2 - FIELD 220-230V
BSD-1614220172.A26
1614220172
|
£21.68
|
£26.01
|
|
|
3/60 - FAN
BSD-1616610095.A23
1616610095
|
£2.16
|
£2.59
|
|
|
4 - ON-OFF SWITCH
BSD-1617200047.A20
1617200047
|
£21.68
|
£26.01
|
|
|
5 - POWER SUPPLY CORD CH 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1604460440.A29
1604460440
|
£21.52
|
£25.83
|
|
|
6 - GROMMET dia7.3-dia8.6x76 MM
BSD-2600703018.A253
2600703018
|
£2.61
|
£3.13
|
|
|
7 - CABLE CLIP
BSD-1611035005.A198
1611035005
|
£2.16
|
£2.59
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110X23.A1
1611110X23
|
-
|
|
|
|
10 - REFERENCE PLATE
BSD-1611110656.A3
1611110656
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1617328025.A7
1617328025
|
£5.58
|
£6.70
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A111
1610905025
|
£6.52
|
£7.83
|
|
|
14 - GROOVE BALL BEARING 9x24x7
BSD-1610905048.A333
1610905048
|
£8.67
|
£10.41
|
|
|
16 - BRUSH HOLDER
BSD-1614336022.A12
1614336022
|
£2.80
|
£3.36
|
|
|
18 - AIR-DEFLECTOR RING
BSD-1610522009.A88
1610522009
|
£1.32
|
£1.58
|
|
|
22 - CYLINDRICAL GEAR Z=50
BSD-1616317602.A55
1616317602
|
£12.04
|
£14.45
|
|
|
24 - TOOTHED SHAFT Z=3/9
BSD-1617000518.A113
1617000518
|
£40.80
|
£48.96
|
|
|
26 - HAMMER PISTON
BSD-1618700062.A70
1618700062
|
£14.91
|
£17.89
|
|
|
27 - STRIKER
BSD-1618710057.A74
1618710057
|
£16.41
|
£19.69
|
|
|
28 - STRIKER PIN
BSD-1613124040.A79
1613124040
|
£5.30
|
£6.36
|
|
|
29 - PISTON PIN
BSD-1613105012.A288
1613105012
|
£3.72
|
£4.47
|
|
|
31 - PROTECTIVE GRILLE
BSD-1615510003.A24
1615510003
|
£2.61
|
£3.13
|
|
|
34 - PROTECTIVE CAP L=17 MM. SDS-PLUS
BSD-1610508008.A235
1610508008
|
£2.16
|
£2.59
|
|
|
35 - RUBBER RING
BSD-1610206021.A273
1610206021
|
£1.75
|
£2.10
|
|
|
37 - DAMPING BUSHING
BSD-1610390017.A43
1610390017
|
£5.30
|
£6.36
|
|
|
38 - SUPPORTING DISC
BSD-1610102026.A109
1610102026
|
£2.61
|
£3.13
|
|
|
41 - SHIM WASHER 1.2 MM
BSD-1610101011.A162
1610101011
|
£1.75
|
£2.10
|
|
|
42 - PLAIN BEARING
BSD-1610202015.A95
1610202015
|
£2.80
|
£3.36
|
|
|
43 - TAB WASHER
BSD-1611098005.A41
1611098005
|
£2.80
|
£3.36
|
|
|
44 - SWITCHING ELEMENT
BSD-1615820092.A60
1615820092
|
£2.61
|
£3.13
|
|
|
45 - SWITCH SPRING
BSD-1614651014.A44
1614651014
|
£1.75
|
£2.10
|
|
|
46 - DRIVER PIN
BSD-1614690002.A44
1614690002
|
£1.75
|
£2.10
|
|
|
48 - HOLDING PLATE
BSD-1611016003.A180
1611016003
|
£2.16
|
£2.59
|
|
|
49 - SWITCH BUTTON
BSD-1612026035.A40
1612026035
|
£1.75
|
£2.10
|
|
|
60 - NEEDLE-ROLLER BEARING
BSD-1610910073.A87
1610910073
|
£11.30
|
£13.56
|
|
|
61 - NEEDLE BEARING
BSD-1610910098.A86
1610910098
|
£3.72
|
£4.47
|
|
|
62 - NEEDLE BEARING
BSD-1610910074.A39
1610910074
|
£3.72
|
£4.47
|
|
|
63 - NEEDLE BEARING
BSD-1610910064.A131
1610910064
|
£2.52
|
£3.02
|
|
|
64 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913010.A84
1610913010
|
£4.26
|
£5.11
|
|
|
65 - PLAIN BEARING
BSD-1610591016.A18
1610591016
|
£2.80
|
£3.36
|
|
|
67 - GROOVE BALL BEARING
BSD-1610905016.A86
1610905016
|
£10.10
|
£12.12
|
|
|
70 - SHAFT SEAL
BSD-1610283019.A64
1610283019
|
£7.36
|
£8.83
|
|
|
71 - SCRAPER
BSD-1610290029.A61
1610290029
|
£3.72
|
£4.47
|
|
|
72 - O-RING 24.0x2.5 MM
BSD-1610210068.A216
1610210068
|
£1.75
|
£2.10
|
|
|
73 - O-RING
BSD-1610210187.A201
1610210187
|
£2.16
|
£2.59
|
|
|
74 - O-RING 11.0x3.5 MM
BSD-1610210104.A98
1610210104
|
£2.61
|
£3.13
|
|
|
75 - O-RING 18.0x3.5 MM
BSD-1610210105.A47
1610210105
|
£4.26
|
£5.11
|
|
|
76 - O-RING 10.5x2.7 MM
BSD-1610210046.A62
1610210046
|
£2.16
|
£2.59
|
|
|
77 - O-RING 60.0x3.0 MM
BSD-1610210106.A98
1610210106
|
£2.61
|
£3.13
|
|
|
80 - COMPRESSION SPRING
BSD-1614634005.A43
1614634005
|
£1.75
|
£2.10
|
|
|
81 - COMPRESSION SPRING
BSD-1614611009.A14
1614611009
|
£1.75
|
£2.10
|
|
|
83 - COMPRESSION SPRING
BSD-1614611006.A367
1614611006
|
£3.72
|
£4.47
|
|
|
85 - RETAINING RING
BSD-1614601011.A105
1614601011
|
£1.75
|
£2.10
|
|
|
86 - RETAINING RING
BSD-1614601024.A20
1614601024
|
£1.75
|
£2.10
|
|
|
87 - RETAINING RING DIN 7993-A22
BSD-2916540012.A175
2916540012
|
-
|
|
|
|
88 - ROLLER
BSD-1613200007.A53
1613200007
|
£1.75
|
£2.10
|
|
|
89 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A661
1903230013
|
£2.16
|
£2.59
|
|
|
90 - TAPPING SCREW 4.8x78 MM. TORX T-20
BSD-1603435036.A58
1603435036
|
£1.75
|
£2.10
|
|
|
91 - LENS HEAD SCREW 4x32
BSD-2603490026.A205
2603490026
|
£1.75
|
£2.10
|
|
|
92 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A77
2603490023
|
£1.75
|
£2.10
|
|
|
93 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A493
2910211005
|
£1.75
|
£2.10
|
|
|
94 - RECESSED-HEAD SCREW DIN 7981-ST3.5x9.5-F
BSD-2603435015.A602
2603435015
|
£2.16
|
£2.59
|
|
|
95 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2736
2603410001
|
£1.75
|
£2.10
|
|
|
96 - TAPPING SCREW DIN7981-ST3.9x13-C-Z
BSD-2912401018.A76
2912401018
|
£1.75
|
£2.10
|
|
|
102 - CABLE L=130 MM
BSD-2604448005.A154
2604448005
|
£1.75
|
£2.10
|
|
|
700 - DRILL CHUCK SHANK
BSD-1617000132.A31
1617000132
|
£16.84
|
£20.21
|
|
|
700/20 - COUNTERSUNK-HEAD SCREW M6x27
BSD-2603421226.A243
2603421226
|
£1.75
|
£2.10
|
|
|
701 - KEY CHUCK R/L dia13 MM. 1/2-20 UNF
BSD-1608571062.A34
1608571062
|
£17.49
|
£20.99
|
|
|
701/700 - CHUCK WRENCH SG2
BSD-2607950007.A516
2607950007
|
£6.52
|
£7.83
|
|
|
711 - PARTS SET
BSD-1617000133.A194
1617000133
|
-
|
|
|
|
711/10/2 - RETAINING RING
BSD-2604601004.A225
2604601004
|
£1.75
|
£2.10
|
|
|
750 - CARRYING CASE
BSD-2605438294.A29
2605438294
|
-
|
|
|
|
755 - ANGLE DRILL HEAD
BSD-1618580000.A71
1618580000
|
£239.08
|
£286.90
|
|
|
801 - MOTOR HOUSING
BSD-1617000477.A45
1617000477
|
£18.96
|
£22.75
|
|
|
803 - ARMATURE WITH FAN 220-230V
BSD-1614010732.A22
1614010732
|
£81.81
|
£98.17
|
|
|
811 - CARBON-BRUSH SET
BSD-1617014132.A0
1617014132
|
£12.04
|
£14.45
|
|
|
819 - GEAR HOUSING
BSD-1617000385.A1
1617000385
|
£33.45
|
£40.14
|
|
|
820 - INTERMEDIATE FLANGE
BSD-1617000981.A2
1617000981
|
£27.23
|
£32.68
|
|
|
821 - RATCHET SLEEVE SDS-PLUS
BSD-1616490061.A55
1616490061
|
£59.53
|
£71.44
|
|
|
821/01 - RATCHET SLEEVE SDS-PLUS
BSD-1616490060.A42
1616490060
|
£72.18
|
£86.62
|
|
|
822 - AUXILIARY HANDLE dia43 MM
BSD-2602025118.A44
2602025118
|
£14.91
|
£17.89
|
|
|
822/120 - AUXILIARY HANDLE M8
BSD-1612025019.A167
1612025019
|
£6.52
|
£7.83
|
|
|
822/124 - CLAMPING BAND dia43 MM
BSD-1611316006.A204
1611316006
|
£2.61
|
£3.13
|
|
|
822/125 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A398
1613490002
|
£4.26
|
£5.11
|
|
|
822/802 - SUPPORT CLAMP dia43 MM
BSD-2608040176.A84
2608040176
|
£6.52
|
£7.83
|
|
|
823 - GEAR SLEEVE Z=26/6
BSD-1616328042.A40
1616328042
|
£40.80
|
£48.96
|
|
|
826 - TOOTHED SHAFT Z=3/9
BSD-1617000517.A10
1617000517
|
£72.18
|
£86.62
|
|
|
830 - DRIVE BEARING
BSD-1615819018.A42
1615819018
|
£51.22
|
£61.47
|
|
|
832 - CLAMP HANDLE
BSD-1612026037.A176
1612026037
|
£10.82
|
£12.99
|
|
|
833 - PROTECTION SLEEVE
BSD-1617000163.A161
1617000163
|
£7.36
|
£8.83
|
|
|
847 - GUIDE RING
BSD-1617000348.A64
1617000348
|
£14.91
|
£17.89
|
|
|
879 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001009.A128
1613001009
|
£3.72
|
£4.47
|
|
|
888 - NAMEPLATE
BSD-160111A3H5.A118
160111A3H5
|
£2.61
|
£3.13
|
|
