Bosch ANGLE EXACT 10-650 / 0602492610 / --- 9.6 Volt Spare Parts

An exploded drawing and listing for the Bosch ANGLE EXACT 10-650 / 0602492610 / --- 9.6 Volt

	Ex VAT	Inc VAT
1 - HOUSING SECTION BSD-3609202A45.A7 3609202A45	£59.53	£71.44
4 - ELECTRONIC ASSEMBLY BSD-3607200120.A8 3607200120	£500.46	£600.55
8 - RETAINING RING dia36.6xdia1.5 BSD-1614601016.A23 1614601016	£2.80	£3.36
10 - SWITCH SLIDE BSD-3601099003.A48 3601099003	£2.80	£3.36
11 - ANGLE FLANGE BSD-3605700165.A1 3605700165	£59.53	£71.44
12 - GROOVE BALL BEARING BSD-1280905004.A49 1280905004	£31.64	£37.97
13 - SPRING RETAINING RING 16x1 MM. DIN 472 BSD-2916660003.A29 2916660003	£1.75	£2.10
14 - SLEEVE BSD-3600423004.A25 3600423004	£5.58	£6.70
15 - COMPRESSION SPRING BSD-3604611037.A51 3604611037	£5.30	£6.36
16 - LED-HOLDER BSD-3605105019.A18 3605105019	£11.30	£13.56
17 - LED-HOLDER BSD-3605105020.A25 3605105020	£11.30	£13.56
18 - O-RING 20.0x1.0 MM BSD-3600210012.A53 3600210012	£2.80	£3.36
20 - PINION BSD-3606309060.A12 3606309060	£48.38	£58.06
29 - INTERMEDIATE FLANGE BSD-2605719011.A79 2605719011	£3.72	£4.47
30 - PLANETARY GEAR TRAIN BSD-3607030469.A17 3607030469	£72.18	£86.62
40 - ASSEMBLY KIT BSD-3607031567.A21 3607031567	£218.41	£262.09
40/101 - CLUTCH ELEMENT BSD-3606445043.A69 3606445043	£102.57	£123.08
40/102 - OUTPUT SHAFT BSD-3603124034.A3 3603124034	£51.22	£61.47
40/109 - COMPRESSION SPRING BSD-3604619020.A76 3604619020	£5.58	£6.70
40/110 - RETAINING RING BSD-3600224053.A167 3600224053	£1.75	£2.10
40/115 - SEALING PLATE BSD-3601023011.A71 3601023011	£2.61	£3.13
40/116 - SETTING RING BSD-3600134016.A11 3600134016	£59.53	£71.44
40/117 - PLAIN WASHER 0.5 MM BSD-1600101023.A114 1600101023	£1.75	£2.10
40/119 - SUPPORT DISC BSD-3600190036.A107 3600190036	£8.67	£10.41
40/120 - CATCH DISK BSD-3603344046.A0 3603344046	£33.74	£40.49
40/122 - SHIM WASHER BSD-3600101052.A25 3600101052	£8.67	£10.41
40/127 - BALL DIN 5401-3.5 MM-III-ST BSD-1903230006.A413 1903230006	£2.16	£2.59
40/128 - BALL 4.5 MM III DIN 5401-ST BSD-1903230008.A183 1903230008	£1.75	£2.10
40/140 - LOCKING WASHER DIN 6799-9-FSt BSD-2916080012.A201 2916080012	£1.75	£2.10
60 - SWITCHING ELEMENT BSD-3601923022.A120 3601923022	£5.30	£6.36
61 - COMPRESSION SPRING BSD-3604611022.A125 3604611022	£3.72	£4.47
62 - PUSHER BSD-3601923029.A131 3601923029	£5.30	£6.36
71 - LIGHT CONDUCTOR BSD-3604460132.A1 3604460132	£2.80	£3.36
80 - TORX OVAL-HEAD SCREW 3x18 BSD-2603490018.A160 2603490018	£1.75	£2.10
82 - TORX SH CAP SCREW M3x5-8.8-Z BSD-2603414048.A90 2603414048	£1.75	£2.10
90 - RING BSD-3600106023.A1 3600106023	£2.80	£3.36
657 - SCREWDRIVER BSD-3607950027.A75 3607950027	£14.91	£17.89
659 - SUSPENSION LOOP BSD-3601923024.A8 3601923024	£11.30	£13.56
697 - PROTECTIVE CAP 25.4x25.4 MM BSD-3608872557.A17 3608872557	£2.80	£3.36
703 - SLIDE-IN ACCU PACKAGE 9.6V.2.6Ah.NiMh BSD-2607335681.A56 2607335681	£116.15	£139.38
802 - DC MOTOR BSD-3607031625.A3 3607031625	£283.50	£340.20
803 - WIRING HARNESS BSD-3609202B02.A9 3609202B02	£72.18	£86.62
804 - WIRING HARNESS BSD-3609202B03.A9 3609202B03	£18.96	£22.75
806 - CONTACT RETAINER BSD-1609280416.A41 1609280416	£10.10	£12.12
820 - CATCH DISK BSD-3603344047.A178 3603344047	£23.86	£28.63
854 - FAST CHARGER EU 230/7.2-24V. 30 MIN. BSD-2607225027.A73 2607225027	£120.11	£144.13
854 - FAST CHARGER GB 230/7.2-24V. 30 MIN. BSD-2607225029.A90 2607225029	£88.07	£105.68
854 - FAST CHARGER AUS 240/7.2-24V. 30 MIN. BSD-2607225031.A63 2607225031	£98.11	£117.73
854 - FAST CHARGER USA 120/7.2-24V. 30 MIN. BSD-2607225033.A75 2607225033	-
854 - FAST CHARGER SAM 115/7.2-24V. 15 MIN. BSD-2607225035.A53 2607225035	-
854 - FAST CHARGER J 100/7.2-24V. 1h BSD-2607224435.A8 2607224435	£120.11	£144.13
854 - FAST CHARGER ROK 220/7.2-24V. 30 MIN. BSD-2607225039.A75 2607225039	£80.61	£96.73
855 - NAMEPLATE BSD-3601119474.A1 3601119474	£18.96	£22.75
866 - MANUFACTURER'S NAMEPLATE BSD-3601110524.A1 3601110524	£6.52	£7.83
890 - PARTS SET BSD-3600106027.A8 3600106027	£21.68	£26.01
890 - PARTS SET BSD-3600106028.A60 3600106028	£21.52	£25.83
890 - PARTS SET BSD-3600106029.A8 3600106029	£21.68	£26.01
890 - PARTS SET BSD-3600106030.A60 3600106030	£21.68	£26.01
890 - PARTS SET BSD-3600106031.A8 3600106031	£23.86	£28.63
890 - PARTS SET BSD-3600106032.A60 3600106032	£21.68	£26.01
890 - PARTS SET BSD-3600106033.A8 3600106033	£21.52	£25.83
