1 - HOUSING SECTION
BSD-1615104030.A1
1615104030
|
£33.45
|
£40.14
|
|
|
2 - POLE HOUSING 14;4-24V
BSD-2610942109.A6
2610942109
|
£21.68
|
£26.01
|
|
|
4 - ON-OFF SWITCH
BSD-1617200067.A47
1617200067
|
£68.42
|
£82.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110X14.A0
1611110X14
|
£3.34
|
£4.01
|
|
|
11 - REFERENCE PLATE
BSD-1611110X15.A0
1611110X15
|
£3.34
|
£4.01
|
|
|
13 - GROOVE BALL BEARING 8x22x7
BSD-1600905033.A38
1600905033
|
£7.36
|
£8.83
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-2600905052.A349
2600905052
|
£7.36
|
£8.83
|
|
|
15 - FAN
BSD-1616610092.A12
1616610092
|
£6.61
|
£7.93
|
|
|
17 - SPIRAL SPRING
BSD-1614652008.A34
1614652008
|
£2.16
|
£2.59
|
|
|
18 - DAMPING RUBBER
BSD-2603100056.A136
2603100056
|
£1.75
|
£2.10
|
|
|
27 - STRIKER
BSD-1618710076.A11
1618710076
|
£6.61
|
£7.93
|
|
|
30 - DRIVE LEVER
BSD-1611911000.A46
1611911000
|
-
|
|
|
|
34 - BEARING PIN
BSD-1613100021.A44
1613100021
|
£2.33
|
£2.80
|
|
|
45 - DRIVE PINION Z=9
BSD-1616316602.A45
1616316602
|
£14.75
|
£17.70
|
|
|
46 - STRAIGHT PIN
BSD-1613160022.A76
1613160022
|
£1.75
|
£2.10
|
|
|
47 - INSULATING PLATE
BSD-1601010010.A20
1601010010
|
£5.01
|
£6.01
|
|
|
53 - NEEDLE BEARING
BSD-1610910077.A69
1610910077
|
£4.26
|
£5.11
|
|
|
57 - ROLLER THRUST BEARING
BSD-1610920009.A51
1610920009
|
£3.34
|
£4.01
|
|
|
62 - O-RING 18.0x2.5 MM
BSD-1610210125.A39
1610210125
|
£1.95
|
£2.34
|
|
|
72 - SHIM WASHER 1.0 MM
BSD-1610100007.A76
1610100007
|
£1.75
|
£2.10
|
|
|
74 - SEALING FRAME
BSD-1611015045.A35
1611015045
|
£5.30
|
£6.36
|
|
|
75 - SEALING FRAME
BSD-1611015041.A99
1611015041
|
£1.95
|
£2.34
|
|
|
76 - SEAL RING
BSD-1610210138.A8
1610210138
|
£1.75
|
£2.10
|
|
|
77 - RETAINING RING
BSD-1614601026.A0
1614601026
|
£1.75
|
£2.10
|
|
|
78 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A271
1903230010
|
£1.75
|
£2.10
|
|
|
80 - SEALING DISK
BSD-1610100008.A10
1610100008
|
£1.75
|
£2.10
|
|
|
81 - LOCATING RING
BSD-1610290043.A52
1610290043
|
£2.16
|
£2.59
|
|
|
83 - LOCATING RING
BSD-1610290078.A1
1610290078
|
£2.33
|
£2.80
|
|
|
84 - INSERTED PART
BSD-1601016013.A0
1601016013
|
£1.95
|
£2.34
|
|
|
85 - SWITCH SLIDE
BSD-1613231006.A32
1613231006
|
£1.95
|
£2.34
|
|
|
86 - CONTACT RETAINER
BSD-1609280157.A8
1609280157
|
-
|
|
|
|
92 - TAPPING SCREW DIN7981-ST3.9x22-C-Z
BSD-2912401021.A237
2912401021
|
£1.75
|
£2.10
|
|
|
93 - TAPPING SCREW DIN7981-ST3.9x16-C-Z
BSD-2912401019.A238
2912401019
|
£1.75
|
£2.10
|
|
|
94 - TAPPING SCREW DIN 7981-ST2.9x16.0-C-Z
BSD-2912401007.A12
2912401007
|
£1.75
|
£2.10
|
|
|
98 - CONNECTING CABLE L=260 MM
BSD-1614416012.A50
1614416012
|
£1.75
|
£2.10
|
|
|
99 - CONNECTING CABLE L=270 MM
BSD-1614416011.A3
1614416011
|
£1.75
|
£2.10
|
|
|
652 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001009.A371
1613001009
|
£3.72
|
£4.47
|
|
|
653 - BATTERY PACK 24V.2.0Ah.NiCd
BSD-2607335445.A15
2607335445
|
£263.33
|
£316.00
|
|
|
653 - BATTERY PACK 24V.2.6Ah.NiMh
BSD-2607335561.A5
2607335561
|
-
|
|
|
|
653 - BATTERY PACK 24V.3.0Ah.NiMh
BSD-2607335509.A1
2607335509
|
-
|
|
|
|
654 - FAST CHARGER J 100/7.2-24V. 15 MIN.
BSD-2607224493.A1
2607224493
|
£218.41
|
£262.09
|
|
|
654 - FAST CHARGER EU 230/7.2-24V. 30 MIN.
BSD-2607225027.A123
2607225027
|
£120.11
|
£144.13
|
|
|
654 - FAST CHARGER EU 230/7.2-24V. 1h
BSD-2607224425.A66
2607224425
|
£88.07
|
£105.68
|
|
|
654 - FAST CHARGER GB 230/7.2-24V. 1h
BSD-2607224427.A230
2607224427
|
£103.14
|
£123.77
|
|
|
654 - FAST CHARGER GB 230/7.2-24V. 30 MIN.
BSD-2607225029.A47
2607225029
|
£88.07
|
£105.68
|
|
|
654 - FAST CHARGER AUS 240/7.2-24V. 1h
BSD-2607224429.A8
2607224429
|
£102.57
|
£123.08
|
|
|
655 - PROTECTIVE CAP
BSD-1610508032.A39
1610508032
|
£2.16
|
£2.59
|
|
|
661 - GREASE TUBE 30 ML
BSD-1615430010.A175
1615430010
|
£6.52
|
£7.83
|
|
|
803 - ARMATURE WITH FAN 24V
BSD-1617000511.A3
1617000511
|
£93.88
|
£112.65
|
|
|
808 - NAMEPLATE
BSD-160111A3H9.A2
160111A3H9
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-1617014131.A37
1617014131
|
-
|
|
|
|
816 - BRUSH HOLDER L=145 MM
BSD-1617000379.A19
1617000379
|
-
|
|
|
|
817 - BRUSH HOLDER L=45 MM
BSD-1617000380.A34
1617000380
|
-
|
|
|
|
820 - AUXILIARY HANDLE dia43 MM
BSD-2602025118.A85
2602025118
|
£14.91
|
£17.89
|
|
|
820/120 - AUXILIARY HANDLE M8
BSD-1612025019.A139
1612025019
|
£6.52
|
£7.83
|
|
|
820/124 - CLAMPING BAND dia43 MM
BSD-1611316006.A5
1611316006
|
£2.61
|
£3.13
|
|
|
820/125 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A628
1613490002
|
£4.26
|
£5.11
|
|
|
820/802 - SUPPORT CLAMP dia43 MM
BSD-2608040176.A87
2608040176
|
£6.52
|
£7.83
|
|
|
821 - HAMMER PIPE
BSD-1617000387.A11
1617000387
|
-
|
|
|
|
824 - JACK SHAFT Z=31/12
BSD-1617000314.A50
1617000314
|
£46.82
|
£56.18
|
|
|
844 - CLAMP HANDLE
BSD-1617000322.A34
1617000322
|
£3.72
|
£4.47
|
|
|
850 - BUSHING
BSD-1617000975.A21
1617000975
|
£6.61
|
£7.93
|
|
|
856 - KEYLESS CHUCK
BSD-1617000332.A11
1617000332
|
£93.88
|
£112.65
|
|
|
857 - KEY CHUCK
BSD-1618571029.A2
1618571029
|
£63.50
|
£76.20
|
|
|
858 - CHUCK WRENCH SG2
BSD-2607950007.A406
2607950007
|
£6.52
|
£7.83
|
|
|
870 - QUICK-CHANGE COLLET CHUCK
BSD-1617000327.A23
1617000327
|
£63.50
|
£76.20
|
|
|
870/34 - PROTECTIVE CAP
BSD-1610508047.A57
1610508047
|
£2.29
|
£2.75
|
|
|
899 - CORDLESS ROTARY HAMMER 24V
BSD-0611262220.A0
0611262220
|
-
|
|
|
|
899 - CORDLESS ROTARY HAMMER 24V
BSD-0611262223.A0
0611262223
|
-
|
|
|
