1 - HOUSING SECTION
BSD-3609202A45.A6
3609202A45
|
£62.51
|
£75.01
|
|
|
4 - ELECTRONIC ASSEMBLY
BSD-3607200120.A5
3607200120
|
£500.46
|
£600.55
|
|
|
8 - RETAINING RING dia36.6xdia1.5
BSD-1614601016.A22
1614601016
|
£2.94
|
£3.53
|
|
|
9 - ANGLE SCREWDRIVER HEAD 3/8
BSD-3607020165.A12
3607020165
|
£798.41
|
£958.09
|
|
|
10 - SWITCH SLIDE
BSD-3601099003.A56
3601099003
|
£2.80
|
£3.36
|
|
|
11/1 - ANGLE FLANGE
BSD-3609202A33.A5
3609202A33
|
£107.69
|
£129.23
|
|
|
11/2 - GROOVE BALL BEARING
BSD-3600905026.A23
3600905026
|
£22.76
|
£27.31
|
|
|
11/3 - SPRING RETAINING RING
BSD-2600119000.A79
2600119000
|
£1.84
|
£2.21
|
|
|
11/4 - O-RING 20.0x1.0 MM
BSD-3600210012.A50
3600210012
|
£2.94
|
£3.53
|
|
|
11/5 - SHIM RING 1.0 MM
BSD-1610101015.A26
1610101015
|
£1.84
|
£2.21
|
|
|
16 - LED-HOLDER
BSD-3605105019.A23
3605105019
|
£11.87
|
£14.24
|
|
|
17 - LED-HOLDER
BSD-3605105020.A20
3605105020
|
£11.30
|
£13.56
|
|
|
19 - O-RING 25x2.5 MM
BSD-1900210125.A28
1900210125
|
£7.36
|
£8.83
|
|
|
20 - PINION
BSD-3606309061.A2
3606309061
|
£50.80
|
£60.96
|
|
|
28 - COMPRESSION SPRING
BSD-1604616017.A40
1604616017
|
£2.80
|
£3.36
|
|
|
29 - INTERMEDIATE FLANGE
BSD-2605719011.A73
2605719011
|
£3.72
|
£4.47
|
|
|
30 - PLANETARY GEAR TRAIN
BSD-3607030472.A10
3607030472
|
£66.68
|
£80.01
|
|
|
31 - PLANETARY GEAR TRAIN
BSD-3607030458.A0
3607030458
|
£525.48
|
£630.58
|
|
|
40 - ASSEMBLY KIT
BSD-3607031643.A1
3607031643
|
£297.68
|
£357.21
|
|
|
40/101 - CLUTCH ELEMENT
BSD-3606445043.A74
3606445043
|
£102.57
|
£123.08
|
|
|
40/102 - DRIVE SHAFT
BSD-3603124035.A0
3603124035
|
£120.11
|
£144.13
|
|
|
40/109 - COMPRESSION SPRING
BSD-3604619003.A66
3604619003
|
£5.58
|
£6.70
|
|
|
40/110 - RETAINING RING
BSD-3600224053.A170
3600224053
|
£1.84
|
£2.21
|
|
|
40/115 - SEALING PLATE
BSD-3601023011.A63
3601023011
|
£2.61
|
£3.13
|
|
|
40/116 - SETTING RING
BSD-3600134014.A64
3600134014
|
£31.64
|
£37.97
|
|
|
40/119 - SUPPORT DISC
BSD-3600190036.A110
3600190036
|
£9.11
|
£10.93
|
|
|
40/120 - CATCH DISK
BSD-3603344047.A182
3603344047
|
£23.86
|
£28.63
|
|
|
40/127 - BALL DIN 5401-3.5 MM-III-ST
BSD-1903230006.A421
1903230006
|
£2.27
|
£2.72
|
|
|
40/128 - BALL 4.5 MM III DIN 5401-ST
BSD-1903230008.A191
1903230008
|
£1.75
|
£2.10
|
|
|
40/140 - LOCKING WASHER DIN 6799-9-FSt
BSD-2916080012.A206
2916080012
|
£1.84
|
£2.21
|
|
|
60 - SWITCHING ELEMENT
BSD-3601923022.A129
3601923022
|
£5.30
|
£6.36
|
|
|
61 - COMPRESSION SPRING
BSD-3604611022.A128
3604611022
|
£3.72
|
£4.47
|
|
|
62 - PUSHER
BSD-3601923029.A139
3601923029
|
£5.30
|
£6.36
|
|
|
71 - LIGHT CONDUCTOR
BSD-3604460132.A8
3604460132
|
£2.94
|
£3.53
|
|
|
80 - TORX OVAL-HEAD SCREW 3x18
BSD-2603490018.A164
2603490018
|
£1.75
|
£2.10
|
|
|
82 - TORX SH CAP SCREW M3x5-8.8-Z
BSD-2603414048.A86
2603414048
|
£1.84
|
£2.21
|
|
|
90 - RING
BSD-3600106025.A1
3600106025
|
£3.72
|
£4.47
|
|
|
657 - SCREWDRIVER
BSD-3607950027.A79
3607950027
|
£15.65
|
£18.78
|
|
|
659 - SUSPENSION LOOP
BSD-3601923024.A0
3601923024
|
£11.30
|
£13.56
|
|
|
751 - PROTECTIVE CAP
BSD-3609202A29.A8
3609202A29
|
£13.78
|
£16.54
|
|
|
802 - DC MOTOR
BSD-3607031633.A2
3607031633
|
£229.32
|
£275.19
|
|
|
803 - WIRING HARNESS
BSD-3609202B02.A13
3609202B02
|
£72.18
|
£86.62
|
|
|
804 - WIRING HARNESS
BSD-3609202B03.A5
3609202B03
|
£19.91
|
£23.89
|
|
|
806 - CONTACT RETAINER
BSD-1609280416.A38
1609280416
|
£10.61
|
£12.73
|
|
|
807 - SLIDE-IN ACCU PACKAGE 9.6V.2.6Ah.NiMh
BSD-2607335681.A53
2607335681
|
£116.15
|
£139.38
|
|
|
820 - CATCH DISK
BSD-3603344047.A183
3603344047
|
£23.86
|
£28.63
|
|
|
854 - FAST CHARGER EU 230/7.2-24V. 30 MIN.
BSD-2607225027.A75
2607225027
|
£126.12
|
£151.34
|
|
|
854 - FAST CHARGER GB 230/7.2-24V. 30 MIN.
BSD-2607225029.A88
2607225029
|
£92.47
|
£110.96
|
|
|
854 - FAST CHARGER AUS 240/7.2-24V. 30 MIN.
BSD-2607225031.A65
2607225031
|
£98.11
|
£117.73
|
|
|
854 - FAST CHARGER USA 120/7.2-24V. 30 MIN.
BSD-2607225033.A73
2607225033
|
-
|
|
|
|
854 - FAST CHARGER SAM 115/7.2-24V. 15 MIN.
BSD-2607225035.A55
2607225035
|
-
|
|
|
|
854 - FAST CHARGER J 100/7.2-24V. 1h
BSD-2607224435.A6
2607224435
|
£120.11
|
£144.13
|
|
|
854 - FAST CHARGER ROK 220/7.2-24V. 30 MIN.
BSD-2607225039.A73
2607225039
|
£84.64
|
£101.57
|
|
|
855 - MANUFACTURER'S NAMEPLATE
BSD-3601110532.A0
3601110532
|
£10.10
|
£12.12
|
|
|
866 - NAMEPLATE
BSD-16070312BV.A0
16070312BV
|
£3.91
|
£4.69
|
|
|
890 - PARTS SET
BSD-3600106027.A5
3600106027
|
£21.68
|
£26.01
|
|
|
890 - PARTS SET
BSD-3600106028.A63
3600106028
|
£21.52
|
£25.83
|
|
|
890 - PARTS SET
BSD-3600106029.A5
3600106029
|
£21.68
|
£26.01
|
|
|
890 - PARTS SET
BSD-3600106030.A63
3600106030
|
£21.68
|
£26.01
|
|
|
890 - PARTS SET
BSD-3600106031.A5
3600106031
|
£23.86
|
£28.63
|
|
|
890 - PARTS SET
BSD-3600106032.A63
3600106032
|
£21.68
|
£26.01
|
|
|
890 - PARTS SET
BSD-3600106033.A5
3600106033
|
£21.52
|
£25.83
|
|
