1 - ARMATURE 230V AR-CL-IT (TY Y3)
BDE-369454-13.A13
369454-13
|
-
|
|
|
|
1 - ARMATURE 230V CH (TY Y1-Y2)
BDE-369454-13.A14
369454-13
|
-
|
|
|
|
1 - ARMATURE 230V DE (TY Y1-Y2)
BDE-369454-13.A15
369454-13
|
-
|
|
|
|
1 - ARMATURE 230V SI (TY Y1-Y2)
BDE-369454-13.A16
369454-13
|
-
|
|
|
|
1 - NO LONGER AVAILABLE GB 115V (TY Y3)
BDE-000000-00.A42216
000000-00
|
-
|
|
|
|
1 - ARMATURE 230V CH (TY Y3)
BDE-369454-13.A6
369454-13
|
-
|
|
|
|
1 - ARMATURE 230V GB 240V (TY Y1-Y2)
BDE-369454-13.A7
369454-13
|
-
|
|
|
|
1 - ARMATURE 230V NL-PT-SG (TY Y3)
BDE-369454-13.A8
369454-13
|
-
|
|
|
|
1 - ARMATURE 230V AE-AT-BE-ES (TY Y3)
BDE-369454-13.A9
369454-13
|
-
|
|
|
|
1 - ARMATURE 230V GB 240V (TY Y3)
BDE-369454-13.A10
369454-13
|
-
|
|
|
|
1 - ARMATURE 230V SI (TY Y3)
BDE-369454-13.A11
369454-13
|
-
|
|
|
|
1 - ARMATURE 230V DE-FR (TY Y3)
BDE-369454-13.A12
369454-13
|
-
|
|
|
|
2 - NO LONGER AVAILABLE GB 115V (TY Y3)
BDE-000000-00.A42217
000000-00
|
-
|
|
|
|
2 - FIELD 230V CH (TY Y1-Y2)
BDE-373007-13.A23
373007-13
|
-
|
|
|
|
2 - FIELD 230V GB 240V (TY Y1-Y2)
BDE-373007-13.A24
373007-13
|
-
|
|
|
|
2 - FIELD 230V GB 240V (TY Y3)
BDE-373007-13.A25
373007-13
|
-
|
|
|
|
2 - FIELD 230V CH (TY Y3)
BDE-373007-13.A26
373007-13
|
-
|
|
|
|
2 - FIELD 230V DE (TY Y1-Y2)
BDE-373007-13.A27
373007-13
|
-
|
|
|
|
2 - FIELD 230V DE-FR (TY Y3)
BDE-373007-13.A28
373007-13
|
-
|
|
|
|
2 - FIELD 230V NL-PT-SG (TY Y3)
BDE-373007-13.A29
373007-13
|
-
|
|
|
|
2 - FIELD 230V SI (TY Y1-Y2)
BDE-373007-13.A30
373007-13
|
-
|
|
|
|
2 - FIELD 230V AR-CL-IT (TY Y3)
BDE-373007-13.A31
373007-13
|
-
|
|
|
|
2 - FIELD 230V SI (TY Y3)
BDE-373007-13.A32
373007-13
|
-
|
|
|
|
2 - FIELD 230V AE-AT-BE-ES (TY Y3)
BDE-373007-13.A33
373007-13
|
-
|
|
|
|
3 - NO LONGER AVAILABLE
BDE-000000-00.A42226
000000-00
|
-
|
|
|
|
4 - COVER GEARCASE
BDE-876522.A6
876522
|
-
|
|
|
|
5 - NO LONGER AVAILABLE
BDE-000000-00.A42218
000000-00
|
-
|
|
|
|
6 - NO LONGER AVAILABLE Y1-Y2
BDE-000000-00.A42219
000000-00
|
-
|
|
|
|
6 - NO LONGER AVAILABLE D1
BDE-000000-00.A42220
000000-00
|
-
|
|
|
|
6 - NO LONGER AVAILABLE Y3
BDE-000000-00.A42221
000000-00
|
-
|
|
|
|
7 - NO LONGER AVAILABLE Y1-Y2
BDE-000000-00.A42222
000000-00
|
-
|
|
|
|
7 - NO LONGER AVAILABLE Y3
BDE-000000-00.A42223
000000-00
|
-
|
|
|
|
8 - NO LONGER AVAILABLE
BDE-000000-00.A42224
000000-00
|
-
|
|
|
|
9 - NO LONGER AVAILABLE
BDE-000000-00.A42225
000000-00
|
-
|
|
|
|
10 - CLAMP Y3
BDE-328233-01.A2
328233-01
|
-
|
|
|
|
10 - NO LONGER AVAILABLE D1
BDE-000000-00.A42227
000000-00
|
-
|
|
|
|
10 - CLAMP Y1-Y2
BDE-328233-01.A1
328233-01
|
-
|
|
|
|
11 - BEARING
BDE-915358.A16
915358
|
-
|
|
|
|
12 - NO LONGER AVAILABLE
BDE-000000-00.A42228
000000-00
|
-
|
|
|
|
13 - NO LONGER AVAILABLE
BDE-000000-00.A42229
000000-00
|
-
|
|
|
|
14 - NO LONGER AVAILABLE
BDE-000000-00.A42230
000000-00
|
-
|
|
|
|
15 - NO LONGER AVAILABLE
BDE-000000-00.A42231
000000-00
|
-
|
|
|
|
16 - BAFFLE FAN
BDE-916128.A3
916128
|
-
|
|
|
|
17 - NO LONGER AVAILABLE
BDE-000000-00.A42232
000000-00
|
-
|
|
|
|
18 - NO LONGER AVAILABLE
BDE-000000-00.A42233
000000-00
|
-
|
|
|
|
19 - SPRING
BDE-912748-00.A2
912748-00
|
£1.42
|
£1.70
|
|
|
20 - NO LONGER AVAILABLE
BDE-000000-00.A42234
000000-00
|
-
|
|
|
|
21 - NO LONGER AVAILABLE
BDE-000000-00.A42235
000000-00
|
-
|
|
|
|
22 - FLANGE
BDE-911795.A18
911795
|
-
|
|
|
|
23 - BRUSH & HOLDER 230V Y3
BDE-324826-00.A1
324826-00
|
£5.88
|
£7.06
|
|
|
23 - NO LONGER AVAILABLE D1
BDE-000000-00.A42236
000000-00
|
-
|
|
|
|
23 - NO LONGER AVAILABLE GB 115V (TY Y3)
BDE-000000-00.A42237
000000-00
|
-
|
|
|
|
23 - NO LONGER AVAILABLE Y1-Y2
BDE-000000-00.A42238
000000-00
|
-
|
|
|
|
24 - BRUSH DE (TY Y1-Y2)
BDE-914633.A2
914633
|
£7.85
|
£9.42
|
|
|
24 - BRUSH SI (TY Y1-Y2)
BDE-914633.A3
914633
|
£7.85
|
£9.42
|
|
|
24 - BRUSH GB 240V (TY Y1-Y2)
BDE-914633.A4
914633
|
£7.85
|
£9.42
|
|
|
24 - BRUSH CH (TY Y1-Y2)
BDE-914633.A5
914633
|
£7.85
|
£9.42
|
|
|
25 - BEARING
BDE-330003-31.A86
330003-31
|
£2.78
|
£3.34
|
|
|
26 - CIRCLIP
BDE-913784.A4
913784
|
£1.42
|
£1.70
|
|
|
27 - NO LONGER AVAILABLE CH (TY Y3)
BDE-000000-00.A42239
000000-00
|
-
|
|
|
|
27 - CORDSET NL-PT-SG (TY Y3)
BDE-324438-86.A20
324438-86
|
£16.03
|
£19.24
|
|
|
27 - CORDSET (M/PLUG) GB 240V (TY Y1-Y2)
BDE-330060-44.A47
330060-44
|
£14.57
|
£17.48
|
|
|
27 - CORDSET (M/PLUG) GB 115V (TY Y3)
BDE-330061-04.A47
330061-04
|
£12.17
|
£14.60
|
|
|
27 - NO LONGER AVAILABLE SI (TY Y1-Y2)
BDE-000000-00.A42240
000000-00
|
-
|
|
|
|
27 - CORDSET DE (TY Y1-Y2)
BDE-324438-86.A18
324438-86
|
£16.03
|
£19.24
|
|
|
27 - CORDSET SI (TY Y3)
BDE-324438-86.A19
324438-86
|
£16.03
|
£19.24
|
|
|
27 - NO LONGER AVAILABLE AR-CL-IT (TY Y3)
BDE-000000-00.A42241
000000-00
|
-
|
|
|
|
27 - NO LONGER AVAILABLE CH (TY Y1-Y2)
BDE-000000-00.A42242
000000-00
|
-
|
|
|
|
27 - CORDSET AE-AT-BE-ES (TY Y3)
BDE-324438-86.A16
324438-86
|
£16.03
|
£19.24
|
|
|
27 - CORDSET (M/PLUG) GB 240V (TY Y3)
BDE-330060-44.A48
330060-44
|
£14.57
|
£17.48
|
|
|
27 - CORDSET DE-FR (TY Y3)
BDE-324438-86.A17
324438-86
|
£16.03
|
£19.24
|
|
|
28 - CORD PROTECTOR
BDE-916968.A12
916968
|
-
|
|
|
|
29 - CABLE CLAMP
BDE-910556.A130
910556
|
£1.42
|
£1.70
|
|
|
30 - NO LONGER AVAILABLE AE-AT-BE-ES (TY Y3)
BDE-000000-00.A42243
000000-00
|
-
|
|
|
|
30 - NO LONGER AVAILABLE CH (TY Y1-Y2)
BDE-000000-00.A42244
000000-00
|
-
|
|
|
|
30 - NO LONGER AVAILABLE CH (TY Y3)
BDE-000000-00.A42245
000000-00
|
-
|
|
|
|
30 - NO LONGER AVAILABLE DE (TY Y1-Y2)
BDE-000000-00.A42246
000000-00
|
-
|
|
|
|
30 - NO LONGER AVAILABLE NL-PT-SG (TY Y3)
BDE-000000-00.A42247
000000-00
|
-
|
|
|
|
30 - NO LONGER AVAILABLE AR-CL-IT (TY Y3)
BDE-000000-00.A42248
000000-00
|
-
|
|
|
|
30 - NO LONGER AVAILABLE DE-FR (TY Y3)
BDE-000000-00.A42249
000000-00
|
-
|
|
|
|
30 - NO LONGER AVAILABLE GB 240V (TY Y1-Y2)
BDE-000000-00.A42250
000000-00
|
-
|
|
|
|
30 - SWITCH GB 115V (TY Y3)
BDE-590976-00.A6
590976-00
|
-
|
|
|
|
30 - NO LONGER AVAILABLE SI (TY Y1-Y2)
BDE-000000-00.A42251
000000-00
|
-
|
|
|
|
30 - NO LONGER AVAILABLE GB 240V (TY Y3)
BDE-000000-00.A42252
000000-00
|
-
|
|
|
|
30 - NO LONGER AVAILABLE SI (TY Y3)
BDE-000000-00.A42253
000000-00
|
-
|
|
|
|
31 - CAPACITOR
BDE-321384.A152
321384
|
£1.50
|
£1.80
|
|
|
33 - HOLDER
BDE-911897.A64
911897
|
-
|
|
|
|
34 - NO LONGER AVAILABLE
BDE-000000-00.A42254
000000-00
|
-
|
|
|
|
35 - NO LONGER AVAILABLE
BDE-000000-00.A42255
000000-00
|
-
|
|
|
|
36 - NO LONGER AVAILABLE Y3
BDE-000000-00.A42256
000000-00
|
-
|
|
|
|
36 - NO LONGER AVAILABLE D1
BDE-000000-00.A42257
000000-00
|
-
|
|
|
|
36 - NO LONGER AVAILABLE Y1-Y2
BDE-000000-00.A42258
000000-00
|
-
|
|
|
|
37 - BEARING
BDE-910560.A9
910560
|
£1.50
|
£1.80
|
|
|
38 - NO LONGER AVAILABLE
BDE-000000-00.A42292
000000-00
|
-
|
|
|
|
39 - NO LONGER AVAILABLE
BDE-000000-00.A42293
000000-00
|
-
|
|
|
|
40 - NO LONGER AVAILABLE Y3
BDE-000000-00.A42294
000000-00
|
-
|
|
|
|
40 - NO LONGER AVAILABLE D1
BDE-000000-00.A42295
000000-00
|
-
|
|
|
|
40 - NO LONGER AVAILABLE Y1-Y2
BDE-000000-00.A42296
000000-00
|
-
|
|
|
|
41 - NO LONGER AVAILABLE
BDE-000000-00.A42297
000000-00
|
-
|
|
|
|
42 - NO LONGER AVAILABLE Y3
BDE-000000-00.A42298
000000-00
|
-
|
|
|
|
42 - SCREW Y1-Y2
BDE-911276.A51
911276
|
£1.42
|
£1.70
|
|
|
42 - SCREW D1
BDE-911276.A52
911276
|
£1.42
|
£1.70
|
|
|
43 - WASHER D1
BDE-330016-01.A9
330016-01
|
£1.50
|
£1.80
|
|
|
43 - WASHER Y1-Y2
BDE-330016-01.A10
330016-01
|
£1.50
|
£1.80
|
|
|
43 - WASHER Y3
BDE-725165.A16
725165
|
£1.50
|
£1.80
|
|
|
44 - SCREW Y3
BDE-911026.A36
911026
|
£1.50
|
£1.80
|
|
|
44 - SCREW D1
BDE-911026.A37
911026
|
£1.50
|
£1.80
|
|
|
44 - SCREW Y1-Y2
BDE-911026.A38
911026
|
£1.50
|
£1.80
|
|
|
45 - NO LONGER AVAILABLE
BDE-000000-00.A42299
000000-00
|
-
|
|
|
|
46 - NUT WING
BDE-915848.A7
915848
|
-
|
|
|
|
47 - WING NUT
BDE-478905-00.A5
478905-00
|
-
|
|
|
|
48 - BEARING NEEDLE
BDE-330004-31.A22
330004-31
|
£3.80
|
£4.56
|
|
|
49 - SCREW
BDE-894748.A63
894748
|
£1.42
|
£1.70
|
|
|
50 - WASHER
BDE-249092-20.A20
249092-20
|
£1.42
|
£1.70
|
|
|
51 - NO LONGER AVAILABLE
BDE-000000-00.A42300
000000-00
|
-
|
|
|
|
52 - SCREW
BDE-911059.A14
911059
|
£1.42
|
£1.70
|
|
|
53 - NO LONGER AVAILABLE
BDE-000000-00.A42301
000000-00
|
-
|
|
|
|
54 - NO LONGER AVAILABLE
BDE-000000-00.A42302
000000-00
|
-
|
|
|
|
55 - NO LONGER AVAILABLE
BDE-000000-00.A42303
000000-00
|
-
|
|
|
|
57 - SCREW
BDE-860301-00.A47
860301-00
|
£1.50
|
£1.80
|
|
|
58 - NO LONGER AVAILABLE
BDE-000000-00.A42312
000000-00
|
-
|
|
|
|
59 - NO LONGER AVAILABLE
BDE-000000-00.A42313
000000-00
|
-
|
|
|
|
66 - HEX KEY
BDE-322929.A41
322929
|
-
|
|
|
|
67 - WASHER
BDE-910623.A56
910623
|
-
|
|
|
|
68 - INSERT
BDE-917101.A2
917101
|
£1.78
|
£2.13
|
|
|
69 - NO LONGER AVAILABLE
BDE-000000-00.A42314
000000-00
|
-
|
|
|
|
70 - SCREW
BDE-911141.A19
911141
|
£1.50
|
£1.80
|
|
|
72 - NO LONGER AVAILABLE Y1-Y2
BDE-000000-00.A42259
000000-00
|
-
|
|
|
|
72 - NO LONGER AVAILABLE D1
BDE-000000-00.A42260
000000-00
|
-
|
|
|
|
73 - NO LONGER AVAILABLE
BDE-000000-00.A42261
000000-00
|
-
|
|
|
|
76 - NO LONGER AVAILABLE Y3
BDE-000000-00.A42262
000000-00
|
-
|
|
|
|
78 - NO LONGER AVAILABLE AE-AT-BE-ES (TY Y3)
BDE-000000-00.A42263
000000-00
|
-
|
|
|
|
78 - NO LONGER AVAILABLE AR-CL-IT (TY Y3)
BDE-000000-00.A42264
000000-00
|
-
|
|
|
|
78 - NO LONGER AVAILABLE GB 115V (TY Y3)
BDE-000000-00.A42265
000000-00
|
-
|
|
|
|
78 - NO LONGER AVAILABLE SI (TY Y3)
BDE-000000-00.A42266
000000-00
|
-
|
|
|
|
78 - NO LONGER AVAILABLE CH (TY Y3)
BDE-000000-00.A42267
000000-00
|
-
|
|
|
|
78 - NO LONGER AVAILABLE NL-PT-SG (TY Y3)
BDE-000000-00.A42268
000000-00
|
-
|
|
|
|
78 - NO LONGER AVAILABLE DE-FR (TY Y3)
BDE-000000-00.A42269
000000-00
|
-
|
|
|
|
78 - NO LONGER AVAILABLE GB 240V (TY Y3)
BDE-000000-00.A42270
000000-00
|
-
|
|
|
