3 - LOCATING RING
BSD-3600200043.A13
3600200043
|
£5.30
|
£6.36
|
|
|
5 - STICKER
BSD-3601110245.A0
3601110245
|
-
|
|
|
|
6 - STICKER
BSD-2601110606.A0
2601110606
|
£1.75
|
£2.10
|
|
|
20 - STICKER
BSD-3601110256.A8
3601110256
|
£4.75
|
£5.70
|
|
|
25 - RETAINING RING 10 DIN 9045
BSD-2916600006.A122
2916600006
|
£1.75
|
£2.10
|
|
|
26 - TOOL HOLDING FIXTURE
BSD-3607218009.A5
3607218009
|
-
|
|
|
|
27 - PLAIN WASHER DIN 433-A13-ST 50
BSD-2916011019.A23
2916011019
|
£2.16
|
£2.59
|
|
|
28 - BALL DIN 5401-5 G28
BSD-1903230009.A705
1903230009
|
£1.75
|
£2.10
|
|
|
29 - COMPRESSION SPRING
BSD-3604611023.A4
3604611023
|
-
|
|
|
|
30 - TAPPING SCREW DIN 7972-ST 2.2x6.5-C
BSD-2910601101.A9
2910601101
|
-
|
|
|
|
31 - BEARING PLATE
BSD-3601023007.A5
3601023007
|
-
|
|
|
|
32 - RETAINING RING
BSD-3604601001.A71
3604601001
|
£2.16
|
£2.59
|
|
|
33 - COUPLING HALF
BSD-3606455036.A1
3606455036
|
-
|
|
|
|
34 - COUPLING WHEEL
BSD-3606455039.A5
3606455039
|
£88.07
|
£105.68
|
|
|
35 - ROLLER THRUST BEARING
BSD-3600929008.A8
3600929008
|
£10.10
|
£12.12
|
|
|
36 - SPRING RETAINING RING DIN 471-10x1MM-FSt
BSD-2916650001.A21
2916650001
|
£2.61
|
£3.13
|
|
|
37 - GROOVE BALL BEARING
BSD-1600900042.A42
1600900042
|
£5.58
|
£6.70
|
|
|
40 - SPRING RETAINING RING DIN 472-26x1.2 MM
BSD-2916660010.A92
2916660010
|
£1.75
|
£2.10
|
|
|
41 - CATCH DISK
BSD-3600106002.A0
3600106002
|
-
|
|
|
|
42 - BUSHING
BSD-3600311012.A5
3600311012
|
-
|
|
|
|
43 - SUPPORT DISC
BSD-3600106003.A13
3600106003
|
-
|
|
|
|
44 - ROUND NUT
BSD-3603400003.A13
3603400003
|
-
|
|
|
|
45 - BALL DIN 5401-6 G28
BSD-1903230011.A393
1903230011
|
£2.61
|
£3.13
|
|
|
46 - SEALING PLATE
BSD-3601023008.A8
3601023008
|
-
|
|
|
|
47 - ACTUATING ELEMENT
BSD-3601923007.A0
3601923007
|
-
|
|
|
|
48 - PLAIN BEARING
BSD-3600917038.A13
3600917038
|
-
|
|
|
|
49 - TAPPING SCREW DIN 7981-ST3.9x16-C-H
BSD-2910611019.A531
2910611019
|
£2.80
|
£3.36
|
|
|
53 - PINION Z=14
BSD-2606316120.A51
2606316120
|
-
|
|
|
|
54 - PLAIN BEARING
BSD-3600917037.A0
3600917037
|
-
|
|
|
|
55 - SHIM 0.3 MM
BSD-2600100636.A92
2600100636
|
-
|
|
|
|
58 - COUPLING PLATE
BSD-3606455038.A0
3606455038
|
-
|
|
|
|
59 - COMPRESSION SPRING
BSD-3604611021.A8
3604611021
|
-
|
|
|
|
66 - CONTACT SPRING
BSD-2601324012.A124
2601324012
|
£1.75
|
£2.10
|
|
|
71 - HOLDING SPRING dia8.7 MM
BSD-2601251003.A103
2601251003
|
-
|
|
|
|
73 - CLAMPING SLEEVE
BSD-3600422006.A0
3600422006
|
-
|
|
|
|
74 - BALL DIN 5401-3 MM-III-ST
BSD-1903230004.A341
1903230004
|
£2.16
|
£2.59
|
|
|
75 - COMPRESSION SPRING
BSD-3604615009.A22
3604615009
|
£2.16
|
£2.59
|
|
|
76 - RETAINING RING
BSD-3600224006.A117
3600224006
|
£2.80
|
£3.36
|
|
|
78 - STOP DISC dia11.15xdia12.85 MM
BSD-3600101039.A6
3600101039
|
£2.16
|
£2.59
|
|
|
80 - SWITCH SLIDE
BSD-3608750036.A8
3608750036
|
-
|
|
|
|
81 - LED-HOLDER
BSD-3608750037.A5
3608750037
|
-
|
|
|
|
85 - GUIDE PIECE
BSD-3602329026.A13
3602329026
|
-
|
|
|
|
86 - SWITCH
BSD-3607200063.A8
3607200063
|
-
|
|
|
|
87 - SPRING HOLDER
BSD-3602329027.A0
3602329027
|
-
|
|
|
|
88 - COMPRESSION SPRING
BSD-3604611022.A2
3604611022
|
£3.72
|
£4.47
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A20
3601119236
|
£3.72
|
£4.47
|
|
|
105 - FILLER PIECE
BSD-2605510027.A0
2605510027
|
-
|
|
|
|
650 - SCREWDRIVER
BSD-3607950014.A5
3607950014
|
-
|
|
|
|
651 - HEXAGON-SOCKET KEY
BSD-3607950001.A140
3607950001
|
£2.80
|
£3.36
|
|
|
700 - AUXILIARY HANDLE dia43 MM
BSD-2602025032.A58
2602025032
|
-
|
|
|
|
753 - FAST CHARGER EU 230/7.2-14.4V. 30 MIN.
BSD-2607224701.A410
2607224701
|
£88.07
|
£105.68
|
|
|
753 - FAST CHARGER EU 230/7.2-24V. 1h
BSD-2607224425.A306
2607224425
|
£88.07
|
£105.68
|
|
|
791 - ACCUMULATOR BATTERY 9.6V.1.4Ah.NiCd
BSD-2607335023.A4
2607335023
|
-
|
|
|
|
791 - SLIDE-IN ACCU PACKAGE 9.6V.1.4Ah. NiCd
BSD-2607335203.A52
2607335203
|
-
|
|
|
|
791 - SLIDE-IN ACCU PACKAGE 12V. 1.4Ah. NiCd
BSD-2607335021.A28
2607335021
|
-
|
|
|
|
801 - HOUSING SECTION
BSD-3605105014.A0
3605105014
|
-
|
|
|
|
802 - DC MOTOR 9.6-12V
BSD-3607030295.A2
3607030295
|
£37.72
|
£45.27
|
|
|
851 - SPINDLE WITH GEAR
BSD-3607031549.A6
3607031549
|
-
|
|
|
|
877 - PRINTED-BOARD ASSEMBLY
BSD-3608300178.A9
3608300178
|
-
|
|
|
