1 - MOTOR HOUSING
BSD-3600760097.A12
3600760097
|
£73.75
|
£88.50
|
|
|
2 - STATOR 120W
BSD-3604090058.A26
3604090058
|
£135.25
|
£162.30
|
|
|
3 - ROTOR
BSD-3604220087.A0
3604220087
|
£107.69
|
£129.23
|
|
|
5 - BEARING FLANGE
BSD-3605700111.A0
3605700111
|
£42.84
|
£51.41
|
|
|
6 - GROOVE BALL BEARING 7x19x6
BSD-1900905044.A87
1900905044
|
£7.72
|
£9.27
|
|
|
7 - BEARING FLANGE
BSD-3605700112.A24
3605700112
|
£48.38
|
£58.06
|
|
|
8 - GROOVE BALL BEARING 7x14x5
BSD-1900905030.A39
1900905030
|
£33.74
|
£40.49
|
|
|
26 - PINION Z=15
BSD-3606300015.A23
3606300015
|
-
|
|
|
|
27 - STOP DISC
BSD-3600101008.A40
3600101008
|
£1.75
|
£2.10
|
|
|
28 - RING GEAR Z=42/54
BSD-3606334083.A1
3606334083
|
£21.52
|
£25.83
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337181.A7
3606337181
|
£48.38
|
£58.06
|
|
|
30 - SPACER RING
BSD-3600209013.A38
3600209013
|
£5.87
|
£7.04
|
|
|
31 - CYLINDRICAL GEAR Z=13
BSD-3606316010.A7
3606316010
|
-
|
|
|
|
32 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A200
3600913000
|
£4.26
|
£5.11
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A414
3603201000
|
£1.84
|
£2.21
|
|
|
35 - NEEDLE ROLLER DIN 5402-A3x11.8-G2
BSD-1903201042.A278
1903201042
|
£2.27
|
£2.72
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337191.A11
3606337191
|
£63.50
|
£76.20
|
|
|
39 - CYLINDRICAL GEAR
BSD-3606316114.A75
3606316114
|
£13.78
|
£16.54
|
|
|
41 - GROOVE BALL BEARING
BSD-3600905023.A0
3600905023
|
£22.60
|
£27.12
|
|
|
43 - SPRING RETAINING RING
BSD-3600118006.A21
3600118006
|
£2.74
|
£3.29
|
|
|
54 - COMPRESSION SPRING
BSD-3604611017.A108
3604611017
|
£2.74
|
£3.29
|
|
|
56 - VALVE HOUSING
BSD-3605190178.A0
3605190178
|
£39.13
|
£46.96
|
|
|
58 - O-RING 4.3x2.4 MM
BSD-3600210084.A56
3600210084
|
£2.61
|
£3.13
|
|
|
60 - STRAINER
BSD-3600002000.A74
3600002000
|
£3.72
|
£4.47
|
|
|
61 - O-RING 9.0x1.5 MM
BSD-2600210021.A64
2600210021
|
£1.75
|
£2.10
|
|
|
62 - FITTING
BSD-3603458016.A0
3603458016
|
£11.87
|
£14.24
|
|
|
63 - STRAIGHT PIN 75 MM
BSD-3603201006.A25
3603201006
|
£3.91
|
£4.69
|
|
|
65 - STRAIGHT PIN
BSD-3603201001.A0
3603201001
|
£4.26
|
£5.11
|
|
|
66 - STRAIGHT PIN
BSD-3604710044.A27
3604710044
|
£8.67
|
£10.41
|
|
|
68 - BALL DIN 5401-8 MM III-ST
BSD-1903230014.A6
1903230014
|
£1.75
|
£2.10
|
|
|
71 - CONTROL PISTON
BSD-3608750038.A0
3608750038
|
£25.05
|
£30.06
|
|
|
72 - COILED SPRING PIN DIN 7343-1.5x10
BSD-2917800016.A50
2917800016
|
£1.75
|
£2.10
|
|
|
74 - COMPRESSION SPRING
BSD-3604611007.A1
3604611007
|
£2.16
|
£2.59
|
|
|
76 - O-RING
BSD-3600210094.A71
3600210094
|
£2.94
|
£3.53
|
|
|
79 - O-RING
BSD-3600210093.A2
3600210093
|
£1.84
|
£2.21
|
|
|
82 - O-RING 26.0x1.0 MM
BSD-3600210056.A0
3600210056
|
£1.84
|
£2.21
|
|
|
87 - SILENCER
BSD-3601010010.A17
3601010010
|
£2.16
|
£2.59
|
|
|
88 - SILENCER
BSD-3601010037.A45
3601010037
|
£11.87
|
£14.24
|
|
|
89 - SILENCER
BSD-3601010044.A31
3601010044
|
£7.72
|
£9.27
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A410
160111A3HF
|
£3.91
|
£4.69
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601119055.A104
3601119055
|
£3.72
|
£4.47
|
|
|
98 - STICKER
BSD-3601110204.A79
3601110204
|
£1.75
|
£2.10
|
|
|
99 - REFERENCE PLATE
BSD-3601110574.A17
3601110574
|
£2.74
|
£3.29
|
|
|
100 - HOUSING
BSD-3605125056.A2
3605125056
|
£62.51
|
£75.01
|
|
|
101 - CLUTCH ELEMENT
BSD-3606445043.A143
3606445043
|
£102.57
|
£123.08
|
|
|
102 - OUTPUT SHAFT
BSD-3603124022.A11
3603124022
|
£107.69
|
£129.23
|
|
|
106 - COMPRESSION SPRING
BSD-3604610011.A15
3604610011
|
£2.94
|
£3.53
|
|
|
109 - COMPRESSION SPRING
BSD-3604619003.A115
3604619003
|
£5.58
|
£6.70
|
|
|
110 - RETAINING RING
BSD-3600224053.A40
3600224053
|
£1.84
|
£2.21
|
|
|
113 - CLAMP BUSHING
BSD-3600499023.A68
3600499023
|
£19.91
|
£23.89
|
|
|
114 - PLAIN BEARING
BSD-3600921001.A106
3600921001
|
£10.61
|
£12.73
|
|
|
115 - SEALING PLATE
BSD-3601023011.A115
3601023011
|
£2.61
|
£3.13
|
|
|
116 - SETTING RING
BSD-3600134014.A92
3600134014
|
£31.64
|
£37.97
|
|
|
119 - SUPPORT DISC
BSD-3600190038.A58
3600190038
|
£19.91
|
£23.89
|
|
|
120 - CATCH DISK
BSD-3603344047.A29
3603344047
|
£23.86
|
£28.63
|
|
|
125 - BACKUP RING
BSD-3600202020.A22
3600202020
|
£9.11
|
£10.93
|
|
|
126 - RETAINING RING
BSD-3600224006.A171
3600224006
|
£2.80
|
£3.36
|
|
|
127 - BALL DIN 5401-3.5 MM-III-ST
BSD-1903230006.A179
1903230006
|
£2.27
|
£2.72
|
|
|
128 - BALL 4.5 MM III DIN 5401-ST
BSD-1903230008.A65
1903230008
|
£1.75
|
£2.10
|
|
|
129 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A217
1903230003
|
£2.74
|
£3.29
|
|
|
133 - WASHER
BSD-3600190024.A0
3600190024
|
£2.27
|
£2.72
|
|
|
140 - LOCKING WASHER DIN 6799-9-FSt
BSD-2916080012.A88
2916080012
|
£1.84
|
£2.21
|
|
|
141 - PROTECTION SLEEVE
BSD-3600400030.A11
3600400030
|
£7.72
|
£9.27
|
|
|
143 - O-RING 9.0x1.2 MM
BSD-3600210038.A121
3600210038
|
£2.61
|
£3.13
|
|
|
145 - O-RING
BSD-3600210116.A28
3600210116
|
£2.94
|
£3.53
|
|
|
146 - STRAIGHT PIN
BSD-3604710069.A4
3604710069
|
£4.48
|
£5.37
|
|
|
652 - HOSE FITTING
BSD-3603386066.A78
3603386066
|
£14.91
|
£17.89
|
|
|
657 - SCREWDRIVER
BSD-3607950027.A122
3607950027
|
£15.65
|
£18.78
|
|
|
701 - HOUSING
BSD-3605125058.A9
3605125058
|
£81.81
|
£98.17
|
|
|
702 - HANDLE
BSD-3600499002.A40
3600499002
|
£22.76
|
£27.31
|
|
|
706 - COMPRESSION SPRING
BSD-3604618003.A82
3604618003
|
£7.72
|
£9.27
|
|
|
712 - HEXAGON-SOCKET KEY
BSD-3607950001.A36
3607950001
|
£2.80
|
£3.36
|
|
|
760 - SUSPENSION LOOP
BSD-2604720004.A9
2604720004
|
£4.26
|
£5.11
|
|
|
801 - OVERRIDING CLUTCH
BSD-3607031501.A7
3607031501
|
£375.13
|
£450.16
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031303.A20
3607031303
|
£410.78
|
£492.94
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607031305.A22
3607031305
|
£23.86
|
£28.63
|
|
|
808 - ASSEMBLY OF SERVICE PARTS
BSD-3607031425.A13
3607031425
|
£251.67
|
£302.00
|
|
|
809 - ASSEMBLY OF SERVICE PARTS
BSD-3607031422.A12
3607031422
|
£164.02
|
£196.83
|
|
|
821 - STRAIGHT PIN
BSD-3604710064.A10
3604710064
|
£3.91
|
£4.69
|
|
|
859 - HOLDING BELT
BSD-3604710062.A81
3604710062
|
£1.84
|
£2.21
|
|
|
882 - PARTS SET
BSD-3607031524.A3
3607031524
|
£10.61
|
£12.73
|
|
|
890 - AUXILIARY HANDLE
BSD-3607031352.A1
3607031352
|
£98.57
|
£118.28
|
|
|
891 - AIR HOSE
BSD-3607000083.A1
3607000083
|
£62.51
|
£75.01
|
|
|
899 - AIR HOSE
BSD-3607000064.A72
3607000064
|
£27.23
|
£32.68
|
|
