1 - MOTOR HOUSING
BSD-3600760022.A11
3600760022
|
£63.50
|
£76.20
|
|
|
2 - STATOR 120W
BSD-3604090014.A18
3604090014
|
£81.81
|
£98.17
|
|
|
3 - ROTOR
BSD-3604220012.A4
3604220012
|
£72.18
|
£86.62
|
|
|
5 - BEARING FLANGE
BSD-3605700023.A41
3605700023
|
£23.86
|
£28.63
|
|
|
6 - BALL BEARING 7x19x6
BSD-2600905032.A2298
2600905032
|
£5.30
|
£6.36
|
|
|
7 - BEARING FLANGE
BSD-3605700030.A1
3605700030
|
£68.42
|
£82.10
|
|
|
8 - GROOVE BALL BEARING 7x14x5
BSD-1900905030.A70
1900905030
|
£33.74
|
£40.49
|
|
|
11 - PLAIN WASHER DIN 125-A5.3-ST
BSD-2916011012.A250
2916011012
|
£1.75
|
£2.10
|
|
|
12 - HEX SCREW
BSD-3603450000.A51
3603450000
|
£7.36
|
£8.83
|
|
|
25 - SHIM WASHER
BSD-3600100007.A26
3600100007
|
£1.75
|
£2.10
|
|
|
26 - PINION Z=9
BSD-3606300046.A22
3606300046
|
£21.42
|
£25.71
|
|
|
27 - STOP DISC
BSD-3600101008.A27
3600101008
|
£1.75
|
£2.10
|
|
|
28 - RING GEAR Z=42
BSD-3606334011.A6
3606334011
|
£63.50
|
£76.20
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337041.A1
3606337041
|
£93.88
|
£112.65
|
|
|
31 - CYLINDRICAL GEAR
BSD-3606316112.A10
3606316112
|
£21.68
|
£26.01
|
|
|
32 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A179
3600913000
|
£4.26
|
£5.11
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A282
3603201000
|
£1.75
|
£2.10
|
|
|
34 - STOP DISC
BSD-3600103003.A54
3600103003
|
£2.80
|
£3.36
|
|
|
35 - RETAINING RING
BSD-3600224002.A2
3600224002
|
£1.75
|
£2.10
|
|
|
36 - GROOVE BALL BEARING 12x21x5
BSD-3600905002.A63
3600905002
|
£16.41
|
£19.69
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337040.A1
3606337040
|
-
|
|
|
|
39 - CYLINDRICAL GEAR
BSD-3606316112.A11
3606316112
|
£21.68
|
£26.01
|
|
|
41 - GROOVE BALL BEARING 8x22x7
BSD-1900905041.A132
1900905041
|
£13.12
|
£15.75
|
|
|
41 - GROOVE BALL BEARING 8x22x7
BSD-1900905041.A133
1900905041
|
£13.12
|
£15.75
|
|
|
42 - O-RING 22x2 MM
BSD-1900210321.A25
1900210321
|
£5.30
|
£6.36
|
|
|
56 - VALVE HOUSING
BSD-3605190037.A5
3605190037
|
-
|
|
|
|
57 - HOUSING COVER
BSD-3605500006.A11
3605500006
|
£2.16
|
£2.59
|
|
|
59 - SILENCER
BSD-3600002002.A8
3600002002
|
£3.72
|
£4.47
|
|
|
60 - STRAINER
BSD-3600002001.A181
3600002001
|
£2.61
|
£3.13
|
|
|
62 - SUSPENSION LOOP
BSD-2604720004.A57
2604720004
|
£4.26
|
£5.11
|
|
|
63 - STRAIGHT PIN
BSD-3604710011.A11
3604710011
|
£1.95
|
£2.34
|
|
|
65 - STRAIGHT PIN
BSD-3603201016.A4
3603201016
|
-
|
|
|
|
66 - STRAIGHT PIN
BSD-3603201001.A19
3603201001
|
£4.26
|
£5.11
|
|
|
68 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A281
1903230013
|
£2.16
|
£2.59
|
|
|
69 - COMPRESSION SPRING
BSD-3604611006.A81
3604611006
|
£2.16
|
£2.59
|
|
|
71 - CONTROL PISTON
BSD-3608750004.A9
3608750004
|
-
|
|
|
|
72 - COILED SPRING PIN 1.5x8 DIN 7343
BSD-2917800015.A9
2917800015
|
£1.75
|
£2.10
|
|
|
74 - COMPRESSION SPRING
BSD-3604643008.A5
3604643008
|
£2.16
|
£2.59
|
|
|
76 - THREADED RING
BSD-3603344003.A57
3603344003
|
£2.61
|
£3.13
|
|
|
82 - O-RING 20.0x1.0 MM
BSD-3600210012.A33
3600210012
|
£2.80
|
£3.36
|
|
|
86 - COUNTERSUNK-HEAD SCREW M 3x10 DIN 963-5.8
BSD-2910771052.A15
2910771052
|
-
|
|
|
|
87 - SEALING PLATE
BSD-3600054000.A18
3600054000
|
£2.16
|
£2.59
|
|
|
88 - SILENCER
BSD-3601010002.A13
3601010002
|
£2.80
|
£3.36
|
|
|
89 - SILENCER
BSD-3601010001.A111
3601010001
|
£2.16
|
£2.59
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A635
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A396
1601110481
|
£2.16
|
£2.59
|
|
|
97 - GROOVED NAIL
BSD-3603133000.A492
3603133000
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A465
3601119236
|
£3.72
|
£4.47
|
|
|
100 - HOUSING
BSD-3605125009.A1
3605125009
|
-
|
|
|
|
101 - CLUTCH ELEMENT
BSD-3606445035.A3
3606445035
|
£70.24
|
£84.29
|
|
|
102 - DRIVE SHAFT
BSD-3606122012.A9
3606122012
|
£93.88
|
£112.65
|
|
|
106 - COMPRESSION SPRING
BSD-3604610011.A41
3604610011
|
£2.80
|
£3.36
|
|
|
107 - COMPRESSION SPRING
BSD-3604610008.A21
3604610008
|
£1.75
|
£2.10
|
|
|
108 - COMPRESSION SPRING
BSD-3604610007.A15
3604610007
|
£1.75
|
£2.10
|
|
|
109 - COMPRESSION SPRING
BSD-3604619007.A28
3604619007
|
£2.80
|
£3.36
|
|
|
110 - RETAINING RING
BSD-3604603000.A9
3604603000
|
-
|
|
|
|
113 - CLAMP BUSHING
BSD-3600499023.A137
3600499023
|
£18.96
|
£22.75
|
|
|
114 - SINTERED-METAL BUSHING
BSD-3600301005.A7
3600301005
|
-
|
|
|
|
115 - SEALING PLATE
BSD-3600001003.A21
3600001003
|
-
|
|
|
|
116 - ADJUSTING DISC
BSD-3600134002.A7
3600134002
|
£1.75
|
£2.10
|
|
|
118 - LOCKING BOLT
BSD-3603150201.A8
3603150201
|
£21.68
|
£26.01
|
|
|
119 - SUPPORT DISC
BSD-3600114007.A18
3600114007
|
£10.10
|
£12.12
|
|
|
120 - ROUND NUT
BSD-3603340003.A18
3603340003
|
£23.86
|
£28.63
|
|
|
124 - COUPLING PLATE
BSD-3600114005.A18
3600114005
|
£7.36
|
£8.83
|
|
|
125 - BACKUP RING
BSD-3600202020.A83
3600202020
|
£8.67
|
£10.41
|
|
|
126 - RETAINING RING
BSD-3600224008.A25
3600224008
|
£2.16
|
£2.59
|
|
|
127 - BALL DIN 5401-3 MM-III-ST
BSD-1903230004.A410
1903230004
|
£2.16
|
£2.59
|
|
|
128 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A790
1903230007
|
£1.75
|
£2.10
|
|
|
129 - BALL DIN 5401-5 G28
BSD-1903230009.A908
1903230009
|
£1.75
|
£2.10
|
|
|
130 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A76
1903230003
|
£2.61
|
£3.13
|
|
|
131 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A77
1903230003
|
£2.61
|
£3.13
|
|
|
132 - SCREW PLUG
BSD-3603463001.A6
3603463001
|
£2.16
|
£2.59
|
|
|
133 - SLOTTED SPRING PIN DIN 1481-1.5x4
BSD-2917760012.A5
2917760012
|
£1.75
|
£2.10
|
|
|
135 - STOP DISC
BSD-3600113003.A9
3600113003
|
£1.75
|
£2.10
|
|
|
140 - RETAINING RING 12 DIN 9045
BSD-2916600007.A34
2916600007
|
£2.80
|
£3.36
|
|
|
653 - ANGLE PIECE
BSD-3601329007.A156
3601329007
|
£4.26
|
£5.11
|
|
|
702 - HANDLE
BSD-3600499002.A15
3600499002
|
£21.68
|
£26.01
|
|
|
704 - HOSE FITTING
BSD-3607010011.A50
3607010011
|
-
|
|
|
|
705 - CLUTCH ELEMENT
BSD-3607031085.A26
3607031085
|
-
|
|
|
|
706 - COMPRESSION SPRING
BSD-3604618007.A10
3604618007
|
£4.75
|
£5.70
|
|
|
707 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A210
2607950511
|
£4.26
|
£5.11
|
|
|
712 - HEXAGON-SOCKET KEY
BSD-3607950001.A89
3607950001
|
£2.80
|
£3.36
|
|
|
752 - HOSE FITTING
BSD-3603386002.A165
3603386002
|
£3.34
|
£4.01
|
|
|
801 - CUTOFF COUPLING SP SET
BSD-3607031130.A3
3607031130
|
-
|
|
|
|
802 - MOTOR SPARE PARTS SET
BSD-3607031104.A1
3607031104
|
-
|
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030259.A8
3607030259
|
£31.64
|
£37.97
|
|
|
821 - ASSEMBLY OF SERVICE PARTS
BSD-3607031086.A3
3607031086
|
£8.67
|
£10.41
|
|
|
843 - SPRING RETAINING RING
BSD-3607010009.A7
3607010009
|
-
|
|
|
