1 - MOTOR HOUSING
BSD-3605108026.A8
3605108026
|
£218.41
|
£262.09
|
|
|
2 - STATOR 550W
BSD-3604090008.A1
3604090008
|
£102.57
|
£123.08
|
|
|
3 - ROTOR
BSD-3604220014.A10
3604220014
|
-
|
|
|
|
5 - BEARING FLANGE
BSD-3605700014.A34
3605700014
|
£59.53
|
£71.44
|
|
|
6 - GROOVE BALL BEARING 10x26x8
BSD-1900905127.A63
1900905127
|
£27.23
|
£32.68
|
|
|
7 - BEARING FLANGE
BSD-3605700013.A4
3605700013
|
£48.38
|
£58.06
|
|
|
8 - BALL BEARING 8x22x7
BSD-1900905029.A200
1900905029
|
£21.52
|
£25.83
|
|
|
9 - SPACER RING
BSD-2600200007.A40
2600200007
|
£10.10
|
£12.12
|
|
|
10 - SPACER RING
BSD-3600202004.A69
3600202004
|
£11.30
|
£13.56
|
|
|
11 - PLAIN WASHER DIN 125-A5.3-ST
BSD-2916011012.A123
2916011012
|
£1.75
|
£2.10
|
|
|
12 - HEX SCREW
BSD-3603450000.A3
3603450000
|
£7.36
|
£8.83
|
|
|
26 - PINION
BSD-3606300020.A2
3606300020
|
-
|
|
|
|
27 - STOP DISC
BSD-3600101004.A46
3600101004
|
£2.61
|
£3.13
|
|
|
28 - RING GEAR Z=46
BSD-3606334002.A16
3606334002
|
£135.25
|
£162.30
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337032.A0
3606337032
|
-
|
|
|
|
30 - CYLINDRICAL GEAR
BSD-3606316102.A8
3606316102
|
£31.64
|
£37.97
|
|
|
31 - NEEDLE-ROLLER ASSEMBLY
BSD-3600910000.A8
3600910000
|
£4.26
|
£5.11
|
|
|
32 - NEEDLE ROLLER
BSD-3603201005.A3
3603201005
|
£2.80
|
£3.36
|
|
|
33 - RETAINING RING
BSD-3600224004.A4
3600224004
|
£1.75
|
£2.10
|
|
|
35 - GROOVE BALL BEARING 25x37x7
BSD-3600905001.A29
3600905001
|
£31.64
|
£37.97
|
|
|
36 - PLANETARY-GEAR CARRIER
BSD-3606337031.A8
3606337031
|
-
|
|
|
|
37 - CYLINDRICAL GEAR
BSD-3606316103.A22
3606316103
|
£21.68
|
£26.01
|
|
|
38 - STOP DISC
BSD-3600101005.A10
3600101005
|
£6.52
|
£7.83
|
|
|
39 - GROOVE BALL BEARING
BSD-3600905025.A59
3600905025
|
£16.41
|
£19.69
|
|
|
43 - O-RING 41.0x1.78 MM
BSD-3600210006.A16
3600210006
|
£2.16
|
£2.59
|
|
|
54 - FITTING
BSD-3603458008.A3
3603458008
|
£8.67
|
£10.41
|
|
|
55 - O-RING 10x2 MM
BSD-1900210306.A216
1900210306
|
£1.75
|
£2.10
|
|
|
56 - VALVE BODY
BSD-3605190042.A1
3605190042
|
-
|
|
|
|
60 - STRAINER
BSD-3600002000.A179
3600002000
|
£3.72
|
£4.47
|
|
|
63 - STRAIGHT PIN
BSD-3604710005.A0
3604710005
|
-
|
|
|
|
65 - O-RING 15.6x1.8 MM
BSD-3600210003.A97
3600210003
|
£1.75
|
£2.10
|
|
|
66 - STRAIGHT PIN
BSD-3604710007.A14
3604710007
|
£10.10
|
£12.12
|
|
|
67 - CONTROL LEVER
BSD-3602053001.A26
3602053001
|
£2.80
|
£3.36
|
|
|
68 - BALL dia9 MM
BSD-3603230004.A46
3603230004
|
£3.72
|
£4.47
|
|
|
69 - COMPRESSION SPRING
BSD-3604616002.A42
3604616002
|
£2.16
|
£2.59
|
|
|
70 - STRAIGHT PIN 31.0 MM
BSD-3603201032.A8
3603201032
|
£6.52
|
£7.83
|
|
|
72 - STRAIGHT PIN 3M6x24 DIN 7-C35K
BSD-2917610083.A119
2917610083
|
£1.75
|
£2.10
|
|
|
73 - STRAIGHT PIN
BSD-3604710003.A32
3604710003
|
£6.52
|
£7.83
|
|
|
74 - ADJUSTING SCREW
BSD-3603463002.A1
3603463002
|
-
|
|
|
|
75 - VALVE CONE
BSD-3603230008.A24
3603230008
|
-
|
|
|
|
76 - BALL 2 MM III DIN 5401 ST
BSD-1903230002.A62
1903230002
|
£2.16
|
£2.59
|
|
|
77 - HOLDING PIN
BSD-3603203006.A16
3603203006
|
£5.58
|
£6.70
|
|
|
78 - VALVE CONE
BSD-3603231000.A58
3603231000
|
£2.80
|
£3.36
|
|
|
79 - O-RING 1.8x1.0 MM
BSD-3600210002.A20
3600210002
|
£2.61
|
£3.13
|
|
|
80 - BALL
BSD-3603230009.A0
3603230009
|
-
|
|
|
|
91 - SILENCER
BSD-3601010001.A56
3601010001
|
£2.16
|
£2.59
|
|
|
94 - HOLDING SPRING
BSD-3601250003.A23
3601250003
|
£2.80
|
£3.36
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A94
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A280
1601110481
|
£2.16
|
£2.59
|
|
|
97 - GROOVED NAIL
BSD-3603133000.A291
3603133000
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1347
3601119236
|
£3.72
|
£4.47
|
|
|
100 - HOUSING
BSD-3605125016.A1
3605125016
|
-
|
|
|
|
101 - CLUTCH ELEMENT
BSD-3606445031.A17
3606445031
|
£218.41
|
£262.09
|
|
|
102 - DRIVE SHAFT
BSD-3606122008.A79
3606122008
|
£120.11
|
£144.13
|
|
|
103 - SLOTTED SPRING PIN 2x5 DIN 1481
BSD-2917760033.A85
2917760033
|
£1.75
|
£2.10
|
|
|
106 - COMPRESSION SPRING
BSD-3604615001.A28
3604615001
|
£2.61
|
£3.13
|
|
|
107 - COMPRESSION SPRING
BSD-3604610003.A1
3604610003
|
£3.72
|
£4.47
|
|
|
108 - COMPRESSION SPRING
BSD-3604610002.A166
3604610002
|
£3.72
|
£4.47
|
|
|
109 - COMPRESSION SPRING
BSD-3604619004.A38
3604619004
|
£6.52
|
£7.83
|
|
|
110 - RETAINING RING
BSD-3604601001.A147
3604601001
|
£2.16
|
£2.59
|
|
|
111 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A311
1903230007
|
£1.75
|
£2.10
|
|
|
112 - CLAMPING SLEEVE
BSD-3600311015.A13
3600311015
|
£31.64
|
£37.97
|
|
|
114 - BUSHING
BSD-3600202003.A0
3600202003
|
-
|
|
|
|
115 - SEALING PLATE
BSD-3600001000.A46
3600001000
|
£2.80
|
£3.36
|
|
|
116 - ADJUSTING DISC
BSD-3600134000.A63
3600134000
|
£2.80
|
£3.36
|
|
|
118 - LOCKING BOLT
BSD-3603150203.A135
3603150203
|
£45.67
|
£54.80
|
|
|
119 - COUPLING PLATE
BSD-3600114001.A32
3600114001
|
£18.96
|
£22.75
|
|
|
120 - ROUND NUT
BSD-3603301004.A68
3603301004
|
£21.68
|
£26.01
|
|
|
122 - ROLLER THRUST BEARING
BSD-3600921000.A145
3600921000
|
£6.52
|
£7.83
|
|
|
124 - SUPPORT DISC
BSD-3600101002.A114
3600101002
|
£2.16
|
£2.59
|
|
|
125 - RETAINING RING
BSD-3600224001.A23
3600224001
|
£3.72
|
£4.47
|
|
|
127 - BALL DIN 5401-5 G28
BSD-1903230009.A283
1903230009
|
£1.75
|
£2.10
|
|
|
128 - BALL DIN 5401-6 G28
BSD-1903230011.A259
1903230011
|
£2.61
|
£3.13
|
|
|
132 - SCREW PLUG
BSD-3603463000.A48
3603463000
|
£2.61
|
£3.13
|
|
|
134 - PLAIN WASHER
BSD-3600101055.A44
3600101055
|
£12.04
|
£14.45
|
|
|
140 - RETAINING RING 14 DIN 9045
BSD-2916600008.A4
2916600008
|
£2.80
|
£3.36
|
|
|
653 - SILENCER
BSD-3603462000.A42
3603462000
|
£16.41
|
£19.69
|
|
|
657 - ANGLE PIECE
BSD-3601329007.A90
3601329007
|
£4.26
|
£5.11
|
|
|
703 - HOSE FITTING dia 8 MM
BSD-3603386001.A68
3603386001
|
£16.41
|
£19.69
|
|
|
704 - SUPPORT CLAMP
BSD-3608040002.A20
3608040002
|
£72.18
|
£86.62
|
|
|
705 - AUXILIARY HANDLE M14
BSD-1602025022.A688
1602025022
|
£13.41
|
£16.09
|
|
|
705 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A732
1602025030
|
£18.96
|
£22.75
|
|
|
706 - OFFSET SCREWDRIVER DIN 911 SW10
BSD-1907950009.A68
1907950009
|
£21.68
|
£26.01
|
|
|
707 - SINGLE-HEAD ENG. WRENCH DIN 894 SW24
BSD-1907950513.A82
1907950513
|
£16.41
|
£19.69
|
|
|
713 - HEXAGON-SOCKET KEY
BSD-3607950001.A230
3607950001
|
£2.80
|
£3.36
|
|
|
750 - SILENCER
BSD-3607000073.A112
3607000073
|
£18.96
|
£22.75
|
|
|
752 - HOSE FITTING
BSD-2603386002.A211
2603386002
|
£5.30
|
£6.36
|
|
|
800 - PNEUMATIC MOTOR
BSD-3607031077.A4
3607031077
|
-
|
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031114.A1
3607031114
|
-
|
|
|
|
803 - ASSEMBLY OF SERVICE PARTS
BSD-3607031087.A81
3607031087
|
£12.04
|
£14.45
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030260.A2
3607030260
|
£21.68
|
£26.01
|
|
