2 - SEAL RING
BSD-1600209011.A232
1600209011
|
£2.80
|
£3.36
|
|
|
3 - STATOR 220V/360HZ
BSD-1604229204.A14
1604229204
|
-
|
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600502005.A126
1600502005
|
£2.61
|
£3.13
|
|
|
5 - ROTOR
BSD-3604080020.A103
3604080020
|
-
|
|
|
|
6 - GROOVE BALL BEARING 625-2Z DIN 625
BSD-1900905015.A115
1900905015
|
£30.42
|
£36.51
|
|
|
7 - RUBBER RING 6MM.dia12xdia16.4x3MM
BSD-3600206002.A192
3600206002
|
-
|
|
|
|
7 - RUBBER RING 3 MM
BSD-1600206009.A5
1600206009
|
-
|
|
|
|
8 - GROOVE BALL BEARING 9x24x7
BSD-1900905017.A211
1900905017
|
£23.86
|
£28.63
|
|
|
9 - BEARING HOUSING
BSD-3605820046.A44
3605820046
|
-
|
|
|
|
10 - SEALING DISK
BSD-1600108053.A4
1600108053
|
-
|
|
|
|
13 - SOCKET-TERMINAL STRIP 1x1.5 MM/2
BSD-1901091012.A72
1901091012
|
£5.30
|
£6.36
|
|
|
14 - ON-OFF SWITCH
BSD-1607200040.A72
1607200040
|
-
|
|
|
|
15 - POWER SUPPLY CORD
BSD-3604462058.A21
3604462058
|
-
|
|
|
|
16 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A376
3600703011
|
£2.80
|
£3.36
|
|
|
17 - FASTENING CLAMP
BSD-1601302014.A123
1601302014
|
£2.61
|
£3.13
|
|
|
18 - HANDLE
BSD-3605132072.A21
3605132072
|
-
|
|
|
|
20 - GEAR HOUSING
BSD-2605806227.A57
2605806227
|
-
|
|
|
|
21 - SPINDLE WITH GEAR Z=37
BSD-2606100052.A61
2606100052
|
-
|
|
|
|
22 - BALL DIN 5401-3 MM-III-ST
BSD-1903230004.A245
1903230004
|
£2.16
|
£2.59
|
|
|
23 - COUPLING HALF
BSD-2606445000.A7
2606445000
|
-
|
|
|
|
24 - COMPRESSION SPRING
BSD-1604616010.A32
1604616010
|
-
|
|
|
|
25 - COMPRESSION SPRING
BSD-1604619005.A11
1604619005
|
-
|
|
|
|
26 - SHIM
BSD-1600100607.A59
1600100607
|
-
|
|
|
|
27 - BUSHING
BSD-1600309004.A57
1600309004
|
-
|
|
|
|
28 - ROUND NUT
BSD-1603341000.A14
1603341000
|
-
|
|
|
|
29 - GUIDE SLEEVE
BSD-2600460001.A22
2600460001
|
-
|
|
|
|
30 - CARRIER 6 KT.. 6.3 MM
BSD-2606455002.A23
2606455002
|
-
|
|
|
|
31 - O-RING 8.0x1.5 MM
BSD-1900210103.A85
1900210103
|
£2.80
|
£3.36
|
|
|
32 - PRESSURE SPINDLE
BSD-1603120022.A4
1603120022
|
-
|
|
|
|
33 - COMPRESSION SPRING
BSD-1604626002.A11
1604626002
|
-
|
|
|
|
34 - SPINDLE WITH GEAR Z=14/34
BSD-1606328086.A16
1606328086
|
-
|
|
|
|
36 - SHIM 0.50 MM
BSD-2600100613.A93
2600100613
|
£1.75
|
£2.10
|
|
|
37 - SPRING LOCK WASHER
BSD-1600224011.A7
1600224011
|
-
|
|
|
|
38 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A270
1903230003
|
£2.61
|
£3.13
|
|
|
41 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A610
2910021116
|
£2.16
|
£2.59
|
|
|
42 - SOCKET HEAD CAP SCREW DIN 84-AM4x18-8.8
BSD-2910021128.A150
2910021128
|
-
|
|
|
|
43 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x12-8.8
BSD-2910141122.A205
2910141122
|
£2.16
|
£2.59
|
|
|
44 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x45-8.8
BSD-2910141140.A48
2910141140
|
£1.75
|
£2.10
|
|
|
45 - HEX SOCKET HEAD CAP SCREW
BSD-3603414001.A53
3603414001
|
-
|
|
|
|
46 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A11
2910091118
|
£1.75
|
£2.10
|
|
|
47 - PAN HEAD SCREW DIN 85 AM 4x6-MS
BSD-2910110116.A201
2910110116
|
£1.75
|
£2.10
|
|
|
48 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A354
2910211019
|
£1.75
|
£2.10
|
|
|
50 - SPRING WASHER DIN 137-A4
BSD-1600150006.A770
1600150006
|
-
|
|
|
|
51 - PLAIN WASHER DIN 46 255-DPG 9
BSD-2916010409.A43
2916010409
|
-
|
|
|
|
54 - SET SCREW
BSD-3603402000.A432
3603402000
|
£1.75
|
£2.10
|
|
|
55 - SOCKET HEAD CAP SCREW DIN 84-AM4x5-8.8
BSD-2910021115.A8
2910021115
|
-
|
|
|
|
650 - SINGLE-HEAD ENG. WRENCH DIN 894 SW 12
BSD-1907950506.A108
1907950506
|
£13.12
|
£15.75
|
|
|
651 - STRAIGHT PIN 4x60 MM
BSD-2603101035.A26
2603101035
|
£2.80
|
£3.36
|
|
|
801 - MOTOR HOUSING
BSD-3605102022.A0
3605102022
|
-
|
|
|
|
809 - BEARING HOUSING
BSD-1605820162.A9
1605820162
|
-
|
|
|
