1 - MOTOR HOUSING
BSD-3605108031.A4
3605108031
|
-
|
|
|
|
2 - STATOR 180W
BSD-3604090010.A11
3604090010
|
£85.90
|
£103.08
|
|
|
3 - ROTOR
BSD-3604220008.A11
3604220008
|
£72.18
|
£86.62
|
|
|
5 - BEARING FLANGE
BSD-3605700015.A34
3605700015
|
£47.95
|
£57.54
|
|
|
6 - BALL BEARING 7x19x6
BSD-2600905032.A1272
2600905032
|
£5.57
|
£6.68
|
|
|
7 - BEARING FLANGE
BSD-3605700017.A13
3605700017
|
£50.80
|
£60.96
|
|
|
8 - GROOVE BALL BEARING 7x17x5
BSD-1900905028.A103
1900905028
|
£33.74
|
£40.49
|
|
|
11 - PLAIN WASHER DIN 433-5.3-ST
BSD-2916011011.A247
2916011011
|
£1.75
|
£2.10
|
|
|
12 - HEX SCREW
BSD-3603450002.A13
3603450002
|
£25.05
|
£30.06
|
|
|
26 - PINION Z=12
BSD-3606300014.A53
3606300014
|
£15.49
|
£18.59
|
|
|
27 - STOP DISC
BSD-3600101047.A26
3600101047
|
£2.16
|
£2.59
|
|
|
28 - RING GEAR Z=42/54
BSD-3606334021.A3
3606334021
|
£18.96
|
£22.75
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337057.A3
3606337057
|
£50.80
|
£60.96
|
|
|
31 - CYLINDRICAL GEAR Z=14
BSD-3606316093.A41
3606316093
|
£2.74
|
£3.29
|
|
|
32 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A402
3600913000
|
£4.26
|
£5.11
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A26
3603201000
|
£1.84
|
£2.21
|
|
|
36 - GROOVE BALL BEARING 12x21x5
BSD-3600905002.A172
3600905002
|
£16.41
|
£19.69
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337015.A24
3606337015
|
£98.57
|
£118.28
|
|
|
39 - CYLINDRICAL GEAR
BSD-3606316114.A55
3606316114
|
£13.78
|
£16.54
|
|
|
41 - GROOVE BALL BEARING
BSD-3600905015.A167
3600905015
|
£17.22
|
£20.67
|
|
|
56 - FITTING
BSD-3603458009.A31
3603458009
|
-
|
|
|
|
57 - GUIDE SLEEVE
BSD-3600364002.A0
3600364002
|
£15.65
|
£18.78
|
|
|
60 - STRAINER
BSD-3600002001.A58
3600002001
|
£2.61
|
£3.13
|
|
|
63 - STRAIGHT PIN
BSD-3604710008.A11
3604710008
|
-
|
|
|
|
65 - NEEDLE ROLLER DIN 5402-A 2x19.8G5
BSD-3603100026.A12
3603100026
|
£2.27
|
£2.72
|
|
|
66 - STRAIGHT PIN
BSD-3603201012.A12
3603201012
|
-
|
|
|
|
67 - VALVE SPOOL
BSD-3608750003.A17
3608750003
|
£10.10
|
£12.12
|
|
|
68 - NEEDLE ROLLER DIN 5402-A 2x19.8G5
BSD-3603100026.A11
3603100026
|
£2.27
|
£2.72
|
|
|
69 - O-RING 15x2 MM
BSD-1900210112.A17
1900210112
|
£2.61
|
£3.13
|
|
|
70 - BALL dia9 MM
BSD-3603230004.A90
3603230004
|
£3.91
|
£4.69
|
|
|
71 - COMPRESSION SPRING
BSD-3604643003.A7
3604643003
|
£1.75
|
£2.10
|
|
|
75 - INTERMEDIATE PIECE
BSD-3602305006.A18
3602305006
|
£5.87
|
£7.04
|
|
|
76 - THREADED RING
BSD-3603344003.A14
3603344003
|
£2.61
|
£3.13
|
|
|
77 - CONTROL LEVER
BSD-3602053000.A2
3602053000
|
-
|
|
|
|
78 - STRAIGHT PIN 3M6x24 DIN 7-C35K
BSD-2917610083.A144
2917610083
|
£1.75
|
£2.10
|
|
|
83 - COMPRESSION SPRING
BSD-3604611006.A9
3604611006
|
£2.27
|
£2.72
|
|
|
88 - SILENCER
BSD-3601010004.A42
3601010004
|
£2.16
|
£2.59
|
|
|
89 - SILENCER
BSD-3601010001.A1
3601010001
|
£2.16
|
£2.59
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A212
160111A3HF
|
£3.91
|
£4.69
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A108
1601110481
|
£2.27
|
£2.72
|
|
|
97 - GROOVED NAIL
BSD-3603133000.A14
3603133000
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1911
3601119236
|
£3.91
|
£4.69
|
|
|
100 - HOUSING
BSD-3605125011.A32
3605125011
|
£50.80
|
£60.96
|
|
|
101 - CLUTCH ELEMENT
BSD-3606432006.A1
3606432006
|
£85.90
|
£103.08
|
|
|
102 - DRIVE SHAFT
BSD-3606122011.A28
3606122011
|
£126.12
|
£151.34
|
|
|
106 - COMPRESSION SPRING
BSD-3604615000.A1
3604615000
|
£1.84
|
£2.21
|
|
|
107 - COMPRESSION SPRING
BSD-3604610006.A16
3604610006
|
£2.27
|
£2.72
|
|
|
108 - COMPRESSION SPRING
BSD-3604610002.A112
3604610002
|
£3.91
|
£4.69
|
|
|
109 - COMPRESSION SPRING
BSD-3604619003.A61
3604619003
|
£5.58
|
£6.70
|
|
|
110 - RETAINING RING
BSD-3604601002.A26
3604601002
|
£1.84
|
£2.21
|
|
|
113 - UNION NUT
BSD-3603340000.A0
3603340000
|
£4.26
|
£5.11
|
|
|
114 - BUSHING
BSD-3600202000.A0
3600202000
|
£5.87
|
£7.04
|
|
|
115 - SEALING PLATE
BSD-3600001002.A78
3600001002
|
£3.72
|
£4.47
|
|
|
116 - ADJUSTING DISC
BSD-3600134003.A37
3600134003
|
£2.74
|
£3.29
|
|
|
118 - LOCKING BOLT
BSD-3603150203.A113
3603150203
|
£45.67
|
£54.80
|
|
|
119 - SUPPORT DISC
BSD-3600114002.A74
3600114002
|
£12.04
|
£14.45
|
|
|
120 - ROUND NUT
BSD-3603344009.A41
3603344009
|
£28.59
|
£34.31
|
|
|
124 - COUPLING PLATE
BSD-3600220001.A39
3600220001
|
£11.87
|
£14.24
|
|
|
126 - LEAF SPRING
BSD-2601250001.A85
2601250001
|
£3.72
|
£4.47
|
|
|
127 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A193
1903230007
|
£1.84
|
£2.21
|
|
|
128 - BALL DIN 5401-5 G28
BSD-1903230009.A199
1903230009
|
£1.84
|
£2.21
|
|
|
129 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A478
1903230003
|
£2.74
|
£3.29
|
|
|
130 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A479
1903230003
|
£2.74
|
£3.29
|
|
|
132 - SCREW PLUG
BSD-3603463000.A0
3603463000
|
£2.74
|
£3.29
|
|
|
133 - SLOTTED SPRING PIN 2x5 DIN 1481
BSD-2917760033.A57
2917760033
|
£1.75
|
£2.10
|
|
|
140 - RETAINING RING 14 DIN 9045
BSD-2916600008.A47
2916600008
|
£2.80
|
£3.36
|
|
|
651 - GUIDE SLEEVE
BSD-3600329000.A100
3600329000
|
£7.72
|
£9.27
|
|
|
652 - HOSE FITTING
BSD-3603386002.A70
3603386002
|
£3.34
|
£4.01
|
|
|
653 - SILENCER
BSD-3607000074.A3
3607000074
|
£25.05
|
£30.06
|
|
|
657 - ANGLE PIECE
BSD-3601329007.A59
3601329007
|
£4.48
|
£5.37
|
|
|
701 - GUIDE SLEEVE
BSD-3600328003.A4
3600328003
|
-
|
|
|
|
706 - COMPRESSION SPRING
BSD-3604618003.A64
3604618003
|
£7.72
|
£9.27
|
|
|
708 - SINGLE-HEAD ENG. WRENCH SW22
BSD-1607950505.A124
1607950505
|
£17.22
|
£20.67
|
|
|
712 - HEXAGON-SOCKET KEY
BSD-3607950001.A215
3607950001
|
£2.80
|
£3.36
|
|
|
801 - CUTOFF COUPLING SP SET
BSD-3607031117.A4
3607031117
|
£264.25
|
£317.10
|
|
|
802 - MOTOR
BSD-3607031045.A18
3607031045
|
-
|
|
|
|
803 - PARTS SET
BSD-3607010016.A19
3607010016
|
-
|
|
|
|
804 - PARTS SET
BSD-3607030256.A38
3607030256
|
£31.95
|
£38.34
|
|
|
821 - ASSEMBLY OF SERVICE PARTS
BSD-3607031087.A112
3607031087
|
£12.64
|
£15.17
|
|
|
843 - PARTS SET
BSD-3607010010.A72
3607010010
|
£7.36
|
£8.83
|
|
|
855 - PARTS SET
BSD-3607010000.A60
3607010000
|
£5.87
|
£7.04
|
|
|
882 - O-RING
BSD-3607010006.A141
3607010006
|
£33.22
|
£39.87
|
|
