1 - HOUSING SECTION
BSD-2605104994.A0
2605104994
|
-
|
|
|
|
2 - FIELD 220-240V
BSD-2604220423.A95
2604220423
|
£25.68
|
£30.81
|
|
|
3 - ARMATURE 220V
BSD-2604010658.A6
2604010658
|
-
|
|
|
|
3/50 - FAN
BSD-2606610027.A165
2606610027
|
£2.80
|
£3.36
|
|
|
4 - SWITCH
BSD-2607200199.A16
2607200199
|
-
|
|
|
|
5 - POWER SUPPLY CORD EU 2.65m 2 x 1.0mm H05 RN-F
BSD-1607000388.A55
1607000388
|
£12.04
|
£14.45
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A974
2600703012
|
£2.94
|
£3.53
|
|
|
7 - CABLE CLIP
BSD-2601035001.A475
2601035001
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601118929.A4
2601118929
|
-
|
|
|
|
12 - SUPPRESSION CAPACITOR
BSD-2607329117.A6
2607329117
|
-
|
|
|
|
14 - GROOVE BALL BEARING 15x32x9
BSD-2600905017.A29
2600905017
|
£10.61
|
£12.73
|
|
|
16 - BRUSH HOLDER
BSD-2604449026.A74
2604449026
|
£1.84
|
£2.21
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A426
2603410001
|
£1.84
|
£2.21
|
|
|
22 - BRUSH PLATE
BSD-2601015054.A59
2601015054
|
-
|
|
|
|
25 - O-RING 15x2 MM
BSD-1900210012.A37
1900210012
|
£1.84
|
£2.21
|
|
|
26 - RETAINING CLIP DIN 471-15x1-FSt
BSD-2916650006.A490
2916650006
|
£1.75
|
£2.10
|
|
|
27 - BUSHING
BSD-2600300062.A9
2600300062
|
-
|
|
|
|
28 - CUPPED WASHER
BSD-2600500033.A98
2600500033
|
£2.74
|
£3.29
|
|
|
29 - FELT WASHER
BSD-2600108033.A70
2600108033
|
£1.84
|
£2.21
|
|
|
30 - COLLET
BSD-2608570005.A4
2608570005
|
£15.65
|
£18.78
|
|
|
31 - UNION NUT SW 17. dia 18.5 MM
BSD-2603312006.A12
2603312006
|
£6.85
|
£8.22
|
|
|
32 - BALL dia 6.5 MM
BSD-2603230000.A10
2603230000
|
-
|
|
|
|
33 - SQUARE NUT M8
BSD-2603320003.A71
2603320003
|
£1.75
|
£2.10
|
|
|
34 - HANDLE
BSD-1603481001.A44
1603481001
|
-
|
|
|
|
35 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A1280
2915011007
|
-
|
|
|
|
36 - CONNECTING CABLE
BSD-2604448082.A6
2604448082
|
-
|
|
|
|
37 - CONNECTING CABLE
BSD-2604448083.A3
2604448083
|
-
|
|
|
|
38 - HOUSING COVER
BSD-2605500083.A9
2605500083
|
-
|
|
|
|
45 - PLAIN WASHER
BSD-2600101109.A8
2600101109
|
-
|
|
|
|
46 - SOCKET HEAD CAP SCREW DIN 84-AM6x16-5.8
BSD-2910011191.A68
2910011191
|
-
|
|
|
|
47 - COMPRESSION SPRING
BSD-2604617001.A10
2604617001
|
£1.32
|
£1.58
|
|
|
48 - DEPTH-GAUGE
BSD-2602316006.A7
2602316006
|
-
|
|
|
|
52 - WING SCREW M 6x16 MM
BSD-2603480003.A90
2603480003
|
£2.74
|
£3.29
|
|
|
54 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A112
2916011014
|
£1.84
|
£2.21
|
|
|
654 - STRAIGHT PIN 4x60 MM
BSD-2603101035.A153
2603101035
|
£2.94
|
£3.53
|
|
|
655 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A592
2607950511
|
£4.48
|
£5.37
|
|
|
656 - GUIDING BOLT
BSD-2603102004.A1
2603102004
|
-
|
|
|
|
657 - EDGE GUIDE
BSD-2608005016.A4
2608005016
|
-
|
|
|
|
659 - CLAMPING PIECE
BSD-2608040024.A8
2608040024
|
-
|
|
|
|
660 - O-RING 4.0x1.5 MM
BSD-1610210043.A125
1610210043
|
£1.84
|
£2.21
|
|
|
661 - SUCTION NOZZLE
BSD-2605730024.A2
2605730024
|
£9.11
|
£10.93
|
|
|
662 - PROTECTIVE RING
BSD-2605730034.A8
2605730034
|
-
|
|
|
|
663 - HOSE FITTING dia30xdia36x66 MM
BSD-1600306008.A10
1600306008
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A1402
160111A3H3
|
£2.74
|
£3.29
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321905.A681
2604321905
|
£11.87
|
£14.24
|
|
|
821 - RUBBER PLUG
BSD-2603239010.A24
2603239010
|
-
|
|
|
|
823 - TAPPING SCREW DIN 7981-ST2.9x13-C-H
BSD-2910611006.A100
2910611006
|
£1.84
|
£2.21
|
|
|
824 - BUSHING
BSD-2600420900.A9
2600420900
|
-
|
|
|
|
840 - SCREW 4x16
BSD-2603490022.A1369
2603490022
|
£1.84
|
£2.21
|
|
|
842 - BASE PLATE
BSD-2608000902.A8
2608000902
|
-
|
|
|
