1 - MOTOR HOUSING
BSD-3600760015.A8
3600760015
|
£98.57
|
£118.28
|
|
|
2 - STATOR 370W
BSD-3604090003.A34
3604090003
|
£93.88
|
£112.65
|
|
|
3 - ROTOR
BSD-3604220003.A19
3604220003
|
£81.81
|
£98.17
|
|
|
5 - BEARING FLANGE
BSD-3605700005.A95
3605700005
|
£57.14
|
£68.57
|
|
|
6 - GROOVE BALL BEARING 9x24x7 MM
BSD-3600905039.A193
3600905039
|
£12.04
|
£14.45
|
|
|
7 - BEARING FLANGE
BSD-3605700007.A38
3605700007
|
£66.68
|
£80.01
|
|
|
8 - BALL BEARING 7x19x6
BSD-2600905032.A2340
2600905032
|
£5.57
|
£6.68
|
|
|
9 - SPACER RING
BSD-2600202013.A133
2600202013
|
£8.67
|
£10.41
|
|
|
10 - SPACER RING
BSD-2600202014.A59
2600202014
|
£11.87
|
£14.24
|
|
|
11 - PLAIN WASHER DIN 125-A5.3-ST
BSD-2916011012.A234
2916011012
|
£1.84
|
£2.21
|
|
|
12 - HEX SCREW DIN 933-M5x8-8.8
BSD-2911061150.A74
2911061150
|
£2.74
|
£3.29
|
|
|
13 - INTERMEDIATE PIECE
BSD-3602305000.A23
3602305000
|
£37.27
|
£44.72
|
|
|
14 - CYLINDRICAL GEAR Z=12
BSD-3606316098.A53
3606316098
|
£27.23
|
£32.68
|
|
|
15 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A106
3600913000
|
£4.26
|
£5.11
|
|
|
16 - CYLINDRICAL GEAR Z=16
BSD-3606316099.A43
3606316099
|
£22.76
|
£27.31
|
|
|
26 - PINION Z=23
BSD-3606300002.A29
3606300002
|
£25.05
|
£30.06
|
|
|
27 - STOP DISC
BSD-3600101001.A211
3600101001
|
£2.61
|
£3.13
|
|
|
28 - RING GEAR Z=49
BSD-3606334000.A48
3606334000
|
£107.69
|
£129.23
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337002.A2
3606337002
|
£93.88
|
£112.65
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A237
3603201000
|
£1.84
|
£2.21
|
|
|
34 - SHIM WASHER
BSD-3600103002.A1
3600103002
|
£3.72
|
£4.47
|
|
|
35 - RETAINING RING
BSD-3600224000.A11
3600224000
|
£1.75
|
£2.10
|
|
|
36 - GROOVE BALL BEARING 12x28x8
BSD-1900900287.A167
1900900287
|
£21.68
|
£26.01
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337014.A11
3606337014
|
-
|
|
|
|
41 - GROOVE BALL BEARING 12x32x10
BSD-1600905007.A16
1600905007
|
£11.30
|
£13.56
|
|
|
43 - SPRING RETAINING RING
BSD-3600119000.A63
3600119000
|
£10.61
|
£12.73
|
|
|
54 - SPACER BUSHING
BSD-3600328021.A4
3600328021
|
-
|
|
|
|
56 - VALVE BODY
BSD-3605190003.A0
3605190003
|
-
|
|
|
|
57 - SILENCER
BSD-3605190014.A8
3605190014
|
-
|
|
|
|
58 - FITTING
BSD-3603458001.A26
3603458001
|
-
|
|
|
|
59 - SINTERED-METAL BUSHING
BSD-3600521000.A25
3600521000
|
-
|
|
|
|
60 - STRAINER
BSD-3600002000.A35
3600002000
|
£3.72
|
£4.47
|
|
|
61 - PLAIN WASHER
BSD-3600101003.A32
3600101003
|
-
|
|
|
|
62 - SUSPENSION LOOP
BSD-2604720004.A22
2604720004
|
£4.26
|
£5.11
|
|
|
63 - PRESSURE SPINDLE
BSD-3603123000.A6
3603123000
|
-
|
|
|
|
65 - STRAIGHT PIN 3 H 8x6 DIN 7
BSD-2917500074.A26
2917500074
|
-
|
|
|
|
66 - STRAIGHT PIN
BSD-3604710000.A23
3604710000
|
£5.87
|
£7.04
|
|
|
68 - BALL III DIN 5401 ST
BSD-1903230529.A3
1903230529
|
-
|
|
|
|
69 - COMPRESSION SPRING
BSD-3604643002.A12
3604643002
|
£2.80
|
£3.36
|
|
|
76 - O-RING 1.8x1.0 MM
BSD-3600210002.A83
3600210002
|
£2.74
|
£3.29
|
|
|
77 - CONTROL LEVER
BSD-3601902000.A8
3601902000
|
-
|
|
|
|
78 - STRAIGHT PIN 3 H 8x20 DIN 7
BSD-2917500081.A10
2917500081
|
-
|
|
|
|
79 - COMPRESSION SPRING
BSD-3604610001.A4
3604610001
|
-
|
|
|
|
90 - SILENCER
BSD-3603462000.A134
3603462000
|
£17.22
|
£20.67
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A610
160111A3HF
|
£3.91
|
£4.69
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A412
1601110481
|
£2.27
|
£2.72
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A381
3601119236
|
£3.91
|
£4.69
|
|
|
100 - HOUSING
BSD-3605125019.A2
3605125019
|
-
|
|
|
|
101 - CLUTCH ELEMENT
BSD-3606445031.A36
3606445031
|
£218.41
|
£262.09
|
|
|
103 - DRIVE SHAFT
BSD-3606122013.A6
3606122013
|
£85.90
|
£103.08
|
|
|
106 - COMPRESSION SPRING
BSD-3604615001.A25
3604615001
|
£2.74
|
£3.29
|
|
|
109 - COMPRESSION SPRING dia 3.5 MM
BSD-3604619005.A25
3604619005
|
£7.72
|
£9.27
|
|
|
110 - RETAINING RING
BSD-3604601001.A93
3604601001
|
£2.16
|
£2.59
|
|
|
111 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A833
1903230007
|
£1.84
|
£2.21
|
|
|
112 - CLAMPING SLEEVE
BSD-3600311015.A37
3600311015
|
£31.64
|
£37.97
|
|
|
114 - SINTERED-METAL BUSHING
BSD-3600301003.A10
3600301003
|
-
|
|
|
|
115 - SEALING PLATE
BSD-3600001000.A73
3600001000
|
£2.80
|
£3.36
|
|
|
116 - ADJUSTING DISC
BSD-3600134000.A76
3600134000
|
£2.94
|
£3.53
|
|
|
120 - ROUND NUT
BSD-3603301004.A142
3603301004
|
£21.68
|
£26.01
|
|
|
122 - ROLLER THRUST BEARING
BSD-3600921000.A69
3600921000
|
£6.85
|
£8.22
|
|
|
123 - SUPPORT DISC
BSD-3600103004.A9
3600103004
|
£13.12
|
£15.75
|
|
|
124 - SUPPORT DISC
BSD-3600101002.A0
3600101002
|
£2.16
|
£2.59
|
|
|
125 - RETAINING RING
BSD-3600224001.A59
3600224001
|
£3.72
|
£4.47
|
|
|
127 - BALL DIN 5401-5 G28
BSD-1903230009.A948
1903230009
|
£1.84
|
£2.21
|
|
|
128 - BALL DIN 5401-6 G28
BSD-1903230011.A461
1903230011
|
£2.74
|
£3.29
|
|
|
134 - PLAIN WASHER
BSD-3600101055.A4
3600101055
|
£12.04
|
£14.45
|
|
|
140 - RETAINING RING 14 DIN 9045
BSD-2916600008.A265
2916600008
|
£2.80
|
£3.36
|
|
|
652 - HOSE FITTING
BSD-2603386002.A119
2603386002
|
£5.30
|
£6.36
|
|
|
657 - ANGLE PIECE
BSD-3601329007.A141
3601329007
|
£4.48
|
£5.37
|
|
|
703 - HOSE FITTING dia 8 MM
BSD-3603386001.A11
3603386001
|
£16.41
|
£19.69
|
|
|
704 - SUPPORT CLAMP
BSD-3608040000.A79
3608040000
|
-
|
|
|
|
705 - AUXILIARY HANDLE M14
BSD-1602025022.A1318
1602025022
|
£13.41
|
£16.09
|
|
|
705 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A1186
1602025030
|
£19.91
|
£23.89
|
|
|
705 - HANDLE
BSD-3600499000.A38
3600499000
|
-
|
|
|
|
706 - SILENCER
BSD-3607000073.A93
3607000073
|
£19.91
|
£23.89
|
|
|
707 - OFFSET SCREWDRIVER DIN 911 SW10
BSD-1907950009.A164
1907950009
|
£22.76
|
£27.31
|
|
|
708 - SINGLE-HEAD ENG. WRENCH DIN 894 SW24
BSD-1907950513.A12
1907950513
|
£17.22
|
£20.67
|
|
|
713 - HEXAGON-SOCKET KEY
BSD-3607950001.A134
3607950001
|
£2.80
|
£3.36
|
|
|
801 - ASSEMBLY OF SERVICE PARTS
BSD-3607031019.A0
3607031019
|
-
|
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031108.A5
3607031108
|
-
|
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030248.A5
3607030248
|
£33.22
|
£39.87
|
|
|
855 - O-RING 10x2 MM
BSD-1900210306.A28
1900210306
|
£1.84
|
£2.21
|
|
