54
|
£1.50
|
£1.80
|
|
|
43 - BELT
BDE-1004526-55.A1
1004526-55
|
£5.88
|
£7.06
|
|
|
44 - COVER BELT
BDE-1004526-56.A4
1004526-56
|
£1.50
|
£1.80
|
|
|
47 - BEARING
BDE-1004526-59.A1
1004526-59
|
£5.88
|
£7.06
|
|
|
48 - BEARING PLATE
BDE-1004526-60.A6
1004526-60
|
£1.50
|
£1.80
|
|
|
50 - WHEEL LARGE
BDE-1004526-62.A1
1004526-62
|
£1.82
|
£2.19
|
|
|
51 - NUT
BDE-1004526-63.A5
1004526-63
|
£1.50
|
£1.80
|
|
|
52 - BAFFLE
BDE-1004526-64.A1
1004526-64
|
£1.50
|
£1.80
|
|
|
53 - SCREW
BDE-1004526-65.A6
1004526-65
|
£1.50
|
£1.80
|
|
|
54 - BEARING
BDE-1004526-66.A1
1004526-66
|
£2.78
|
£3.34
|
|
|
56 - WHEEL DRIVING
BDE-1004526-68.A6
1004526-68
|
£3.30
|
£3.96
|
|
|
57 - BEARING PLATE
BDE-1004526-69.A1
1004526-69
|
£1.50
|
£1.80
|
|
|
61 - SPANNER
BDE-1004526-77.A2
1004526-77
|
£1.42
|
£1.70
|
|
|
63 - FENCE
BDE-1004526-80.A1
1004526-80
|
£10.57
|
£12.68
|
|
|
64 - ADJUSTER BLOCK
BDE-1004526-87.A1
1004526-87
|
£5.88
|
£7.06
|
|
|
65 - SUPPORT PLATE
BDE-1004526-86.A2
1004526-86
|
£5.88
|
£7.06
|
|
|
67 - BRUSH HOLDER
BDE-1004526-15.A7
1004526-15
|
£2.26
|
£2.71
|
|
|
68 - BRUSH PAIR
BDE-1004526-16.A0
1004526-16
|
£1.50
|
£1.80
|
|
|
69 - SCREW
BDE-1004526-40.A0
1004526-40
|
£1.42
|
£1.70
|
|
|
70 - BLADE CLAMP
BDE-1004526-41.A3
1004526-41
|
£4.69
|
£5.63
|
|
|
71 - SCREW
BDE-1004526-42.A0
1004526-42
|
£1.42
|
£1.70
|
|
|
72 - SUPPORT
BDE-1004526-43.A3
1004526-43
|
£3.22
|
£3.86
|
|
|
73 - BLADE
BDE-1004526-44.A0
1004526-44
|
£14.57
|
£17.48
|
|
|
74 - CUTTER BLOCK
BDE-1004526-45.A3
1004526-45
|
£18.42
|
£22.10
|
|
